Ge WE49X23896 Dryer Timer And Wiring Harness Kit OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dryer Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WE49X23896 replaces AP6024651, WE4M285, 4467199, PS11736665, WE26X20268.

Description

• Regulates cycle timing and advances the dial through settings
• Directs power to motor and heater circuits at the proper points in the cycle
• Updated harness mates with the revised timer terminals/connectors
• Typical symptoms include: timer not advancing, cycles running too long/short, won't start, or won't shut off

• Disconnect power before servicing; turn off gas supply for gas dryers
• Note wire locations; move wires one at a time; install the adapter harness if your original connector differs
• Mount timer securely; route and secure wiring away from sharp edges, heat, and moving parts
• Run a timed dry test to ensure the timer advances and the dryer shuts off properly
