Frigidaire 297345201 Icemaker Assembly OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Freezer Cap Or Cover and Freezer Ice Maker & Related.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 297345201 replaces AP6332957, 297345200, 297306700, 4838938, PS12364245.

Description

This icemaker assembly replaces the automatic ice maker in your freezer. It restores dependable ice production by controlling the fill–freeze–eject cycle, providing a steady supply of properly sized cubes to the bin when operating correctly.

• Automates the fill, freeze, and harvest cycle to produce ice cubes and drop them into the bin
• Sends power to the water inlet valve during the fill portion of the cycle; stops production when the bin is full (shut-off arm, if equipped)
• Common symptoms of a failed icemaker include no ice production, slow or small cubes, cubes not ejecting, or leaking/overflowing from the icemaker area
• Replaces a worn or seized icemaker module to restore normal cube production

What's included: 1 icemaker assembly Install notes:

• Disconnect power and shut off the water supply before servicing
• Remove the ice bin for access; detach the old unit and disconnect its wire harness
• Mount the new assembly; ensure the fill tube is aligned and the shut-off arm moves freely
• Restore power and water; discard the first batch and allow up to 24 hours for production to normalize
