Parts for Ge TBX22PCSMRAA: 09 - Ice Maker Parts

This is the installation instruction sheet and reference documentation for a refrigerator. It provides step-by-step guidance on proper setup, leveling, water line connections, and safety warnings. Replace this document if your original was lost or damaged and you need accurate installation details for your refrigerator.

This trim recess assembly replaces the finished plastic trim around the refrigerator dispenser opening to restore appearance and secure dispenser components. It helps maintain a clean, snug fit between the dispenser and door surface. What it does:

• Provides the finished trim piece around the dispenser opening and hides mounting points
• Helps keep the dispenser bezel properly aligned and reduces gaps
• Addresses cracked, dented, or broken trim that affects appearance
• Prevents loose or wobbly dispenser parts caused by a damaged recess trim

• One trim recess assembly

• Disconnect power and shut off the water supply to the refrigerator before starting
• Remove the dispenser bezel/door panel to access the trim
• Handle plastic trim carefully to avoid cracking; use plastic-safe tools or trim tools as needed

Assembly screw kit for refrigerators. Secures handles, shelf tracks, door hinges, and interior panels. Replace missing, stripped, or lost screws.

Seals freezer door to keep cold air in and warm air out. Replace if torn, cracked, or not sealing properly. Verify fit with your model number.

Hardware kit with 12 mounting screws for refrigerator assembly and component installation. Replace missing, stripped, or corroded screws during repairs.

Spring for recess duct. For spring sleeve use WR2X4822.
