Parts for Bosch HBN8451UC/01: Pcb Parts

This is the evaporator fan motor and blade assembly that circulates cold air across the evaporator and throughout the fresh food and freezer compartments for even cooling and proper temperature control.

• Draws air across the evaporator coils and distributes chilled air to all sections
• Helps prevent warm spots, frost build-up, and temperature swings
• Common failure symptoms: unusual fan noise, intermittent or no airflow, rising temperatures, or frost accumulating on the evaporator cover
• Located in the evaporator compartment; runs during cooling cycles

• Disconnect power before servicing; wear cut-resistant gloves
• Access is typically from the rear of the freezer/evaporator cover; remove shelves and panels as needed
• Note wire orientation and mounting before removal; transfer grommets/brackets if applicable
• After installation, verify unobstructed fan spin and restore power to test operation

Oven won't heat after self-clean cycle? A failed temperature limiter (high-limit thermostat) cuts power to protect against overheating. Direct fix.

This Terminal Box is an OEM part for Bosch Built-In Ovens. Integral to the oven's electrical system, this component serves as a secure connection point for various electrical wires within the appliance.

A common issue with a malfunctioning Terminal Box is loose connections or damage to the terminal block due to heat exposure or aging.

Symptoms of a defective Terminal Box may include:

• Inconsistent power supply to the oven
• Non-functional heating elements
• Sparks or electrical arcing within the terminal box area

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

If your oven won't heat, displays errors, or cycles incorrectly, the control module may have failed. This programmed board controls all oven functions.

Fix misaligned oven components with this spacer. Restores proper gap between parts to prevent rubbing and ensure smooth operation. Simple DIY repair.

Mounting bracket for wall ovens. Secures the oven to the cabinet opening. Replace if bent, cracked, or missing to ensure proper oven installation.

Oven overheats or shows E115 error? The temperature limiter (safety thermostat) may have failed. Moderate difficulty repair requiring careful disassembly.

Oven door won't latch or stays locked? This door latch secures your oven door during cooking and prevents accidental openings. Moderate DIY repair.
