Parts for Ge GDF511PGR3BB: Installation Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

Extension drain hose replaces a damaged or missing refrigerator drain extension to restore a secure path for defrost and condensation water. Properly routing drain flow helps prevent leaks, puddles, and water damage under the appliance. What it does:

• Routes defrost and condensation water from the refrigerator drain outlet to the drain system or pan.
• Restores a sealed drain connection to reduce water pooling or dripping at the rear or under the unit.
• Flexible design allows routing through cabinet openings to reach the drain location.
• Common symptoms this part can address: water puddling on the floor, recurring leaks, or slow drain flow causing interior moisture.

• Always unplug the refrigerator and turn off the water supply before servicing.
• Remove the access panel or toe-kick to reach the drain outlet; carefully disconnect the old hose.
• Clear any clogs from the drain inlet (warm water flush) before installing the new hose.
• Attach the hose to the drain outlet and secure with the existing or a replacement clamp; ensure a continuous downward slope to avoid water trapping.

Size: 10-32 GXTT FLP.595 S

This is a machine screw used to secure dishwasher components. The 10-32 thread and 3/8-inch length with an integrated hex washer head provide a firm, vibration-resistant hold to keep parts properly fastened.

• Secures brackets, panels, or internal assemblies in the dishwasher
• Helps prevent looseness, rattling, or misalignment during operation
• Common symptoms of a missing/stripped screw include panel movement, vibration, or loose mounting points

• Disconnect power and shut off water before servicing
• Use the correct nut driver or socket to avoid stripping the head
• Replace any damaged or missing screws in matching locations
• Do not overtighten; snug to manufacturer's torque guidance when available

This dishwasher junction box cover encloses the power-connection compartment at the base of the unit. Replacing a damaged or missing cover helps protect wiring from debris and accidental contact, restoring a safe, secure connection area. What it does:

• Covers and secures the dishwasher's electrical junction box
• Helps shield wire splices from moisture, dust, and accidental contact
• Restores proper fit when the original cover is cracked, broken, or missing
• Useful if the junction box won't stay closed or the cover no longer secures properly

• Includes 1 junction box cover

• Disconnect power at the circuit breaker before servicing
• Remove the lower access/kick panel to reach the junction box
• Remove the old cover and screw, position the new cover, and secure with the existing hardware
• Ensure all wiring and the strain relief are fully inside the box before closing; restore power and test

The Toe Kick Plate is an OEM component compatible with GE dishwashers. It is an exterior part that covers the bottom front portion of the dishwasher, protecting the unit from impact and preserving its aesthetic by continuing the clean lines up front.

Over time, through repeated impact from cabinetry and foot traffic, the plate's material integrity can deteriorate.

Causes of a bad toe kick plate are generally normal wear and tear from use in a busy kitchen environment. Exposure to moisture or cleaning chemicals may also affect its appearance or functionality.

Some signs a replacement is needed are:

• Dents, dings, or cracks in the material
• Loose or improperly fitting attachment to the dishwasher
• Ripped or missing sections of the plate

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore dishwasher models. A new plate upgrades the look of the dishwasher and shields it from future damage.


The Clamp is an OEM replacement part for GE dishwashers. It holds and secures critical components such as tubing or hoses securely in place. Clamps play an important supporting role by fastening tubing and preventing kinking, both of which are essential for proper water flow and circulation within the dishwasher.

Causes of a bad clamp can include cracks, corrosion, or fatigue that causes the clamp to fail in its gripping function over time. Hoses or tubes may also wear down a clamp through constant vibration.

Symptoms of a bad clamp include:

• Leaks from hoses, tubes or connections
• Reduced water pressure or uneven spray patterns
• Moisture or water damage around connections
• Loose hoses that rub or chafe

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Countertop Mounting Bracket is an OEM part for GE dishwashers. It is used to secure the dishwasher to the underside of the countertop, ensuring stability and preventing movement during operation. This bracket is essential for maintaining the dishwasher's position and preventing it from tipping or shifting.

Over time, mounting brackets can become damaged or loose due to repeated vibrations, improper installation, or wear and tear. A compromised bracket may fail to hold the dishwasher securely, leading to potential operational issues and safety hazards.

Symptoms of a bad mounting bracket include:

• The dishwasher wobbling or moving during cycles
• Visible damage or bending of the bracket
• The dishwasher not being level or properly aligned with the countertop
• Increased noise or vibrations during use

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces
