Parts for Ge AJCM10DCEL2: 01 - Grille & Chassis Parts

This orifice meters gas flow to an oven burner, helping the appliance produce the correct flame for baking or broiling. Replaces a worn or clogged orifice to restore consistent burner performance. What it does:

• Controls the gas jet size to regulate burner flame size and heat output
• Helps correct symptoms like weak or uneven flame, slow oven heat-up, or burner that won't stay lit
• Prevents improper fuel-air mixture caused by a damaged or clogged orifice
• Used where precise gas flow is required for safe, efficient oven operation

• One orifice

• Shut off gas supply and unplug the appliance before servicing
• Use appropriate wrenches and avoid over-tightening to prevent damage
• Confirm correct orifice type for your fuel (natural gas vs. LP) before installation

This swing louver directs and balances airflow inside the refrigerator to help maintain even temperatures in the fresh-food compartment. It replaces a damaged or broken louver to restore adjustable airflow and proper venting. What it does

• Directs cooled air from the evaporator/fan into the fresh-food area
• Allows adjustable swing motion to spread air evenly across shelves
• Common fix for broken, cracked, or stuck louvers that limit airflow
• Helps reduce localized warm or cold spots caused by blocked vents

• One swing louver assembly

• Disconnect power to the appliance before beginning work
• Remove shelves or drawers as needed for access; handle plastic parts carefully
• Most installations snap into or slide onto the vent housing—do not force; verify alignment of tabs
• If clips are broken, replace clips or adjacent housing as needed for secure fit

This nut with attached washer is a small securing fastener used to clamp appliance parts and prevent loosening. It provides a low-profile, integrated washer bearing surface for a reliable hold. What it does:

• Secures panels, brackets, or components to prevent movement and rattling
• Maintains clamping force where an integrated washer is needed
• Helps keep electrical and mechanical connections stable
• Common symptom: loose or vibrating parts, squeaks, or components that shift during use

• One nut with attached washer

• Disconnect power and water before servicing
• Use the correct socket or wrench to avoid rounding the nut
• Tighten to snug fit — avoid overtightening which can strip threads or damage parts
• If replacing a rusted or damaged fastener, inspect mating threads and replace as needed

This flat washer provides a secure, even load distribution for a fastener on the appliance, helping maintain proper assembly and reduce loosening or wear. Use it to replace a damaged or missing washer during repairs. What it does:

• Sits under a nut or bolt to spread load and protect the appliance surface
• Helps prevent fasteners from loosening due to vibration
• Restores proper spacing and alignment for connected parts
• Commonly replaced when you see corrosion, cracking, or a loose connection

• One flat washer

• Disconnect power and turn off water supply before starting any repair
• Tighten fasteners to a snug fit—avoid over-tightening which can crush the washer
• If adjacent parts show damage or corrosion, inspect and replace as needed

Fix weak airflow or no cooling in your room air conditioner. This centrifugal fan circulates air through the unit. Common repair for most models.

Replacement washer sleeve for room air conditioners. Installs on mounting hardware to provide spacing and support. Needed when original is missing, cracked, or worn.

Air conditioner not cooling or making noise? This fan motor circulates air and keeps your room cool. Moderate DIY repair in 1-2 hours with basic tools.

Air conditioner not cooling or making unusual noise? This fan motor powers airflow in your room AC unit. Moderate DIY repair with basic tools.

Fix weak airflow or no cooling in your room air conditioner with a new axial flow fan. This part circulates air across the evaporator coils. DIY-friendly.

This spring washer provides resilient tension to help keep screws and bolts from loosening on appliance assemblies. It's a simple replacement part that restores proper fastener tension and helps maintain secure connections. What it does:

• Applies spring force around a fastener to resist vibration-related loosening
• Commonly used on panels, brackets, and components that see movement or vibration
• Can reduce rattling and intermittent connection issues caused by loose hardware
• Works with 6 mm-diameter fasteners where a small lock-style washer is required

• Disconnect power and unplug the appliance before servicing
• Use the correct 6 mm fastener and proper orientation when reinstalling
• Tighten hardware to the OEM's recommended torque if available; avoid overtightening
• If other fasteners or parts are damaged, replace them to ensure a secure repair

A small mounting nut used to secure components and panels on compatible appliances. Replaces a loose or missing nut to restore stable, safe fastening and reduce rattling or wobble. What it does:

• Secures panels, brackets, or assemblies to the appliance frame
• Prevents fasteners from backing out during normal operation
• Helps stop rattling, vibration noise, and loose-fitting parts
• Restores proper alignment for attached components

• Disconnect power and water before beginning any repair
• Match threads and size before installation; hand-start the nut to avoid cross-threading
• Tighten securely with the correct socket or wrench, but do not overtighten
• If the original fastener was damaged, replace the mating bolt/stud as needed

Replacement front panel for room air conditioner. Installs on the unit exterior. Order when the original panel is cracked, broken, or missing.

This louver holder secures a refrigerator/freezer vent louver, keeping the air grille aligned for proper airflow and a finished appearance. It replaces a broken or missing retainer so the vent stays in place and the louver operates smoothly. What it does

• Holds the vent/louver in the appliance cabinet or grille so it doesn't fall out or rattle
• Restores proper alignment of the vent for unobstructed airflow
• Stops noise caused by a loose or broken louver mount
• Helps maintain the appliance's finished look by securing trim and grille pieces

• One louver holder (single mounting retainer) as shown

• Remove power to the appliance before any service when working near electrical components
• Usually installs by snapping or fastening into the louver/grille area; inspect for broken clips or fasteners
• If screws or clips are corroded or missing, replace them with OEM-specified hardware

This louver link connects and moves the louver/damper assembly to direct air flow. It restores proper louver movement so vents open and close smoothly for consistent airflow or exhaust performance. What it does

• Transfers motion from the actuator/motor to the louver/damper for opening and closing
• Helps restore normal venting when louvers stick, bind, or fail to move
• Prevents uneven airflow caused by a broken or disconnected link
• Works as the mechanical connection in louver/damper assemblies on compatible units

• Disconnect power to the appliance before servicing to avoid shock or injury
• Handle plastic tabs and pivots gently to avoid breakage during removal/installation
• Basic hand tools may be required;

Replacement front panel for room air conditioner. Installs on the unit exterior. Order when the original panel is cracked, broken, or missing.

Weak airflow or poor cooling often means a clogged filter. This air filter traps dust and debris to protect your evaporator and restore efficiency.
