Parts for Kenmore 867.741971 (867741971, 867 741971): Functional Replacement Parts

The Timer Knob is an OEM part for Whirlpool washing machines. It enables users to select and adjust the various wash cycles and settings, ensuring proper control over the washer’s functions.

Causes of a bad timer knob can include wear and tear from regular use, cracking or breaking from frequent handling, or damage due to accidental impacts.

Symptoms of a bad timer knob include:

• Difficulty turning the knob or selecting cycles
• The knob feeling loose or not staying in place
• The washer not starting or cycling properly
• The knob appearing cracked or damaged

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This oil burner primary control is the safety device that senses ignition and allows the burner to run only when combustion is confirmed, helping prevent fuel flow without a stable flame. It replaces a failed primary control to restore normal burner operation. What it does:

• Acts as the main flame-sensing and safety interlock for oil burners to prevent unsafe operation
• Detects flame presence and permits the burner motor and fuel valve to stay energized
• Commonly used when the burner cycles to lockout, won't stay lit, or has intermittent ignition
• Helps stop continuous fuel flow during a no-flame condition, reducing fire/flood risk

• One oil burner primary control

• High-voltage and fuel hazards — disconnect power and follow fuel shutoff procedures before servicing
• Replace with the exact control for your burner model; wire per OEM wiring diagram
• After installation, test burner operation and safety interlocks per manufacturer instructions

This fan and limit control regulates furnace blower operation and provides a safety high-limit cutout to help prevent overheating. It replaces a failed control to restore normal blower cycling and overheat protection. What it does:

• Senses heat and energizes the blower on warm-up, then shuts the blower off as the heat exchanger cools
• Opens the circuit at a high temperature to stop the burner if the furnace overheats
• Commonly used when the blower won't turn on, runs continuously, or the furnace overheats
• Works as the temperature-activated switching and safety control in forced-air furnaces

• One fan and limit control

• For experienced DIYers only; disconnect power before servicing
• Follow OEM instructions and local codes; replace with the exact part number when required
