Parts for Kenmore 911.4654590 (9114654590, 911 4654590): Main Top Section Parts

This repair kit contains components needed to fix common issues with your oven's electronic control board. It includes replacement parts for display problems, button malfunctions, or control failures. Use this kit when your oven display is blank, buttons don't respond, or temperature controls aren't working properly.

6" element switch

Burner won't stay at set temperature or jumps to high? The infinite switch controls power to heating elements. Easy DIY repair, takes under 30 minutes.

Color: Black

Oven light switch.

Range indicator light shows when your oven is heating or in operation. Replace if the light fails to illuminate or stays on constantly. Verify fit with your model.

Indicator light lens covers and diffuses the panel light on your range or oven. Replace when cracked, discolored, or missing to restore visibility.

6-inch burner won't heat? This surface element coil restores steady heat for boiling and simmering. DIY-friendly replacement takes about 5-15 minutes.

Burner not heating or heating unevenly? This 8-inch plug-in coil element restores consistent heat to your range cooktop. Simple 5-minute replacement.

Chrome drip bowl that sits under your range's 6-inch surface burner. Replaces cracked, warped, or discolored pans. Measures 8 inches across at top rim.

This 8-inch chrome drip pan sits directly beneath a large surface burner on an electric range, catching spills and food drips before they reach the stovetop cavity below. It reflects heat upward toward your cookware, improving cooking efficiency. Replace it when your existing pan is warped, heavily stained, or so corroded that it can no longer be cleaned.

Support rod clip secures internal components in your range. Replace if loose, broken, or causing rattling noises. Verify fit with your model number.

Insulation pad that installs behind the range control panel to reduce heat and dampen sound. Replace if cracked, compressed, or missing for proper protection.

Burner not heating or making poor contact? A damaged terminal block disrupts power to heating elements. DIY-friendly repair, takes about 10 minutes.

Fix loose or wobbly burner connections with this terminal block mounting bracket. Secures the element receptacle so coils plug in firmly and heat properly.

Right-side hinge for range oven doors. Installs on the door frame to support opening and closing. Replace if cracked, bent, or causing door misalignment.

Lower back

Main wire harness for ranges. Connects electrical components throughout the unit. Replace if wires are frayed, damaged, or connections are loose.

ST10-16 X 7/16"

ST10-16 X 7/16"

Replacement mounting screw secures panels, brackets, and components in place. Needed when original fasteners are missing, stripped, or damaged.

Nickel

Package of 12

Black. 8-18 AB HXW 3/8

Speed nut for ovens and ranges. Secures internal components and panels. Replace if stripped, missing, or damaged during appliance maintenance or repair.
