Ge WE4M284 Timer (Mechanical Dryer Control) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dryer Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WE4M284 replaces AP3189811, 947935, AH267987, EA267987, PS267987, WE04M0284.

Description

This mechanical dryer timer controls cycle selection and advances internal switches to run heating and motor circuits, letting you choose timed drying cycles and automatic transitions. Replaces a worn or non-advancing timer to restore cycle control. What it does:

• Selects and advances dryer cycles by rotating internal cams and switching circuits
• Starts and stops motor and heating circuits according to the chosen cycle
• Resolves symptoms like a timer that won't turn, dryer not advancing through cycles, or inability to select timed cycles
• Works as the user-facing control for timed and some automatic drying functions

What's included:

• One mechanical dryer timer

Install notes:

• Disconnect power (and shut off gas supply on gas dryers) before beginning any work
• Remove the control console or access panel to reach the timer; note knob/shaft alignment for reassembly
• Handle the timer and wiring harness gently; reconnect wires to the original terminals and secure the timer before testing
• After reinstalling, restore power and run a short cycle to confirm proper function
