Jack H Meadville , MS May 04, 2020 Appliance: General Electric Electric Wall Oven JK5500SF3SS GE double oven f97 code. The first attempt was to replace the sensor board on the lower cooling fan motor. That didn’t fix the problem. Next, I replaced the lower cooling fan. The oven is working correctly for now. Time will tell. The repair is fairly simple. 1. Pulled oven out of wall onto a platform that I built to be the same height as the bottom of the oven. 2. Took off the bottom back cover as well as the middle cover. I also had to take off a couple of pieces on the left side where the fan is. 3. There are about three or four screws that hold the fan in place. 4. Unplug the sensor connector from the fan. The hardest part was figuring out how the main harness wire for the fan is unplugged. This can be figured out by looking at the plug on the new fan. 5 plug the two harness wires back in and put everything back together. Overall the repair was relatively easy and only took about 30 min. Start to finish. I compared how well the old fan spun to the new fan before I put the new one in. The new fan spun a little easier/better than the old one. I just hope this fixes the problem for good. I’ve read in various forums where pepper replace these fans and the fix lasted only a few months. Read More... 17 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers
George P Driftwood , TX June 25, 2021 Appliance: Model JT5500SP3SS Error code F96 on GE oven jt5500sp3ss To replace the cooling fan which is located on the upper back left of the oven, it required removing the oven and 3 metal panels. To remove the oven the best way was to remove the oven doors first which will reduce the weight significantly. Once I did this it was much easier to left the oven by myself and move on a self made stand. After the removal of the metal panels there were 4 screws to remove the metal plate holding the fan to oven, 2 electrical plugs, and then another 4 screws to remove the fan from the metal plate. After a little cleaning to remove some grease and replacing the fan (also replaced the Hall Effect module but I don't think this was bad), it was easy to put back into the oven reversing the process. Also please remember to remove power during this process. Read More... 7 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Screwdrivers
Jack L Lamoille , NV November 24, 2020 Error code came on indicated fan blower system failure only 2 parts were in that circuit (1) fan sensor (2) fan blower ordered both and changed them out it appears to be working. Removed oven from cabinet, removed fan assembly and re installed. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Nut Drivers, Screwdrivers
David C Milford , CT February 20, 2022 Appliance: General Electric Electric Wall Oven JK3500DF3WW F97and f96 error codes Ordered new fans and boards. The parts were delivered really fast. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers
Christian F Westminster , MD November 10, 2021 F96 blower not working Replaced blower and onboard sensor. Cleaned a lot of grease from inside housing Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers, Screwdrivers
