Parts for Lg LRSDS2706D/00: Machine Compartment Parts

This drain tube assembly routes and removes wash water from the tub to the drain system, helping prevent water buildup and allowing normal drain cycles. It replaces worn or damaged drain tubing for reliable water flow. What it does:

• Channels discharged water from the washer tub to the household drain
• Prevents leaks and water pooling caused by cracked, split, or collapsed tubing
• Supports normal draining and pump operation by maintaining a clear path for flow
• Helps reduce the chance of odor or mildew from standing water in the drain line

• Disconnect power and shut off water supply before starting any repair
• Secure with existing or new clamps to prevent kinks and leaks
• Inspect adjoining hoses, fittings, and the pump outlet; replace damaged components as needed
• After installation, run a short drain cycle to check for leaks and proper flow

Connector link between refrigerator door and cabinet. Replace if original is broken, cracked, or worn. Essential for smooth door operation and alignment.

This duct assembly routes airflow inside the appliance to restore proper ventilation and performance. It replaces a damaged, crushed, or disconnected duct to help reduce restricted airflow and related operation issues. What it does:

• Channels air through the appliance's ventilation path to maintain correct airflow
• Helps resolve symptoms caused by restricted or misdirected airflow, such as reduced drying/venting performance or overheating warnings
• Replaces ducts that are cracked, collapsed, or disconnected and may cause unusual noises or airflow loss
• Works as the internal airflow connector between housing components

• One duct assembly

• Disconnect power (and gas if applicable) before beginning any service
• Handle edges carefully; use gloves to avoid cuts from sheet metal
• Secure all clamps/fasteners; check seals and clearances before returning the appliance to service

Fix ice spilling or not dispensing properly with a new ice bucket assembly. Collects and stores ice from your ice maker. Moderate DIY repair.

Removable ice bucket assembly that collects and stores ice from your refrigerator's icemaker. Replace if cracked, warped, damaged, or missing.

Plastic cap that covers the air duct opening in your refrigerator. Replace if cracked, broken, or missing to restore proper airflow channel coverage.

Replaces a damaged or cracked refrigerator drawer tray surface. Restores level storage so food sits flat and slides smoothly without spills or tipping.

Molded plastic drawer tray assembly that holds and guides refrigerator drawers. Replace cracked, warped, or broken trays that no longer support contents.

Replace a cracked or damaged drawer tray in your side-by-side refrigerator. Restores stable storage surface so food items sit securely and drawer fits properly.

Glass shelf assembly for side-by-side refrigerators. Replaces cracked, chipped, or broken shelves to restore storage space and organization.

Replaces a cracked, broken, or missing refrigerator glass shelf. Restores a stable storage surface for food and containers. Direct-fit assembly.

Refrigerator shelf assembly provides storage and organization. Replace if shelf is sagging, bowing, or has broken brackets. Verify fit with your model.

This is the upper cover assembly that sits on top of the freezer drawer compartment in a refrigerator. It acts as a partition or shelf to separate the freezer drawer section from the space above, helping maintain proper airflow and temperature distribution. Replace this cover if it is cracked, broken, or missing, which can lead to frost buildup, uneven cooling, or difficulty organizing items in the freezer section.

This is a glass shelf and cover assembly that sits on top of the freezer drawer compartment in the refrigerator. It acts as a barrier between the freezer drawer and the space above, helping maintain proper temperature separation and organization. Replace this assembly if the glass is cracked, the frame is broken, or if the cover no longer sits securely in position.

This is the cover assembly that sits on top of the crisper drawers in the fresh food compartment of a refrigerator. It acts as a shelf and humidity barrier, helping to maintain proper moisture levels for fruits and vegetables stored in the drawers below. Replace this cover if it is cracked, warped, or no longer sits flush, which can reduce crisper humidity control and make it difficult to organize items in the refrigerator.

This is the cover assembly that sits on top of the lower crisper drawers in the refrigerator compartment. It acts as a shelf and helps regulate humidity and airflow around the crisper bins to keep fruits and vegetables fresh. Replace this cover if it is cracked, broken, or warped, which can affect temperature control in the crisper area.

Seals your refrigerator door to maintain stable temperatures and prevent frost buildup. Replace if torn, warped, or leaking. Confirm fit with your model.

Replaces a cracked, broken, or missing door basket on your side-by-side refrigerator. Mounts to the inner door to hold bottles, jars, and condiments.

Restore a tight seal on your refrigerator door. Replace this gasket when you notice frost buildup, warm spots, or air leaks. Confirm fit with your model.

Mounts inside refrigerator door to hold bottles, jars, and condiments. Replace if cracked, broken, or missing to restore secure storage space.

Refrigerator door basket mounts to the inner door liner to hold bottles, jars, and condiments. Replace your cracked, broken, or missing basket.

The door basket is an OEM replacement part for LG refrigerators. This part is designed to provide storage space on the lower portion of your refrigerator door, allowing you to neatly organize and store various items such as condiments, jars, and bottles. It offers a sturdy and reliable storage solution, ensuring that your items are securely held in place while still being easily accessible.

A bad door shelf bin can occur due to wear and tear, cracks, or breakage. If you notice symptoms such as a loose or wobbly shelf bin, difficulty in keeping items in place, or missing or broken parts, it's time to replace the the worn-out or damaged lower door shelf bin with this genuine OEM part.

Symptoms of a bad door shelf bin include:

• Loose or wobbly shelf bin
• Difficulty in keeping items in place
• Missing or broken parts

This OEM LG part can also be used on Kenmore/Sears appliances.


Secures the top refrigerator door to the cabinet and provides the pivot point for smooth opening. Replace if hinge is cracked, broken, or worn.

The Button Assembly is an OEM component specifically designed for LG side-by-side refrigerators equipped with electronic control interfaces. This integral assembly contains all command buttons governing cycles and settings.

Causes of failure include damaged circuit pathways from failed seals exposing buttons to moisture, cracked assembly housings restricting movement over years, or worn tactile buttons becoming unresponsive to light touch inputs.

Symptoms of a bad button assembly include:

• Stuck or non-functional buttons unable to activate modes
• Unintended commands from loose electrical connections
• Missing buttons resulting in inaccessible settings
• Illuminated labels or backlights malfunctioning

Replace yours today with this genuine OEM LG assembly to maintain premium touchscreen usability and aesthetics. Rigid construction and gold-plated contacts deliver reliable performance. This replacement part restores adjustable freezer drawers and freshness centers for Samsung, GE, and Kenmore refrigerators as well. Factory-grade quality sustains dependability.

Lower door hinge assembly for side-by-side refrigerators. Mounts at the bottom of the door to support weight and allow smooth opening. Replace if cracked or worn.

Refrigerator roller wheel for leveling and mobility. Replaces worn, cracked, or broken rollers that prevent smooth movement or proper leveling.

Rattling or loose parts in your refrigerator? This retaining pin secures moving components and keeps them aligned for smooth, quiet operation.

Refrigerator not cooling or running constantly? The compressor circulates refrigerant to maintain proper temperature. This repair requires expertise.

Vibration-isolating grommet that mounts between the compressor and chassis. Replace if cracked, worn, or missing to restore proper cushioning.

This is a small retainer clip that secures the compressor in place at the base of the refrigerator. It helps prevent the compressor from shifting or vibrating excessively during operation. Replace this clip if your refrigerator produces unusual rattling or vibrating noises from the back, or if the compressor appears loose or has shifted from its mounting position.

This noise damper reduces vibration and rattling sounds from refrigerant lines in your refrigerator. It cushions the copper tubing against the cabinet to prevent metal-on-metal contact that creates annoying noises. Install this damper if your refrigerator makes clicking, rattling, or vibrating sounds, especially when the compressor cycles on and off.

Secures the drier assembly to the refrigerator frame. Replace if the clip is cracked, broken, or missing to restore stability and reduce movement.

If your refrigerator has uneven cooling or fan noise, the fan guide may be damaged. This part channels airflow properly and prevents blade rubbing.

This condenser assembly wire harness routes power and signals to the refrigerator condenser and fan components, restoring proper condenser operation and improving cooling reliability. Replaces a damaged or disconnected condenser wiring assembly. What it does:

• Provides the electrical connection between the condenser, fan motor, and control components.
• Restores power and signal continuity to condenser components when wiring is frayed, burned, or broken.
• Helps eliminate intermittent condenser or fan failures and related cooling issues.
• Matches OEM connector types and routing for correct fit and function when installed.

• Disconnect power to the appliance before attempting any service to avoid shock or injury.
• Verify connectors and routing match the original harness; secure wiring away from moving parts and heat sources.
• Use proper tools and follow OEM service instructions.
• Inspect associated terminals and components for damage and replace as needed to ensure reliable operation.

Fix uneven cooling or warm spots in your refrigerator with a new evaporator fan blade. This part circulates cold air throughout the unit for consistent temps.

Refrigerator making loud noise or not cooling evenly? This fan assembly circulates air to eliminate hot spots and restore consistent temperatures.

Protective fan grill assembly for side-by-side refrigerators. Covers and shields the internal fan. Replace if cracked, broken, or missing parts.

If your refrigerator light stays on or interior won't cool properly, the door switch may have failed. This magnetic switch detects door position.

Fix a stuck or non-working ice/water dispenser with this micro switch. Common cause of dispensers running continuously or not activating. Easy DIY repair.

A direct-current (DC) motor assembly that powers the appliance's rotating components, restoring normal drum/agitator motion and drive control. Replaces a worn or failed motor to stop intermittent rotation and restore reliable operation. What it does:

• Converts electrical power into rotational force to turn the drum/agitator.
• Provides speed control and torque needed during spin and agitation cycles.
• Commonly replaced for symptoms such as no spin, slow or intermittent rotation, unusual humming, or burning-odor during operation.
• Interfaces with the drive harness and mounting bracket to transfer motion to the drive system.

• Disconnect power (unplug or switch off breaker) before starting any repair.
• Handle the motor and electrical connectors carefully to avoid damage; support the motor while removing mounting fasteners.
• Verify connector orientation and secure wiring harness during reassembly; use manufacturer torque guidelines for fasteners if available.

The Fan Motor Assembly is an OEM part for LG refrigerators. It is responsible for circulating air throughout the refrigerator and freezer compartments to maintain consistent temperatures. By ensuring proper airflow, the fan motor helps to keep your food fresh and evenly cooled.

Over time, fan motors can wear out or become damaged due to factors such as dust buildup, electrical issues, or general wear and tear from continuous use. A faulty fan motor can lead to uneven cooling, increased energy consumption, and potential spoilage of food.

Symptoms of a bad fan motor include:

• Unusual noises coming from the refrigerator
• Inconsistent temperatures in the fridge or freezer
• The refrigerator running constantly or cycling on and off frequently
• Frost buildup in the freezer section

This OEM LG part is also compatible with Sears/Kenmore.

The Rear Evaporator Motor Grommet is an OEM part for LG refrigerators. It's designed to secure and cushion the evaporator motor, ensuring it remains in place and operates quietly. This grommet plays a crucial role in minimizing vibrations and noise from the motor, which can otherwise lead to a disruptive refrigerator operation.

Causes of a bad Rear Evaporator Motor Grommet can result from deterioration due to cooling and thawing cycles in the refrigerator. Physical damage during cleaning or servicing may cause a loose motor fit.

Symptoms of a malfunctioning Rear Evaporator Motor Grommet include:

• Unusual noises or vibrations from the back of the refrigerator.
• The evaporator motor shifting out of place, which can affect cooling efficiency.
• Increased wear on the evaporator motor due to lack of proper cushioning and support.

This OEM LG part is also compatible with some Kenmore models.

This is a rubber or elastomer damper that supports and isolates the evaporator fan motor inside the refrigerator. It absorbs vibration from the motor to reduce noise during normal operation. Replace this part if you hear excessive buzzing, rattling, or vibration coming from the freezer section, which often indicates the damper has hardened or deteriorated.

Fix a refrigerator that won't power on with this power cord assembly. Connects your side-by-side refrigerator to the electrical outlet. Simple installation.

If your refrigerator display is dead, shows error codes, or behaves unpredictably, this sub PCB assembly processes inputs and controls specific functions.

Deodorizer cover assembly for side-by-side refrigerators. Secures and protects the air filter deodorizer unit. Replace if cracked, broken, or missing.

Reduces food and musty odors in your refrigerator's fresh food compartment. Replace every 6 months for optimal freshness. Confirm fit with your model.

Fix inaccurate temperature readings or sensor errors with this refrigerator sensor control board. Restores proper sensor communication and feedback.

Removes impurities and contaminants for clean, fresh-tasting water and ice. Replace every 6 months or when water flow decreases. Verify fit with your model.

The Ice Maker Assembly Kit is an OEM part for LG refrigerators. It includes the ice maker along with all related components needed for installation and operation. This assembly works with the freezer to automatically produce ice cubes on demand.

Causes of a bad ice maker assembly include wear and tear over time, failure of electronic functions that control ice production, or buildup and blockages that prevent proper ice ejection.

Symptoms of a bad assembly include:

• Insufficient or inconsistent ice production
• Ice cubes jammed or clumped together
• Strange noises from the ice maker area
• Error codes displayed related to ice functions

This OEM LG part is also compatible with select Sears/Kenmore models.

This assembly includes the ice maker module and auger motor, which together produce ice and dispense it through the door. The ice maker freezes water into cubes while the auger motor rotates to push ice forward into the dispenser chute. Replace this assembly if your refrigerator stops making ice, the dispenser won't release ice, or you hear grinding noises when attempting to dispense.

Duct cap assembly for side-by-side refrigerators. Covers and seals the air duct opening. Replace if cracked, broken, or missing to maintain proper airflow.

Fix weak water flow or leaking dispenser with this refrigerator water tank assembly. Restores proper chilled water storage and delivery to your dispenser.

Replaces cracked or broken tube connector in your refrigerator. Secures and routes tubing to prevent leaks from loose connections. Easy install.

If your ice maker isn't filling or water dispenser has stopped working, this inlet valve assembly controls water flow to restore normal operation.

Fix water dispenser leaks or no ice with this inline water connector tube. Joins refrigerator water lines to restore secure flow. Simple repair.

This is a tube connector fitting used in a refrigerator's water supply line. It joins sections of water tubing to maintain a secure, leak-free connection for the ice maker or water dispenser system. Replace this connector if you notice water dripping or pooling beneath or behind the refrigerator, or if the fitting is cracked or no longer holds a tight seal.

Secures hoses and tubing in your refrigerator to prevent leaks. Replace if worn, cracked, or losing grip. Verify fit with your model number listed.
