Lg MHW61841105 Drum Spider (Inner Tub Support) OEM Part

Product Details

Genuine Lg part. See all items in Washer Support.

Cross Reference Information

Part Number MHW61841105 replaces AP6237308, 4422580, PS12082087.

Description

This drum spider supports and centers the inner tub in front-load washers. It bolts to the drum and couples to the drive shaft to keep spins smooth and balanced, reducing noise and vibration as the original wears.

• Supports and centers the inner spin basket within the outer tub
• Transfers drive power through the shaft to spin the drum
• Maintains drum alignment to help prevent rubbing and noise
• When worn: loud banging/rumbling on spin, excessive vibration, metallic scraping, unbalance/spin errors, wetter-than-normal loads

What's included: 1 drum spider assembly Install notes:

• Disconnect power and water; move the washer to a stable work area
• Access requires removing panels, the door boot, and separating the tub to lift out the inner basket
• Clean mating surfaces; install and tighten bolts in a crisscross pattern to ensure even seating
• Inspect rear tub bearings and seal while open; reassemble and run a test spin to check for leaks and vibration
