Parts for Electrolux EW36EC55GS1: 05 - Main Top Parts

This oven bake element is the heating element that warms the oven cavity for baking and roasting. Replacing a damaged element restores proper oven heating and helps return cooking performance to normal. What it does:

• Heats the oven interior for baking, roasting and browning.
• Replaces elements that are visibly burnt, cracked, broken, or no longer glow when the oven is on.
• Common symptoms it can fix: little or no heat from the oven, uneven cooking, or an element that sparks or shows burn spots.
• Works as the direct heater inside the oven cavity; connects to the oven terminal block.

• Disconnect power at the breaker or unplug the appliance before starting any repair.
• Access typically requires removing the oven interior panels or rear access panel; support the element while disconnecting terminals.
• Handle terminals and sharp sheet metal carefully; use insulated tools and secure terminal connections.

The Triple Radiant Surface Element is an OEM part for Frigidaire ranges and cooktops. This component features three individual electric coils contained within a single mounting unit.

The triple element provides versatile cooking options with three distinct zones that heat up rapidly and evenly. Whether simmering a sauce or boiling water, this element allows home chefs to prepare multiple recipe components simultaneously. Precise thermostat controls maintain selected temperatures accurately.

Causes of bad triple elements can include broken internal wiring from shifting or impact over time, or mineral buildup impeding heat transfer and coverage.

Symptoms of failure include:

• Only one or two coils heating up out of three
• Discoloration, cracking or pitting of the coil surfaces
• Coils that pulse or cycle excessively in lower heat settings

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.


The Surface Element is an OEM part for Frigidaire ranges. The small surface element is responsible for providing direct heat to the cookware placed on the corresponding burner of the electric cooktop or range. This element is typically located underneath the glass surface of the cooktop or range, ensuring efficient and even heat distribution for cooking.

Symptoms of a failing Surface Element include:

• The element not heating up at all
• Heating unevenly or only partially
• Noticeable damage or blistering on the element itself
• The control switch not regulating the temperature properly

Causes of a bad surface element can include a burnt-out coil, a break in the element's continuity, or problems with the connection points such as corrosion or loosening. Regular wear and tear from cooking can also lead to degradation over time.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

The Dual Element is an OEM replacement part for Frigidaire electric ranges. This component is located on the cooktop surface and features two heating coils in one unit, one measuring 6 inches in diameter and the other 9 inches. It allows for precise control of cooking temperatures, accommodating various pot and pan sizes for more efficient cooking.

Causes of a bad dual element can include prolonged use that leads to wear and tear, electrical surges that can damage the heating element, or physical damage due to impact or mishandling. Over time, these issues can result in the element failing to heat properly or not working at all.

Symptoms of a bad dual element include:

• The element not heating up or only partially heating
• Inconsistent or fluctuating temperatures
• Visible damage, such as burns or breaks in the element
• The element not responding to temperature controls
• Sparking or unusual noises when the element is in use

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

Used on the 1200 watt element

This element mounting spring secures a surface cooktop heating element to the range, keeping the element stable and ensuring consistent electrical contact for reliable heating. Replaces a worn or missing spring to restore proper element fit. What it does

• Holds the surface heating element in place under the cooktop or in the drip pan.
• Maintains stable mechanical and electrical contact so the element heats evenly.
• Prevents element wobble, movement, or poor seating that can cause intermittent heating.
• Commonly needed when an element drops, rattles, or fails to make solid contact.

• Disconnect power to the appliance before starting any repair.
• Remove the element and/or drip pan per the range service instructions to access the spring.
• Install the spring in the same orientation as the original; ensure the element seats fully and securely.

Used on the 2500 watt element

This wiring harness routes power and signals between components inside the refrigerator to restore reliable electrical connections. Replaces a damaged connector assembly to help resolve intermittent operation and component failures. What it does:

• Transfers power and control signals between control modules, dispensers, ice maker, and other internal components
• Restores reliable electrical connections when wires are frayed, chafed, or connectors are loose
• Helps stop intermittent operation, unresponsive controls, or devices that work only sporadically
• Prevents shorts and arcing caused by damaged wiring when installed correctly

• Disconnect all power to the appliance before starting work to avoid shock or damage
• Handle connectors and wire terminals carefully to avoid bending pins or pulling wires from terminals
• Route and secure the harness with existing clips/retainers; do not pinch under panels or trim

Specs: 8 - 18 x 0.500

This is a #8 screw, 0.500 inch long, used to secure panels and components in appliances. It provides a correct-fit fastener for repairs where the original #8 x 1/2" screw was required, restoring proper assembly and stability. What it does:

• Fastens trim, panels, brackets and small components where a #8 x 1/2" screw is specified
• Holds parts securely to prevent rattling, gaps or loose panels
• Replaces worn, stripped or missing screws to restore proper fit
• Appropriate for common interior and exterior appliance mounting points

• Use the correct screwdriver (typically Phillips) and avoid over-tightening to prevent strip or damage
• Disconnect power and follow appliance manufacturer safety instructions when accessing internal parts

This is a replacement screw used to secure appliance panels and components. It restores proper fastening so panels, trim, or assemblies stay tight and reduce vibration or rattling. What it does

• Fastens panels, brackets, or trim to the appliance chassis
• Helps stop loose or vibrating panels and trim pieces
• Restores proper alignment where a missing or stripped screw causes gaps or movement
• Use when the original screw is missing, damaged, or corroded

• One replacement screw as shown

• Disconnect power to the appliance before starting any repair
• Use the correct screwdriver or bit to avoid stripping the screw head
• Tighten until snug; avoid over-torquing which can strip threads or crack plastic
• Keep removed screws in a safe place; this screw matches the original before installation
