Parts for Dacor EF36IWFSS: Ice Maker 1 Parts

The Water Filter is an OEM part for Whirlpool refrigerators. It is designed to filter and purify the water for your refrigerator, ensuring clean and fresh drinking water and ice.

A bad refrigerator water filter can be caused by regular use and the buildup of contaminants over time. It may also become less effective if not replaced according to the manufacturer's recommended schedule.

Symptoms of a bad refrigerator water filter include:

• A decrease in water flow or water pressure.
• An unpleasant taste or odor in the water.
• The presence of particles or sediment in the water.
• Cloudy or discolored ice cubes.

If you notice any of these signs or if it has been more than six months since your last filter replacement, it's time to replace the refrigerator water filter with this genuine OEM part. This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.


This replacement ice bin stores the ice produced by your refrigerator's icemaker and fits into its designated compartment for easy access. Replace a cracked or warped container to restore reliable ice storage and smooth dispensing.

• Holds harvested ice until use
• Guides cubes toward the dispenser outlet
• Restores proper fit when the original bin is cracked, broken, or warped
• Common symptoms: ice won't dispense or jams; ice spills into the freezer; bin won't seat or latch properly

• Unplug the refrigerator or disconnect power before servicing
• Empty and remove the old bin from the compartment
• Align and slide the new bin into position until fully seated
• Restore power and allow time for new ice to accumulate

This replacement motor restores powered rotation to the assembly it drives, bringing smooth, dependable operation back to your appliance. Replacing a weak, noisy, or seized motor can resolve no-run or intermittent performance of the connected function. What it does

• Converts electrical power into controlled shaft rotation to operate the connected mechanism
• Failure signs can include humming or grinding noises, overheating odor, or the feature not starting
• Excess vibration or heat can indicate worn bearings or windings

• 1 motor

• Disconnect power (and shut off water if applicable) before servicing
• Note wire connections and orientation; transfer any brackets, grommets, or attached parts from the original motor if required by your model
• Ensure the shaft spins freely and clearances are correct before reassembly
• Restore power and test; monitor for abnormal noise or heat on first run

This blower wheel moves air through the appliance's ventilation system so clothes dry evenly and components stay cool. It restores proper airflow to improve drying performance and reduce overheating risk. What it does:

• Spins to circulate air through the drum and exhaust vent for efficient drying
• Replaces a damaged or broken wheel that can cause reduced airflow and long dry times
• Stops abnormal noises from a cracked or out-of-balance impeller
• Helps prevent overheating caused by restricted or insufficient airflow

• Disconnect power (and gas, if applicable) before beginning any repair
• Inspect the mounting shaft, housing, and fasteners; replace any damaged hardware
• Ensure correct wheel orientation and secure fit to avoid vibration or rubbing

A small rubber mounting grommet that cushions and protects components where they pass through or sit against a chassis or housing. Replaces worn or damaged grommets to reduce vibration and keep parts properly positioned. What it does:

• Provides a vibration-dampening cushion for mounted parts or wiring
• Protects wires, hoses, and metal edges from abrasion at pass-throughs
• Helps keep components aligned and secure during operation
• Worn or cracked grommets can cause rattling, rubbing noises, or movement of parts

• One replacement rubber grommet

• Disconnect power before starting any repair
• Access may require removing panels or trim—refer to your model's service manual or diagram
• Inspect surrounding parts and replace any additional worn fasteners or seals as needed
• Use appropriate tools and take care not to damage wiring or components when installing

This gasket for the damper assembly provides a replacement seal that helps keep compartments properly isolated and reduces air leakage. Replacing a worn gasket restores more consistent airflow and supports stable internal temperatures. What it does:

• Seals the damper opening to reduce unwanted air transfer between compartments.
• Helps the damper close and regulate airflow for more consistent temperature control.
• Common symptoms of a failing gasket: temperature swings, frost or moisture buildup, and noisy or improperly closing damper.
• Restoring a proper seal can improve cooling consistency and help avoid overworking the compressor.

• Disconnect power to the appliance before attempting service.
• Remove interior items and any trim panels needed for damper access; use gentle prying to avoid damage.
• Seat the new gasket fully into the damper groove and verify smooth damper movement before replacing panels and contents.

The Auger Motor is an OEM part for Frigidaire refrigerators. This motor powers the auger in the refrigerator's ice maker unit. The auger rotates during ice-making, ejecting ice from the mold and depositing cubes into the storage bin.

Causes of a bad auger motor can include wear and tear over time from continuous use, or damage from unbalanced ice molds or debris buildup.

Symptoms of a bad auger motor include:

• Ice maker not producing ice or producing ice inconsistently
• Ice cubes jammed or frozen together in the storage bin
• Loud buzzing or grinding noises coming from the ice maker area
• Inability to eject ice properly into the storage bin

Replacing this OEM Frigidaire auger motor helps ensure consistent, reliable ice production. This replacement part is compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

Electronic air damper control assembly for the refrigerator. It regulates the flow of cold air from the freezer into the fresh food compartment to keep temperatures consistent, helping prevent warm spots or over-cooling that can freeze items.

• Opens and closes a damper door to meter airflow from the freezer into the refrigerator
• Helps maintain set temperatures and balanced airflow between compartments
• Resolves symptoms such as a warm fresh-food section, items freezing in the refrigerator, temperature swings, weak/no airflow from the diffuser, or clicking/buzzing noises from the damper area

• Disconnect power to the refrigerator before servicing; use gloves to protect from sharp edges
• Remove shelves and the air duct/cover to access the damper; keep fasteners for reuse
• Unplug the wiring connector, release locking tabs, and install the new assembly fully seated and aligned
• Restore power and verify damper operation and airflow before reloading the compartment

This refrigerator dispenser solenoid converts electrical power into a pull on the dispenser linkage so the ice-dispensing mechanism opens and closes correctly. Replacing a weak or stuck solenoid restores consistent dispensing and reduces frost and warm-air leaks at the chute. What it does:

• Actuates the ice dispenser mechanism (e.g., chute door/gate) when the dispenser is engaged
• Helps the chute seal properly when not dispensing
• Resolve issues like no ice dispensing, door not opening/closing, loud buzz/click with no movement, or frost/condensation at the dispenser

• 1 solenoid

• Disconnect power before servicing
• Access the solenoid in the dispenser/freezer-door assembly; remove trim carefully to avoid breaking tabs
• Note wire positions and transfer any linkage or bracket from the original part if reused
• Restore power and test operation before final reassembly

This replacement screw secures specified refrigerator components—such as covers, brackets, and internal panels—so they stay properly mounted. Replace a missing, stripped, or corroded fastener to restore a tight, rattle-free fit and reliable operation.

• Provides the correct fastener for locations identified in your model's parts diagram
• Helps prevent looseness, vibration, and rattling of panels or brackets
• Replace if the head is stripped, threads are worn, or the screw is missing
• Symptoms can include loose parts, gaps, or noises from movement

• Unplug the refrigerator and shut off water if working near the ice maker or dispenser
• Match length and type to the original; follow your model's parts diagram for placement
• Start threads by hand to avoid cross-threading; tighten snugly without over-torquing, especially into plastic
• Keep track of screw positions; do not mix different screw lengths or styles

A replacement solenoid spring that restores proper plunger return and tension for compatible Whirlpool solenoid assemblies. Replaces worn or broken springs to help ensure reliable actuator movement and consistent operation. What it does

• Provides return tension for the solenoid plunger so the actuator snaps back after activation
• Helps restore normal solenoid movement when a worn spring causes sticking or weak response
• Commonly used when the appliance fails to engage, release, or cycle components driven by a solenoid
• Works as a direct-fit spring for the matching solenoid assembly when part is specified

• Disconnect power to the appliance before beginning any repair to avoid shock or injury.
• Remove access panels and the solenoid assembly to access the spring.
• Handle small parts carefully; note placement and orientation of the spring for correct reassembly.
• If other solenoid or actuator components are damaged or corroded, replace the entire assembly for reliable operation.
