Parts for Kenmore 790.33079400 (79033079400, 790 33079400): Maintop Parts

This black burner skirt fits around a 5K simmer burner ring to restore proper appearance and support the cooktop surface. Replaces cracked or damaged skirts to keep the burner area sealed and looking finished. What it does:

• Provides the decorative and protective trim around a 5K (5000 BTU) simmer burner
• Helps keep spills and debris from entering the burner cavity
• Restores even contact and alignment for the burner assembly
• Commonly replaced when the skirt is cracked, warped, or missing

• One black burner skirt (5K)

• Turn off and disconnect power and gas supply and allow all surfaces to cool before servicing
• Remove burner caps and grates per your model's service instructions to access the skirt
• Handle carefully to avoid bending or cracking; hand tools usually sufficient

Seals around cooktop burner to prevent spills from entering burner housing and centers burner for even heating. Replace when hardened or cracked.

Replacement gasket that seals around surface burners to prevent spills from entering the cooktop cavity. Replace when hardened, cracked, or torn. Confirm fit with your model number before ordering.

Strain relief retainer secures electrical cables at the cooktop connection point. Replace if cracked, broken, or missing to protect wiring integrity.

This replacement door gasket creates a tight seal around the refrigerator or freezer door to help maintain interior temperature and reduce energy loss. It restores proper door closure for better cooling and frost prevention. What it does:

• Seals the door perimeter to keep cold air in and warm air out
• Helps maintain consistent internal temperatures for food safety
• Reduces frost build-up and compressor runtime due to air leaks
• Restores proper door alignment and closing performance

• Remove old gasket and clean the door mating surface before installing the new gasket
• Start installation at a corner and work around the door to ensure an even fit
• Gasket may be warmed slightly (hot water or hair dryer on low, if needed) to improve flexibility for positioning
• Unplug or disconnect power to the appliance before beginning work

This bracket kit secures your cooktop to the countertop during installation, providing stable mounting support. The brackets prevent movement and ensure proper alignment with the cutout opening. Install these brackets if your cooktop shifts, sits unevenly, or needs to be properly secured to meet safety requirements.

This is an authentic OEM replacement bracket locking screw sourced directly from the manufacturer for use on range tops. The stovetop bracket is attached to the stovetop and the stove body. This locking screw is a fully threaded 2.1-inch screw. If this screw becomes loose or rusted, it should be removed and replaced to ensure the stovetop remains fully seated and in good working condition. If the screw is missing, the stovetop bracket will not be fully functional, and the stovetop could become loose. To start, disconnect the power and gas from the unit before replacing the screw on the bracket. Make certain the stove burners are not hot. Remove the burner grates, burner caps, and control knobs. Lift the range top cover. Locate the mounting bracket on the wall unit. If the screw is in the bracket but has rusted, use a screwdriver to remove the missing screw. Set the nut aside for use on the new screw. Install the new screw and the nut from the last screw. Check the bracket alignment before tightening the screw. Tighten the screw to the nut. Lower the stovetop and reconnect the power and gas. This bracket locking screw is a heavy-duty 2.1-inch silver metal screw. It is designed for use on gas ranges manufactured by Frigidaire, Kenmore, Electrolux, and Crosley.

Specs: 10-32 X 0.375

This 15-ounce grate cleaner removes grease, food residue, and burnt-on stains from your range's cooking grates. The four-pack provides enough cleaner for multiple thorough cleanings to restore your grates to like-new condition.

Replacement #8 x 0.500 inch screw for securing panels, trim, and brackets in appliances. Needed when original fasteners are stripped, lost, or missing.

Includes one foot pad. Four are required for each grate. Order as needed. For kit of 8 grate feet with adhesive, order 5304475129.
