Ge WD21X31908 User Interface Control Board (Configured) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X31908 replaces AP7198320, WD21X25727, WD21X26184, WD21X24823.

Description

Restore a responsive control panel with this configured user interface control board. It reads your button selections, drives the display/indicator lights, and communicates with the main control so your dishwasher can start and run the chosen cycle.

• Interprets touch/button inputs and sends commands to the main control
• Powers LEDs and status indicators on the control panel
• Enables Start/Cancel, cycle selection, and lock functions
• Common symptoms: unresponsive controls, no panel lights, intermittent/erratic button response, won't start though power is present

What's included: 1 configured user interface control board Install notes:

• Disconnect power at the breaker before servicing to prevent electrical shock
• Access the board by removing the control console/inner door as directed by your model's service information
• Handle the PCB by the edges and use ESD precautions; move connectors and any mounting hardware over one at a time
• Ensure ribbon/plug connectors are fully seated; test operation before final reassembly

Also called: UI board, user interface PCB, control panel board
