Parts for Ge C2Y486SDL1SS: Large Door Assembly Parts

This small set screw secures components inside your refrigerator. Replacing a missing or stripped set screw restores a tight, reliable hold so attached parts stay aligned and are less likely to loosen or rattle during use.

• Fastens an attached part to its mounting point to prevent movement or slipping
• Helps maintain proper alignment of handles, brackets, or trim pieces
• Reduces wobble, vibration, and rattling noises caused by loose hardware
• Replaces missing, stripped, or corroded set screws

• Unplug the refrigerator and shut off water if working near door/dispenser areas
• Support the part being secured; start the screw by hand to avoid cross-threading
• Tighten with the correct driver for your model; do not overtighten to prevent stripping
• The component is secure and aligned before restoring power

Replacement 8-18 x 5/16 screw secures range panels, brackets, and components. Needed when original fastener is stripped, missing, or damaged.

Glass bracket for gas ranges. Secures and supports glass components on your range. Replace if cracked, broken, or missing to restore proper fit and stability.

Small end cap that fits the end of a range extension rail or rod to prevent over-travel and provide a finished edge. Replace if cracked, missing, or worn.

Replace your range oven door liner assembly if the inner panel is cracked, warped, or damaged. This structural component forms the interior surface of your oven door.

Replacement screw for gas ranges. Secures various components and panels. Needed when original screw is stripped, missing, or damaged during repair work.

Seals the gap between your oven door and body to maintain proper cooking temperature. Replace when worn, torn, or heat escapes. Confirm fit with model number.

Replace cracked, chipped, or broken 27-inch oven door glass. Restores heat-resistant viewing window for monitoring cooking. Direct fit for range door.

This top freezer door insulation panel replaces the worn or damaged foam that helps keep the freezer cold and efficient. It restores thermal protection to reduce temperature fluctuations and help prevent frost buildup. What it does:

• Provides thermal barrier inside the top freezer door to help retain cold air
• Reduces heat transfer that can cause compressor short-cycling and energy loss
• Helps minimize frost and moisture buildup on the door interior
• Restores original door fit and insulating performance when damaged or compressed

• Disconnect power to the appliance before starting any repair
• Removal of the door liner or inner panel is typically required; keep fasteners organized
• Handle insulation gently to avoid tearing or compressing the foam

Replace your gas range's left door hinge if it's cracked, broken, or worn. This structural component secures the oven door in place for smooth operation.

This endcap replaces a damaged or missing door-handle end piece to restore the handle's finished look and protect exposed edges. It fits on the end of the appliance door handle to conceal hardware and improve grip. What it does:

• Covers the exposed end of a door handle for a clean, finished appearance
• Helps protect fingers from sharp edges and hides mounting screws
• Keeps the handle secure by retaining the handle trim in place
• Common symptom: cracked, broken or missing endcap that leaves fasteners exposed

• One endcap (handle) as shown

• Turn off power to affected appliance and work on a cool, empty door before starting
• Removal typically requires loosening the handle set screws or removing trim pieces; keep small fasteners in a safe place
• Align the endcap over the handle end and snap or fasten per the factory method; avoid forcing parts to prevent breakage

Decorative badge assembly that mounts on the front of your range. Displays brand and model information. Replace if cracked, peeling, or missing.

Replaces cracked, cloudy, or discolored inner oven door glass. Installs inside the door assembly to restore clear viewing and proper sealing.

Secures the glass window in your oven door. Replace if the window is loose, rattling, or misaligned. Confirm fit with your model number.

Replacement mounting screw secures panels, brackets, and trim on ranges and cooktops. Install to replace missing, stripped, or rusted fasteners.

This is a 1/4-20 x 3/4 inch hex washer head screw used to fasten appliance components securely. It provides a durable, low-profile fastening point to keep panels and assemblies aligned and stable. What it does:

• Secures panels, brackets, and assemblies to prevent movement and maintain alignment
• Helps stop rattling or vibration caused by loose fasteners
• Restores proper fit where a missing or damaged screw causes gaps or instability
• Works with metal-to-metal fastening points requiring 1/4-20 thread engagement

• Disconnect power to the appliance before starting any repair
• Start threads by hand to avoid cross-threading, then tighten with the appropriate hex driver or socket
• Do not overtighten; snug until secure to avoid stripping threads or damaging parts
