Jason M Clermont , FL August 14, 2016 Dead range due to lightning stike The entire control board was replaced. It was quick and easy! The entire repair took a total of 10 minutes, including testing. Be sure to order the new overlay, its permanently stuck to the face of the board. Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
Thomas T Berwyn , IL August 18, 2021 Appliance: General Electric Gas Range JGB400SEP4SS The buttons on the touchpad were out/broken. This was a really easy fix, remove the back upper panel with 4 small nuts, pull 3 wiring harnesses from the original part, remove 4 small sheet metal screws, remove the part, and reverse the process to reinstall. My range is a GE 5 burner with touch pad controls. Be aware you need both WB27K10355 control board and WB27K10264 overlay. The actual replacement took 15 minutes, but an hour to clean the gunk off the hidden surfaces, YUCK. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
Eugene B West Hempstead , NY April 26, 2022 The control board and overlay were cracked and damaged. I replaced both control panel and overlay. Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers, Pliers, Screwdrivers
Nathan S Oakland , CA September 18, 2026 Appliance: General Electric General Electric JGB281DER5BB Control board and touch pad was partially melted Easily removed back housing with a socket wrench, then removed the control panel by unscrewing 4 phillips head screws. I applied the touch pad to the control panel. I then disconnected the cables from the damaged control panel and connected them one by one to the new unit. Then I seated the new control panel, screwed it back in and replaced the back housing. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Socket Set
Eddie S Las Vegas , NV October 03, 2026 No error code but cracked overlay Replaced it. Worked like a charm. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
