Homer G Palm City , FL June 13, 2021 Oven would not pre heat to required temperature. I read that the controller and probe controlled the oven temperature. Also read if replacing controller you should replace the overlay. So I ordered all three parts and installed myself with no problem. I took a photo with my phone prior to unplugging wires so I knew the right way to plug the wires into the new controller. Works like new. Only need a nut driver and screwdriver to repair. Job from star to finish approximately 30 minutes. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
William P Wendell , NC February 22, 2019 Bad control board on Kenmore oven Replaced control board and front button panel due to malfunctioning electronic control board causing F30 error (temperature sensor error). Repair resolved issue and was quite simple. Note that the front button panel is a separate part that must be ordered and replaced when the ECM is replaced. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Socket Set
Paul H Cary , NC September 27, 2021 Appliance: Model 790.92803015 Oven not heating correct Replaced the Controller unit and display. After ordering the CONTROLLER we discovered we also needed the DISPLAY after talking to the Tech department. No where did it ever say when ordering this CONTROLLER you MUST also order the DISPLAY, So I ended up paying 2 Shipping charges. There must be a way to tell people about this problem. Or sell the CONTROLLER and DISPLAY as 1 unit. Paul Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
Darren P Chalfont , PA September 25, 2015 Appliance: Model 79092809013 Error code on kenmore electric rangemodel #79092809013 oven would overheat and not turn off Ordered Controller - Part Number: AP5325528 Replacement was simple. Removed back cover to get to controller. Controller was held on by four screws. Be sure to take picture of where they wires go to make it easy to install the new controller. Reconnected wires and replaced cover. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
