Parts for Whirlpool UXT3030ADB2: 02 - Hood Parts

Color: White

Color: Black

This is a filter latch that secures the refrigerator water/air filter housing so the filter stays seated and the housing seals correctly. Replaces a worn or broken latch to restore proper filter retention. What it does:

• Holds the filter housing cover or cartridge firmly in place to prevent dislodging
• Helps maintain a proper seal to reduce leaks or bypass around the filter
• Stops the filter from falling out when removing or replacing the cartridge
• Resolves symptoms like a loose or broken latch, filter not staying seated, or water bypass near the filter area

• Disconnect power and shut off water supply before servicing the filter area
• Remove the old latch per your model's service instructions; small hand tools may be needed
• Inspect surrounding housing for damage; replace housing if cracked or warped
• Do not force or overtighten; seat the latch so the filter seals correctly

Color: White

This rocker switch replaces a worn or failed control actuator to restore reliable on/off operation for your appliance's control panel. Durable, service-grade part designed to match the original fit and function. What it does:

• Acts as the user control for powering or selecting functions on the appliance control panel
• Restores a firm, responsive on/off or selection action when the original switch is loose, stuck, or non-responsive
• Commonly used when the appliance does not power on, has intermittent control response, or buttons feel soft or unresponsive

• One replacement rocker switch

• Disconnect power (unplug or shut off circuit breaker) before attempting any repair
• Access the switch through the control panel per your model's service instructions; handle wiring and connectors carefully
• Verify switch operation before reassembling the panel

A replacement hood damper assembly that opens and closes the vent opening to help direct exhaust airflow and reduce backdrafts when the range hood or microwave fan is off. Restores proper vent operation and helps control odors and smoke. What it does:

• Opens to allow exhaust air to escape when the hood fan runs
• Closes to block outside air and reduce backdrafts when the fan is off
• Helps improve ventilation performance and reduces kitchen odors and smoke build-up
• Commonly replaced when the damper is stuck, bent, or noisy

• One hood damper assembly

• Disconnect power to the appliance before beginning any repair
• Access typically requires removing the hood or microwave bottom panel; support the unit if needed
• Verify damper orientation and secure mounting fasteners; test operation before reassembly

The Light Cover is an OEM part for Whirlpool range hoods. The light cover protects the internal light bulbs while allowing brightness to illuminate the cooktop below. It helps prevent grease, smoke, and kitchen pollutants from damaging electrical components.

Causes of a bad light cover can include damage from heat and grease in the range hood environment over extended use. Material breakdown from cleaning chemicals is also common.

Symptoms of a bad light cover include:

• Dim or uneven hood lighting that does not adequately illuminate the cooking surface
• Discoloration or stains on the light cover material
• Cracks or breaks that expose light bulbs
• Premature bulb burnout from lack of protection

This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This charcoal filter is used in recirculating range hoods to reduce cooking odors and smoke. Replacing a saturated filter restores ventilation performance and helps keep kitchen air fresher when venting air back into the room. What it does:

• Adsorbs cooking odors and vapors when the hood is set to recirculate indoors
• Helps maintain proper airflow and capture smoke/steam during cooking
• Replace if saturated, damaged, or shedding carbon
• Common signs: lingering odors, reduced airflow, discoloration, or loose carbon granules

• 1 charcoal filter

• Disconnect power to the hood before servicing
• Remove/open the filter cover or grille; release the old filter from its clips or frame
• Insert the new filter with proper orientation; secure it and reinstall the cover
• Charcoal filters are not washable or reusable; replace periodically as needed

This terminal block cover protects the appliance's electrical connection by covering the power terminal area and helping prevent accidental contact. It keeps wiring and terminals shielded for safer operation and service. What it does:

• Covers the main power terminal block to help prevent accidental contact with live terminals
• Shields terminal connections from dust and debris that can affect connections
• Helps keep wiring routed and contained at the appliance rear
• Useful whenever the terminal area is exposed after service or repair

• One terminal block cover

• Disconnect power at the breaker or unplug the appliance before servicing
• Remove the rear access panel or terminal access plate to reach the terminal block
• Align cover over the terminal area and secure per the appliance's mounting points
• Do not attempt electrical repairs while the appliance is powered; replace a damaged cover before restoring power

This replacement power cord provides the electrical connection that supplies your appliance with mains power. It restores safe, reliable power delivery so your appliance can operate normally. What it does:

• Replaces a damaged or missing power cord to restore electrical connection
• Helps address symptoms like no power, intermittent power, or visible cord damage
• Maintains the appliance's grounded connection when matched to the original cord
• Routes power from the wall outlet to the appliance's inlet or terminal block

• One replacement power cord

• Disconnect power at the breaker or unplug the appliance before starting work
• Route the cord and secure strain relief/fasteners per the appliance's service instructions

This hood damper is the backdraft flap in the exhaust outlet. It opens when the blower runs to vent air outside and closes when off to help block outside drafts, odors, and pests from entering.

• Controls airflow from the blower to the duct during ventilation
• Closes when off to reduce backdrafts and outside air intrusion
• Helps maintain effective capture of smoke, steam, and odors
• Typical symptoms: drafts through the vent, flapping/rattling noises, poor venting, or a broken/missing flap

• Disconnect power; if vented, support or disconnect ducting as needed
• Access the exhaust outlet and remove the damaged damper
• Install with arrow/hinge oriented for airflow; the flap moves freely without binding
• Reassemble ductwork, restore power, and test the fan on all speeds

A replacement mounting plate that secures internal components and restores proper alignment in compatible Whirlpool appliances. Helps stop rattling and loose parts so the appliance runs more quietly and reliably. What it does:

• Secures and supports internal assemblies to maintain correct positioning
• Prevents vibration and rattling caused by a damaged or bent plate
• Helps maintain proper clearance so moving parts operate without interference
• Restores stable fit when the original plate is cracked, warped, or corroded

• Disconnect power (unplug or shut off breaker) before starting any repair
• Remove the appropriate access panel or trim to reach the plate; keep track of fasteners
• Use basic hand tools; avoid over-tightening screws to prevent distortion

Keep your vent hood performing at its best. This 3-pack of recirculation filters refreshes the air in non-ducted installations by capturing fine cooking byproducts, helping the hood clear steam and smoke and reduce lingering kitchen odors.

• Filters air when the hood is set up for non-ducted/recirculating operation
• Helps capture fine particles from cooking to reduce haze and odors
• Replace if saturated, warped, damaged, or excessively discolored
• Common symptoms of a spent filter set: lingering odors after cooking, smoke not clearing as well, visible buildup on filters

• Disconnect power to the hood and allow components to cool before servicing
• Access filter area (location and retention method vary by model); note orientation of existing filters
• Release tabs/latches, remove old filters, and seat the new filters securely in the same orientation
• Refer to your model's use & care guide for specific replacement guidance and intervals
