Parts for Whirlpool VSF303PEKQ2: 03 - Manifold Parts

This is a direct-replacement electric surface burner used on the cooktop to provide a heating element for pots and pans. It restores a single cook zone so you can cook evenly and regain full cooktop function. What it does:

• Replaces a damaged or non-heating cooktop surface burner element
• Conducts electricity to produce heat for cookware on the cooktop
• Commonly used when a burner won't heat, cycles irregularly, or shows visible damage
• Fits into the cooktop receptacle and connects to the surface element terminal block

• One standard electric surface burner element

• Disconnect power to the range at the breaker before servicing to avoid shock
• Remove the cooktop grate/trim and lift the element out of its receptacle to replace
• Inspect terminals and receptacle for damage; replace any damaged connectors

This front venturi assembly directs gas flow from the valve to the burner for consistent ignition and flame distribution. It replaces a worn or damaged venturi to restore proper burner performance and reliable lighting. What it does:

• Channels gas from the burner valve to the burner head for correct air/gas mixing
• Helps ensure consistent ignition and stable flames across the burner
• Commonly replaced when burners are hard to light, sputter, or produce uneven flames
• Fits the front burner position and works with factory burner components

• One front venturi assembly

• Turn off gas supply and unplug the appliance before starting work
• Inspect mating surfaces and burner components; replace any corroded or damaged parts
• Hand-tighten fittings as specified by the manufacturer; do not overtighten

The Spark Module is an OEM replacement part for Whirlpool ranges. This module generates and distributes the electrical current needed to ignite the range burners. Dependable sparking is essential for safe and efficient burner ignition.

Causes of a bad spark module can include cracked circuit boards, worn-out electrodes, or malfunctions in the module's timing mechanism.

Symptoms of a bad spark module include:

• Burners failing to light or taking excessive time to ignite
• Constant tripping of the oven or range thermal fuse
• Visible flames or smells coming from under the burners
• Inability to start or maintain oven/range heating functions

This is a genuine Whirlpool OEM replacement this part is also compatible with Maytag, Jenn-Air, and some Kenmore models.

This factory screw secures appliance components to their mounting points. Replace missing, worn, or stripped hardware to restore a tight fit, proper alignment, and quieter operation across the affected assembly.

• Fastens panels, brackets, covers, or internal parts to the chassis or frame
• Helps maintain alignment and support, reducing rattle, vibration, or looseness
• Replaces missing or damaged screws that have backed out, broken, or stripped
• Restores secure mounting after service when original hardware is lost

• Disconnect power; shut off water or gas supplies before servicing
• Use the correct driver; start threads by hand to avoid cross-threading
• Match length and thread to the original location; do not substitute with longer hardware
• Tighten snugly; do not overtighten into plastic or thin metal

Factory replacement screw that secures appliance components and hardware. Use it to replace a missing, stripped, or corroded fastener to restore a tight, rattle-free fit and help prevent loosening or damage from vibration.

• Fastens brackets, panels, or internal parts at the original mounting points
• Replaces worn or missing hardware to correct loose or misaligned components
• Helps reduce vibration-related noise and movement
• Matches the original thread and length specified for the application

• Disconnect power; shut off water or gas if applicable before servicing
• Compare to the original for thread and length match before installation
• Start threads by hand to avoid cross-threading; tighten snugly—do not overtighten
• Reuse any original spacers/washers if present; replace if damaged

Factory replacement screw that secures appliance components and hardware. Use it to replace a missing, stripped, or corroded fastener to restore a tight, rattle-free fit and help prevent loosening or damage from vibration.

• Fastens brackets, panels, or internal parts at the original mounting points
• Replaces worn or missing hardware to correct loose or misaligned components
• Helps reduce vibration-related noise and movement
• Matches the original thread and length specified for the application

• Disconnect power; shut off water or gas if applicable before servicing
• Compare to the original for thread and length match before installation
• Start threads by hand to avoid cross-threading; tighten snugly—do not overtighten
• Reuse any original spacers/washers if present; replace if damaged

This replacement screw secures appliance panels, brackets, and internal components. Install it when original hardware is missing, stripped, or corroded to restore a solid, factory hold and help stop vibration, rattles, and misalignment.

• Provides secure attachment for covers, brackets, and assemblies
• Replaces missing, damaged, or rusted hardware
• Helps resolve loose panels, buzzing/rattling noises, or shifting parts
• Supports proper alignment and reliable operation when tightened correctly

• Disconnect power; shut off gas/water if applicable before service
• Match thread and length to the original; replace in the same location
• Start threads by hand to avoid cross-threading; tighten snugly—do not overtighten
• If washers, spacers, or threadlocker were present originally, transfer or replace them

The Thermostat Kit is an OEM part for Whirlpool gas ranges. This kit includes the thermostat, which is responsible for regulating the oven temperature during cooking. By ensuring accurate temperature control, it allows for consistent cooking and baking results.

Over time, the thermostat can wear out or become faulty due to regular use, exposure to high temperatures, or electrical issues. When the thermostat malfunctions, it can lead to inaccurate temperature readings and cooking inefficiencies.

Symptoms of a bad gas range thermostat include:

• The oven not reaching the set temperature
• Inconsistent cooking results
• The oven overheating
• The oven not maintaining the desired temperature

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This machine screw is used across appliances to secure brackets, covers, and internal components. Replacing a missing or stripped fastener helps keep parts aligned and tight, reducing vibration and preventing loose or shifting assemblies.

• Provides machine-thread fastening for panels, brackets, and internal parts
• Helps eliminate rattling, vibration, and loose fits
• Restores proper attachment when the original screw is stripped, missing, or corroded
• Used wherever an 8-32 screw is specified in the service manual or parts list

• Disconnect power to the appliance; turn off gas/water if applicable
• Match the screw to the original location to confirm size and thread
• Start threads by hand to avoid cross-threading; use the correct driver
• Tighten snugly—do not overtighten to prevent stripping or cracking

The Oven Igniter is an OEM part for Whirlpool ovens responsible for igniting the gas burner that heats the oven. It works by drawing electrical current through the igniter filament, heating it to a high temperature until it glows and ignites the gas to start the cooking process.

Symptoms of a failing Oven Igniter include:

• Oven not heating up at all
• Igniter glowing without igniting the gas
• Weak flame or delayed ignition
• Increased gas smell

Causes of a bad Oven Igniter can range from normal wear and tear, which reduces the igniter's efficiency over time, to physical damage or a buildup of dirt and grease that can interfere with its operation. A malfunctioning igniter can lead to uneven cooking, wasted gas, and in some cases, safety hazards due to the accumulation of gas without ignition.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.


3/8 to 9/16

This is a replacement screw used to secure panels, trim, or small components on compatible Whirlpool appliances. Installing the correct fastener restores proper fit and helps stop rattles or loose trim. What it does:

• Secures trim, panels, or control components to prevent movement and rattling
• Replaces missing or damaged hardware that can cause gaps or loose parts
• Helps maintain proper alignment of panels and movement-free operation
• Used wherever a factory screw of this size and head style is specified

• Always disconnect power (and water, if applicable) before servicing the appliance
• Use the correct screwdriver or driver bit to avoid stripping the head
• Install by hand until threads engage, then tighten snugly—do not overtighten
• Keep removed hardware organized before final reassembly

This appliance screw secures panels, brackets, and internal components. Replacing a stripped or missing screw keeps parts tight and aligned, reducing vibration and preventing noise for reliable day-to-day operation.

• Secures mounting points for panels, brackets, or assemblies
• Replaces stripped, rusted, or missing hardware to restore a solid attachment
• Helps reduce rattling, vibration, and misalignment from loose fasteners
• Maintains proper fit so components operate as intended

• Disconnect power; turn off water or gas before service
• Match the screw to its original location and replace one at a time
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• Use the correct driver type/size specified for your model

This surface burner spark electrode creates the electrical arc that lights the gas at your cooktop/range burner. Replace a cracked or fouled electrode to restore quick, reliable ignition on the affected burner and reduce repeated clicking.

• Generates the high-voltage spark that ignites surface-burner gas
• Promotes fast, consistent ignition and stable flame startup
• Common symptoms: burner won't light, lights intermittently, or sparks weakly at one burner while others work
• Visual clues: cracked porcelain insulator, bent tip, or heavy buildup on the electrode

• Disconnect power and shut off gas supply before servicing
• Remove grate, cap, and burner head to access the electrode
• Transfer mounting hardware from the old electrode
• Route and reconnect the lead securely; keep it away from heat and sharp edges, then test for proper spark before reassembly

The Surface Burner Ignitor is an OEM part for Whirlpool gas ranges. This part ignites the gas to create a flame on the burner, allowing for efficient cooking.

Causes of a bad ignitor can include wear and tear from regular use, electrical issues, or physical damage to the ignitor element.

Symptoms of a bad surface burner ignitor include:

• The burner not lighting or taking longer to light
• Clicking sounds without ignition
• Weak or inconsistent flame
• The smell of gas without ignition

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

This orifice spud directs gas flow to a range or oven burner for proper ignition and stable flames. Replacing a worn or damaged spud restores consistent burner performance and helps prevent uneven heating or ignition problems. What it does:

• Seats the burner orifice and channels gas to the burner for correct flame shape and heat output
• Helps maintain steady ignition and consistent burner operation
• Commonly replaced when flames are weak, uneven, or fail to light reliably
• Fits into the burner assembly to ensure safe, controlled gas flow

• Turn off the gas supply and unplug the appliance before servicing
• Remove burner parts to access the orifice; keep track of small parts and orientations
• Thread by hand first, then snug with the correct-size wrench—do not overtighten

The Clip is an OEM part for Whirlpool ranges. This part holds the surface igniter in place, ensuring that it remains properly positioned to ignite the gas burner efficiently.

Causes of a bad surface igniter clip can include wear and tear from regular use, damage from high heat exposure, or breakage due to improper handling during maintenance.

Symptoms of a bad surface igniter clip include:

• The igniter not staying in place
• Difficulty in lighting the burner
• The burner not igniting at all
• Visible damage or deformation of the clip

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.
