Parts for Electrolux EI30MH55GBB: 03 - Oven,Cabinet Parts

This control switch regulates heat to a surface burner so the cooktop reaches and holds the selected temperature. Restores responsive burner control and consistent cooking performance. What it does:

• Sends variable power to a surface burner to adjust heat levels as you set the knob
• Commonly replaces a switch that causes a burner to stay cold, not heat, or only work at one setting
• Can fix clicking, intermittent operation, or loss of variable control on the affected element
• Works with the cooktop's control knob and wiring harness to manage element output

• One replacement infinite burner control switch

• Disconnect power to the appliance before beginning any work
• Remove the cooktop or control panel as needed to access the switch; keep track of mounting hardware
• Match wire locations and connector orientation when reattaching harness; take a photo first if helpful

This replacement lamp restores illumination in your appliance's lighted area. Installing a new lamp brings back clear visibility so you can easily see contents and settings during use.

• Provides light when the door opens or the light switch is turned on
• Replaces a bulb that is burned out, dim, or flickering
• Common symptoms: light not working, intermittent operation, or a blackened/broken filament
• Restores interior/work-area visibility for safer, easier use

• Disconnect power to the appliance before servicing
• Allow the lamp and surrounding area to cool completely before handling
• Handle glass with a clean cloth or gloves; avoid touching the glass directly
• Replace only with the same type and rating specified by the manufacturer

This fuse holder secures the appliance fuse and provides a safe connection point for overcurrent protection. It replaces a damaged or worn holder to restore a secure fuse mounting and reliable circuit continuity. What it does:

• Holds and secures the appliance fuse so it stays in proper contact with the circuit
• Provides the connection point that allows a fuse to interrupt power when a fault occurs
• Common replacement when the fuse won't seat, shows burn or corrosion, or causes intermittent power
• Helps restore normal electrical operation when a failed holder prevents the fuse from making contact

• Disconnect power before inspecting or replacing the holder to avoid shock or damage
• Verify the fuse rating and type before reassembly; replace only with the correct fuse
• Inspect wiring and terminals for damage; repair any frayed or burned leads

The Door Switch is an OEM replacement part for Frigidaire wall ovens. It is a component located on the oven door that detects when the door is opened and closed. The door switch works alongside the control board to regulate oven operations based on door position.

Symptoms of a bad door switch can include:

• Oven failing to automatically go into bake or warm modes after door closure
• Interior lights not turning on when the door is opened
• Control buttons/display remaining constantly lit instead of dimming
• Oven not heating or functioning properly in different modes

Causes relate to normal wear over extended use as the door switch mechanism cycles with frequent door openings and closings. Moisture exposure or impacts could also degrade switch performance.

This OEM Frigidaire switch is compatible with Amana, Jenn-Air, KitchenAid, and some Electrolux wall oven models as well.

This switch/fuse kit replaces a worn or failed control switch and associated fuse to restore reliable power control. It provides the exact components needed to address common start and power interruptions. What it does:

• Replaces a faulty control switch to restore on/off or cycle control
• Replaces the protective fuse to stop power loss from a blown fuse
• Helps resolve no-start, intermittent power, or control failures
• Restores proper electrical continuity for safe operation

• Disconnect power to the appliance before starting any work
• Handle electrical components carefully and avoid metal contact with terminals
• Verify correct part orientation and secure all connections per OEM guidance

Replacement motor that powers the appliance's drive system, restoring rotation and normal operation. Fits in the original motor location and helps return the appliance to proper function when the motor fails. What it does

• Turns the drive mechanism so the drum/basket or agitator can rotate.
• Commonly used when the appliance won't start, won't spin, or only hums without turning.
• Replaces a worn or failed motor that causes intermittent operation or no motion.
• Works with the appliance's existing mounting, wiring and pulleys.

• One motor as shown.

• Disconnect power before starting any repair to avoid shock or injury.
• Verify mounting orientation and wiring match the original motor before final installation.
• Use proper tools and fasteners; tighten mounts and pulleys to OEM specs.

This factory wiring diagram sheet provides the appliance's wiring layout and connector/wire-color references so you can identify circuits and trace electrical paths during diagnosis or service. Handy for accurate repairs and reassembly. What it does:

• Shows wire colors, connector IDs and routing to help locate circuits
• Helps troubleshoot symptoms like intermittent power, no power to components, or suspected short/open circuits
• Clarifies component hookups when replacing controls, switches, or harnesses
• Aids correct reassembly by showing original wire routing and connector positions

• This is an informational service sheet; it does not replace safe electrical practices
• Always disconnect power to the appliance before testing or servicing electrical components
• Keep the sheet dry and protected from grease or damage so wiring detail remains legible
• Use the diagram as a reference along with proper tools and manufacturer service instructions

The Door Release Lever is an OEM part for Frigidaire microwaves. It facilitates the smooth opening of the microwave door by engaging the latch mechanism when the door release button is pressed, ensuring convenient access to the microwave cavity.

Causes of a bad door release lever can include regular wear and tear, exposure to heat, or physical damage from forceful operation.

Symptoms of a bad Microwave Door Release Lever include:

• Difficulty opening the microwave door
• The door not latching properly or remaining ajar
• The door release button not functioning correctly
• Unusual resistance or noises when opening the door

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This replacement tension spring restores proper tension and movement for the related door or internal assembly, helping smooth operation and reducing sag or misalignment. It's a direct-fit service part when your original spring is worn or broken. What it does:

• Provides tension or return force for the associated door/assembly to maintain correct alignment
• Helps eliminate sagging, sticking, or uneven closing caused by a weakened spring
• Restores smooth, consistent movement for the mechanism it supports
• Suitable when the original spring is stretched, broken, or has lost its tension

• One replacement spring

• Replacement requires removing the related trim or hinge components
• Use appropriate hand tools and wear safety glasses; springs can release suddenly and cause injury
• Disconnect power and empty affected compartments before working on the appliance when applicable

This latch hook engages the door catch/lock on your appliance to keep the door securely closed. Replacing a worn or broken hook restores proper latching so cycles can start and run reliably. What it does:

• Engages the mating latch/strike to hold the door shut
• Ensures the door switch/lock is satisfied so the appliance can operate
• Helps prevent the door from popping open during use
• Common symptoms: door won't stay closed, must push/slam to start, "door open" errors, intermittent stopping

• 1 latch hook

• Disconnect electrical power before servicing; allow any hot surfaces to cool
• Wear cut-resistant gloves; edges and panels can be sharp
• Transfer and reuse original screws/fasteners if not supplied
• After installation, verify door alignment and latch engagement; inspect the mating strike/lock if the issue persists

This shaft assembly is the rotating control shaft that connects a control knob to the appliance's internal control mechanism, restoring positive knob engagement and reliable control operation. What it does

• Transfers rotational input from the knob to the control or switch, allowing user adjustments.
• Replaces a worn, bent, or broken shaft that causes loose, wobbly, or slipping knobs.
• Helps re-establish proper control contact so settings register when the knob is turned.
• Commonly used when a knob doesn't turn smoothly, feels loose, or fails to change a control setting.

• One shaft assembly.

• Disconnect power (unplug appliance or switch off breaker) before starting any repair.
• Minor disassembly of the control panel or console may be required; keep fasteners and small parts organized.
• Handle the part and surrounding components carefully to avoid damaging switches, wiring, or trim.

This replacement appliance label provides the factory identification and safety information fastened to the appliance so you can read model/serial and safety/warning text clearly. It restores legible markings for servicing and ownership records. What it does

• Shows the appliance identification, model/serial or rating area and factory safety/warning text so technicians and owners can service data.
• Helps ensure required safety and operating instructions remain visible and readable.
• Replaces a torn, faded, or missing label that can make identification and troubleshooting harder.
• Supports accurate parts ordering and service by restoring the original markings.

• One replacement label

• Peel-and-stick replacement; clean and dry the surface thoroughly before applying.
• Align carefully and press from one edge to the other to avoid bubbles; firm pressure ensures adhesion.
• Do not stretch or trim the label unless explicitly specified by the equipment instructions.
• For safety, disconnect power or follow manufacturer safety precautions before working near electrical components.

This damper assembly controls airflow for the exhaust vent, opening with the blower and closing when off to block backdrafts. Replace a cracked, missing, or sticking damper to restore proper venting and reduce noise and drafts.

• Opens during fan operation to let cooking air exit through the duct; closes when off to prevent outside air from entering
• Helps maintain correct airflow to capture steam, smoke, and odors
• Common symptoms: poor venting, rattling/clacking noises, cold air drafts through the unit, visible broken or missing flap
• A stuck or binding damper can cause louder fan noise and weak airflow

• Disconnect power before servicing; remove the vent cover/adapter to access the damper
• Note airflow arrow and hinge orientation; install so the flap swings freely in the exhaust direction
• Reuse existing screws and seals; replace any damaged foil tape or gaskets to prevent leaks
• After installation, run the fan to ensure the damper opens/closes smoothly without rattling

This is a replacement screw used to secure appliance components and panels so assemblies stay stable and aligned. It provides a straightforward fix when a mounting fastener is missing, stripped, or damaged. What it does

• Secures panels, brackets, or trim to prevent movement and vibration
• Stops rattling or loose parts caused by missing or damaged screws
• Restores proper fit and alignment of the affected assembly
• Works wherever the OEM-designated screw of this size and thread is required

• Turn power off or unplug the appliance before working on electrical areas
• Use the proper-size driver to avoid stripping the head
• Start threads by hand, then tighten until snug — do not overtighten
• If the original screw is corroded or the hole is damaged, inspect mating parts for repair before installing

A replacement screw fastener that secures appliance panels and components to restore proper fit and reduce rattling. Use this exact replacement to refasten loose parts and keep assemblies aligned for dependable operation. What it does:

• Secures panels, brackets, and trim to prevent movement and vibration.
• Common replacement when screws are missing, stripped, or damaged.
• Helps stop rattling, loose panels, or parts that shift during use.
• Uses the original attachment point so the component fits and functions as intended.

• Disconnect power or gas and follow appliance safety procedures before servicing.
• Use the correct screwdriver or bit to avoid cam-out and damage.
• Do not overtighten — snug to manufacturer torque to avoid stripping threads or cracking parts.
• Replace with the identical part number for fit and function; replace the mating fastener or insert as needed.

This is a replacement mounting screw used to secure panels, trim, and small components in compatible appliances. Installing the correct screw restores a secure fit and helps stop rattling or loose parts. What it does:

• Secures panels, brackets, trim pieces or small assemblies to the appliance frame
• Prevents parts from shifting, vibrating, or producing rattling noises when in place
• Replaces missing, worn, or stripped fasteners that cause loose doors or misaligned trim
• Works with the original mounting points and thread types used by the manufacturer

• Always disconnect power or unplug the appliance before servicing to avoid electrical hazard.
• Use the correct screwdriver or bit to avoid stripping the head; do not overtighten.
• Keep track of small parts and compare the new screw to the old one before installation.
