Frigidaire 316560156 Oven Control Board (Clock/Timer) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316560156 replaces AP4979587, 1864822, AH3490771, EA3490771, PS3490771.

Description

This electronic oven control board manages bake and broil functions and provides the clock/timer display. Replacing a failed control can restore accurate temperature regulation, reliable oven operation, and a readable time display.

• Regulates oven heating by controlling bake and broil relays based on temperature sensor input
• Powers elements or igniters to reach and hold set temperatures
• Displays clock, timer, and oven status/settings
• Common symptoms of failure: oven won't heat or overheats, blank or dim display, can't set temperature/timer, unresponsive controls, intermittent beeping

What's included: 1 electronic control board assembly Installation notes:

• Disconnect power at the breaker before servicing
• This is an ESD-sensitive board; handle by the edges and avoid touching components
• Photograph and label wire connectors; transfer connectors and any mounting hardware from the original control
• After installation, set the clock and run a test bake to verify operation
