Parts for Mastercraft 31AE663H515 / 1998: General Assembly 31Ae663 Parts

Parts for Mastercraft 31AE663H515 / 1998: General Assembly 31Ae663 Parts

Location on Diagram
Part Description
Price & Availability
3
Product photo
By: Mtd
Part Number: 918-0417B

Auger won't turn or makes grinding noise? This 30-inch auger gearbox assembly restores snow throwing power. Moderate DIY repair with basic tools.

More
$473.30

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
4
By: Mtd
Part Number: 684-0055C

Replace the auger housing assembly on your snow blower. This structural component encloses the auger system and may need replacement if cracked or damaged.

More
$998.95

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
6
By: Mtd
Part Number: 684-04186-0637

Right-hand auger spiral assembly for 30-inch snow blowers. Replaces worn, damaged, or broken auger spirals that affect snow collection and throwing.

More
$226.95

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
7
By: Mtd
Part Number: 684-04187-0637

Left-hand auger spiral assembly for 30-inch snow throwers. Replaces broken, worn, or damaged auger spirals that collect and move snow into the chute.

More
$200.95

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
8
By: Mtd
Part Number: 705-5226
$10.74

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
9
Product photo
By: Mtd
Part Number: 710-0167

This carriage bolt is a self-locking bolt designed to be used in an unthreaded square or round hole. These bolts are used in outdoor lawn and garden equipment due to their ability to handle heavy weight loads.Carriage bolts are often used to join lawnmower handles to the base of the mower. Over time, the vibration of the lawnmower may cause the bolt to become loose. During routine maintenance, if the bolt is loose, use a wrench to tighten the nut holding the bolt in place. If the bolt is missing, this carriage bolt replacement can be installed. Push the bolt through the hole; if the fit is snug, it may need to be lightly tapped. Once the bolt is through the other side, thread a nut on the bolt. Tighten the nut with a wrench.This is a genuine OEM part sourced directly from the manufacturer. It is sold as an individual unit and does not come with the nut. This carriage bolt is designed for lawnmowers, snowblowers, and other outdoor lawn and garden equipment manufactured by Bolens, Craftsman, Cub Cadet, Huskey, Troy-Bilt, Turf Pro, MTD, Ryobi, and Mastercut.

More
$2.95

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
11
Product photo
By: Mtd
Part Number: 710-0167

This carriage bolt is a self-locking bolt designed to be used in an unthreaded square or round hole. These bolts are used in outdoor lawn and garden equipment due to their ability to handle heavy weight loads.Carriage bolts are often used to join lawnmower handles to the base of the mower. Over time, the vibration of the lawnmower may cause the bolt to become loose. During routine maintenance, if the bolt is loose, use a wrench to tighten the nut holding the bolt in place. If the bolt is missing, this carriage bolt replacement can be installed. Push the bolt through the hole; if the fit is snug, it may need to be lightly tapped. Once the bolt is through the other side, thread a nut on the bolt. Tighten the nut with a wrench.This is a genuine OEM part sourced directly from the manufacturer. It is sold as an individual unit and does not come with the nut. This carriage bolt is designed for lawnmowers, snowblowers, and other outdoor lawn and garden equipment manufactured by Bolens, Craftsman, Cub Cadet, Huskey, Troy-Bilt, Turf Pro, MTD, Ryobi, and Mastercut.

More
$2.95

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
13
Product photo
5.0 (1)
By: Mtd
Part Number: 710-0451

A carriage bolt is a type of fastener. It features a smooth rounded head and a square domed top. It has threading, which leads to up to the square shoulder. The purpose of its square is to prevent the bolt from spinning. Once the carriage bolt is inserted through the hole, using a nut and washer can provide additional security. Carriage bolts can corrode and loosen over time. Since it doesn't have a slotted head, a socket wrench is needed when replacing. This bolt carriage replacement is compatible with wood chippers, tillers, string trimmers, lawnmowers, and edgers. It is a genuine MTD product that measures 5/16x.075. It has a smooth rounded head and square shoulder underneath it. This carriage bolt is sold individually.

More
$5.95

IN STOCK
Ships Today Guaranteed
Add to Cart
16
Product photo
By: Mtd
Part Number: 710-0890A

Auger won't turn or broke after hitting debris? This shear bolt connects your snow blower's auger to the shaft. Quick 10-minute fix for most models.

More
$4.02

IN STOCK
Ships Today Guaranteed
Add to Cart
29
Product photo
By: Mtd
Part Number: 736-0188

Flat washer for lawn mowers and tractors. Spreads load from bolts and screws to prevent damage. Replace if worn, cracked, or missing hardware.

More
$5.77

IN STOCK
Ships Today Guaranteed
Add to Cart
30
Product photo
By: Mtd
Part Number: 736-0242

Bell washer adds spacing on shafts in lawn tractors, tillers, mowers, and chipper shredders. Replace if washer is missing, worn, or damaged during maintenance.

More
$4.31

IN STOCK
Ships Today Guaranteed
Add to Cart
36
Product photo
By: Mtd
Part Number: 741-0493C

Flange bushing for snow throwers and lawn equipment. Replace when worn to maintain smooth operation and prevent part damage. Verify fit with your model.

More
$40.34

IN STOCK
Ships Today Guaranteed
Add to Cart
37
Product photo
By: Mtd
Part Number: 756-0178

Flat idler pulley applies tension to your snowblower's belt for proper operation. Replace if noisy, seizing, or causing belt issues. Verify fit by model.

More
$32.59

IN STOCK
Ships Today Guaranteed
Add to Cart
38
Product photo
5.0 (1)
By: Mtd
Part Number: 784-5580-0637

Replacement skid shoe for snow blowers. Mounts to the side of the auger housing to protect surfaces and control clearing height. Replace when worn.

More
$25.75

IN STOCK
Ships Today Guaranteed
Add to Cart
39
Product photo
By: Mtd
Part Number: 790-00119-0637

30-inch shave plate blade for snow throwers. Installs at the auger housing base to protect surfaces. Replace when worn, cracked, or damaged.

More
$40.63

Out Of Stock

Usually ships within 4 - 14 days

Add to Cart
43
Product photo
By: Mtd
Part Number: 712-0798

Replace a lost, stripped, or corroded nut on your lawn mower, tractor, or outdoor power equipment. Secures components for safe operation.

More
$4.95

IN STOCK
Ships Today Guaranteed
Add to Cart
