Quincy V Las Vegas , NV July 14, 2015 Broken switches on range 1) Unscrewed the metal pieces behind the switch panel. You'll notice 3 screws. Afterwards, I realized that I just needed to remove the screws to the left and right of the switch box. The box then slides out. If you take out the third that connects the box to the wire cover, just remember to screw that back in before you replace the box. 2) To make sure I didn't place the wiring in the wrong place, I basically took the wiring out one by one and placing it into the new switch. 3) Place the new switches in the holes. 4) Place the new switch panel over the switches. 5) Tighten the hex nut over the new switches. 6) Place the new knobs. 7) Put the back cover back in place and screw in the 2 screws on the left and right side. Read More... 32 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Wrench Set
Jose G Covington , GA September 27, 2015 Appliance: General Electric Electric Range JV347H1WW Replace light switch and fan switch Turn off power off at main circuit remove nobs remove hex nuts remove the cover exposing the switches remove the wires (one at a time by inserting a small screwdriver in the wire slot of the old switch . MAKE SURE THE POWER IS OFF) , compare the number on the back of the old switch to the new switch when installing the wires Read More... 15 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Pliers, Screwdrivers
James G Mathis , TX January 20, 2024 Appliance: General Electric Range Hood JV347H2WW The fan switch broke where the nut held it to the appliance. It was so easy I did it myself. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Pliers, Screwdrivers
Milton B San Antonio , TX March 26, 2022 Fan and light switches. Ordered new ones and replaced them. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Adjustable Wrench, Screwdrivers
Gary P Paso Robles , CA February 09, 2019 The light switch I bought a new light switch and hex nut. Only to figure it came with one description does not tell you that one is included. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Pliers
