Parts for Ge YFD45ESPM1DG: Front Panel Parts

The Filter and Mesh Assembly is an OEM part for dryers. This part captures lint and other debris from the air stream during the drying cycle, preventing it from clogging the dryer's internal components or being expelled into the surrounding area.

Causes of a bad filter include excessive lint buildup, damage from mishandling, or general wear and tear over time.

Symptoms of a bad filter and mesh assembly include:

• Clothes taking longer to dry
• Restricted airflow from the dryer
• Overheating or excessive heat buildup
• Visible lint accumulation around the dryer

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This dryer gasket seals a duct connection inside the appliance to keep airflow on the intended path and contain heat and lint. Replacing a worn gasket helps restore drying performance and reduces lint and air leaks.

• Seals the joint between the duct and mating surface to maintain proper airflow
• Helps keep heat and lint inside the air path and out of the cabinet
• Can reduce air-leak noises and hot spots around the cabinet

• Disconnect power; turn off gas supply for gas dryers
• Access the duct connection (front panel/top removal varies by model)
• Remove the old gasket and clean mating surfaces thoroughly
• Install the new gasket; if your model uses adhesive, apply a thin, even coat of high-temp adhesive per product directions before reassembly

The Duct Trap Housing is an OEM component specifically designed for GE laundry machines. It serves as the housing and base unit for the duct trap or lint trap that collects lint and debris during the drying cycle. The duct trap housing is designed to seamlessly integrate with the dryer vent and ducting system.

Causes of a bad duct trap housing include cracks or warping from heat exposure over time, damage due to impact or mishandling, or worn-out mounting components that secure it in place.

Symptoms of a bad duct trap housing include:

• Excessive lint buildup inside the dryer indicating incomplete lint removal
• Airflow issues such as longer dry times or wet clothes after a full cycle
• Venting problems like drafts or leaks at the vent connection
• Noise or vibration originating from the vent area

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Lower Drum Felt seal is an OEM replacement part for GE dryers. The Lower drum felt seal is responsible for creating a seal between the drum and the front panel of the dryer.

This part fixes the following symptoms:

• Air leaking from the dryer drum
• Reduced dryer efficiency and increased energy costs
• Clothes becoming caught in the gap between the drum and front panel
• Potential damage or snags to clothes or the dryer

Causes of a bad Lower Drum Felt Seal can range from normal wear and tear, which degrades the felt material over time, to excessive load sizes that strain the drum and seal. Additionally, over time, the seal can become compressed or damaged, leading to a less effective seal and the potential for heat loss and inefficiency in the drying process.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Top Bearing Assembly is an OEM part for GE dryers. It provides support and stability for the dryer drum, allowing it to rotate smoothly during the drying cycle. This assembly includes the bearing itself along with the necessary hardware to ensure proper installation and functionality.

Over time, the top bearing assembly can wear out due to the constant friction and load from the rotating drum. Other causes can include exposure to high heat, lack of lubrication, or accumulation of lint and debris, which can lead to the bearing malfunctioning.

Symptoms of a bad top bearing assembly include:

• Squeaking or grinding noises during the drying cycle
• The dryer drum not spinning properly or becoming misaligned
• Increased friction leading to longer drying times
• Visible wear or damage to the bearing or its components

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: 10-watt bulb

The Lamp is an OEM part for GE dryers. This part illuminates the dryer's drum interior, enhancing visibility for loading and unloading garments. It ensures that users can easily see their clothes and any items inside the drum, particularly useful in low-light conditions.

Replacing a non-functional dryer lamp is important for maintaining the functionality and convenience of your GE dryer, ensuring you can effectively manage your laundry.

Symptoms of a malfunctioning dryer lamp include:

• A lack of light inside the drum when the dryer door is opened or during operation
• Flickering or intermittent light indicating a loose connection or nearing the end of the lamp's lifespan
• Complete failure to illuminate, which could stem from a burnt-out bulb or electrical issues within the dryer

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Dryer Bearing Slide (2-Pack) is an OEM replacement part for GE dryers. These slides are installed on the front panel of the dryer and support the drum as it rotates. They help reduce friction and wear, ensuring smooth and quiet operation during drying cycles. This pack includes two bearing slides, which are commonly used together in the dryer assembly.

Over time, bearing slides can wear down due to regular use, heat, and friction. When they become worn or damaged, the drum may no longer rotate smoothly, which can affect the dryer's performance and increase noise levels.

Symptoms of bad dryer bearing slides include:

• A loud squeaking or scraping noise during operation
• Difficulty rotating the drum manually
• Clothes taking longer to dry due to improper drum movement
• Visible wear or thinning on the existing slides

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Bearing Slide Assembly is an OEM component for GE electric clothes dryers. As an integral part of the dryer tumbler system, this assembly includes the bearing slides that allow smooth rotation of the tumbler drum during drying cycles.

Symptoms of faulty bearing slides include:

• Abnormal vibrations or shaking of the dryer cabinet
• Noisy operation that gets louder over time
• Rubbing or grinding sounds coming from inside the machine
• Reduced tumbler movement or inability to manually turn the drum

Causes involve general wear of plastic bearing surfaces from years of drum rotation as well as potential damage or misalignment from excess stress on the slides.

This GE OEM replacement helps maintain balanced tumbler movement. Compatible with Hotpoint, RCA, and some Kenmore dryers using the bearing slide assembly design.

The Felt Top Bearing is an OEM part for GE dryers. It provides a smooth surface for the drum to rotate on, reducing friction and wear on the drum and other components.

Causes of a bad felt top bearing can include prolonged use, exposure to high temperatures, or the accumulation of lint and debris.

Symptoms of a bad felt top bearing include:

• A squeaking or grinding noise during the drying cycle
• Increased friction, causing the drum to turn less smoothly
• Visible wear or damage to the felt material
• Clothes snagging or being damaged inside the dryer

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

*** Note: The original seal is no longer available separately. Order complete duct assembly by model. ***

This plastic flat drive belt transmits motion between components to enable proper operation of the appliance. It replaces a worn or broken belt to restore consistent movement and reduce slipping. What it does

• Transfers rotational force from a motor or gearbox to driven parts to power operation
• Restores normal movement when a belt is cracked, stretched, or broken
• Helps eliminate slipping, uneven operation, or intermittent cycles caused by belt failure
• Used where a molded or flat plastic belt is specified instead of a rubber V-belt

• One replacement plastic flat drive belt as shown

• Install only when the appliance is unplugged or the circuit is powered off to avoid shock or injury
• Inspect pulleys, idlers, and related parts for wear and replace if damaged to prevent premature belt failure

This harness top bearing assembly replaces a worn or damaged top bearing and its attached wiring harness, helping restore smooth drum support and reliable electrical connections for the washer's tub. Fits select GE top-load washers. What it does:

• Supports the washer tub at the top to reduce wobble and wear on the drum
• Houses the bearing surface for the tub to rotate smoothly
• Includes the attached wiring harness to maintain connections for sensors or components mounted at the top
• Commonly used when customers notice excessive vibration, noise, or intermittent electrical issues near the top of the washer

• One harness top bearing assembly (bearing with attached wiring harness) as shown

• Service requires access to the washer cabinet and top/tub assembly—disconnect power and water before starting
• Inspect surrounding suspension and seals; replace any damaged fasteners or clips during reassembly
• Handle bearings and electrical connectors carefully to avoid contamination or pin damage

This felt strip lines the lint filter opening. It helps seal the lint screen to reduce lint bypass and air leaks, supporting proper airflow and consistent drying performance. What it does:

• Creates a soft, protective seal around the lint filter opening
• Helps direct airflow through the lint screen to capture lint effectively
• Reduces lint bypass into the exhaust path or cabinet
• Common symptoms of a worn or missing felt: longer dry times, lint beyond the filter, visible gaps, or a loose-fitting lint screen

• 1 filter felt strip

• Disconnect power; turn off gas supply to gas dryers before servicing
• Remove the lint filter and access the filter grille/housing as your model requires
• Remove old felt and residue; position the new felt and secure per your model's design (some use adhesive)
• Reassemble and verify the lint filter seats flush without gaps

The Door Strike is an OEM part for GE dryers. It ensures the dryer door securely latches when closed, allowing the dryer to operate properly. The door strike works with the door catch or latch mechanism, creating a tight seal to prevent heat and noise from escaping during the drying cycle.

A bad door strike can lead to issues with the door not closing or staying closed, resulting in poor drying performance and potential safety hazards. Causes of a bad door strike can include wear and tear over time, damage due to accidental impact or mishandling, or a faulty latch assembly.

Symptoms of a bad door strike include:

• Difficulty in closing or latching the dryer door
• Door opening during operation
• Visible signs of damage or wear on the door strike or latch assembly

Replace your worn-out or damaged door strike with this genuine OEM GE part to ensure a secure and reliable closure of your dryer door.

This GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This strike plate mounts at the door opening and works with the door latch/strike to keep the appliance door securely closed during operation. Replacing a worn plate helps restore positive latching and reliable cycle start/stop via the door switch.

• Provides the catch surface for the door latch/strike to engage
• Helps keep the door closed and properly aligned
• Enables the door switch to engage so the cycle can run
• Common symptoms include: door won't stay closed, door pops open, unit won't start unless the door is pressed, visible wear or bending on the plate

• Disconnect power before servicing
• Open the door and remove the screws securing the existing plate
• Align the new plate with the latch/strike and fasten securely with the existing hardware
• Test door closure and latch engagement; adjust alignment if necessary

This Nut-Strip Door Guide secures the door guide/strip to the appliance, helping keep the door aligned and operating smoothly. Replace a worn or missing nut to restore proper fit and prevent the guide from loosening. What it does

• Fastens the door guide/strip to the appliance frame or door
• Keeps the door guide stable to maintain proper door alignment
• Helps prevent the guide or trim strip from shifting or falling off
• Commonly replaced when the guide is loose, missing, or stripped

• Disconnect power to the appliance before beginning any repair.
• Use appropriate hand tools (screwdriver/socket) and avoid over-tightening to prevent damage.
• Inspect the door guide/strip and surrounding fasteners; replace any damaged parts for proper fit.

This metal mounting plate supports the dryer door strike/catch interface. It provides a solid anchor point so the door latches securely, helping the dryer start and run only when the door is properly closed.

• Reinforces the latch area to keep the door securely closed
• May help when the door won't stay shut or the dryer won't start unless the door is held closed
• Useful if the existing plate is bent, loose, or missing
• Helps prevent vibration-related door pops during a cycle

• Unplug the dryer before servicing
• Open the door and remove fasteners securing the old plate; retain hardware if reusable
• Position the new plate and tighten screws evenly—do not overtighten
• Test door closure and latch engagement before restoring power

This door guide aligns and supports the dryer door as it closes so the strike engages the catch cleanly. Replacing a damaged or missing guide restores smooth, secure latching and reduces gaps that can affect drying performance.

• Guides the door into position for proper latch engagement
• Helps maintain door alignment to prevent gaps, rubbing, or rattling
• Addresses issues like difficulty closing, door popping open, or misalignment
• Direct replacement for a worn, cracked, or missing guide

• Disconnect power to the dryer before servicing
• Open the door and remove the screws or clips securing the existing guide
• Position the new guide and fasten with the original hardware
• Test door operation to ensure smooth latching and proper alignment

This SCR 8-18 AB 1/2 is a replacement silicon controlled rectifier that restores proper power control to the appliance's control circuitry, helping the unit switch and regulate current reliably. What it does:

• Controls current flow in the appliance's power/control circuit for timed or regulated output
• Replaces a failed or intermittent SCR to stop erratic cycling, no-power, or control malfunctions
• Commonly used where electronic switching or phase control is required
• Helps restore stable operation when heating or motor circuits fail to receive proper control signals

• One SCR 8-18 AB 1/2 replacement component

• Disconnect power to the appliance before inspecting or replacing electrical components
• Observe ESD precautions and handle the SCR by its body; avoid touching leads
• Verify wiring and mounting orientation match the original part before final assembly

This steam kit is the OEM steam generator assembly that supplies steam for steam-refresh and wrinkle-care cycles. It restores the appliance's ability to produce steam for improved fabric care and odor removal. What it does

• Heats and releases water as steam into the drum during steam cycles to help relax wrinkles and freshen clothes.
• Addresses weak or no-steam symptoms when the dryer runs steam cycles but garments remain untreated.
• Works with the appliance's control system to deliver steam only during designated cycle phases.
• Helps reduce the need for ironing by loosening fabric fibers during the cycle.

• One steam generator assembly (steam kit) as shown.

• Disconnect power before starting any repair to avoid shock or flooding.
• Suitable for technicians or experienced DIYers; follow the appliance service manual for disassembly and routing of water/steam lines.
• Inspect and replace any brittle or cracked tubing and seals to prevent leaks; test for proper steam delivery after installation.
• Do not operate the dryer with missing or damaged panels; ensure all connectors are secure.
