Parts for Dacor ER30GISCHNG: Manifold Parts

This single aluminum service valve is a sealed-system access valve used on compatible refrigeration systems to allow safe service, pressure checks and refrigerant charging. It provides a reliable access point without replacing major components. What it does

• Provides a sealed access point for refrigerant charging, pressure testing and diagnostic service
• Helps isolate the refrigerant line during repairs or evacuation
• Reduces the need to disturb larger sealed-system components when performing service
• Commonly used when addressing pressure/charge-related symptoms or performing routine diagnostics

• One single aluminum service valve

• Follow all refrigerant-handling regulations and use proper recovery equipment
• Depressurize the system and verify zero pressure before removing or installing the valve
• Inspect fittings and gaskets for damage and replace as needed to ensure a proper seal

This LED socket assembly restores the high-intensity indicator lighting used on select cooktops to show an active cooking zone. Replace a failed module to bring back clear, consistent illumination. What it does:

• Provides bright LED illumination for a cooking zone indicator
• Restores visual feedback that a burner/zone is in use
• Replaces a failed or damaged LED socket/module
• Common symptoms: no light, dim or flickering light, intermittent operation, or physical damage

• One LED socket assembly

• Disconnect power at the breaker before servicing
• Allow the appliance to cool and protect the glass surface while working
• Access the module from beneath the cooktop; match connector orientation and mounting position
• Test illumination before final reassembly

This retaining ring secures the LED assembly in place, keeping indicator lights and display components stable for reliable operation. It's a small but important part that helps prevent loose or misaligned LED modules. What it does:

• Holds the LED assembly securely to the control/display area
• Prevents movement or rattling of indicator lights during operation
• Helps maintain proper alignment so LEDs remain visible and functional
• Can address symptoms like loose display trim, vibrating noises, or intermittently obscured LEDs

• Disconnect power before starting any repair to avoid shock or damage
• Handle the LED assembly and connectors gently to avoid breaking LEDs or wiring
• Use basic hand tools; avoid forcing the ring—align and snap into place per OEM guidance

This thermal cut-off switch is a high-temperature safety device that interrupts power if the appliance overheats. Replacing a failed cutout restores proper overheat protection and can help address no-heat or shutdown issues caused by an open safety circuit.

• Monitors temperature at its mounting location and opens the circuit if temperatures exceed a safe limit
• A failed/open cutout can cause no heat, intermittent heating, or the unit shutting off during use
• Helps protect components from damage due to overheating
• Location varies by model; typically mounted to a bracket or surface near a heat source

• Disconnect power at the breaker or unplug the appliance before servicing
• Note wire orientation and transfer leads one at a time to the new switch
• Mount in the original position with firm, flush contact for accurate temperature sensing
• After replacement, inspect airflow/venting and nearby fans/filters to address any underlying overheating causes

This broil burner assembly replaces the oven's upper-heat jet broil burner to restore broil function and reliable high-heat performance. Designed to fit specific Samsung gas ranges, it delivers concentrated heat for broiling and browning. What it does:

• Replaces the upper oven broil burner assembly that provides concentrated high heat for broiling
• Restores even browning and searing when the broil element is worn or damaged
• Commonly used when the broil flame is weak, uneven, or the burner will not light
• Works as the service replacement assembly for jet-style broil systems

• Turn off and disconnect power and gas supply before beginning any service
• Handle components carefully and follow the appliance manufacturer's service instructions
• Installation may require basic hand tools and removal of the oven interior or broil shield
