Parts for Craftsman 31BH55TH799 / 2012: .Quick Reference Parts

This V-belt is designed for use in snowblowers by several major manufacturers. It is used to rotate the blades in the blower and acts as the primary belt for the device. These belts are made of a rubber material, which means they can sometimes stretch out, break, or wear down. If this occurs, the V-belt needs to be replaced to ensure the snowblower continues to work at its best.The more frequently a snowblower is used, the more likely it is that a replacement V-belt will be needed. In some cases, a V-belt can wear out more quickly than expected due to faults like mechanical failures. When the belt is overly worn, it can cause the snowblower to act sluggishly since the belt can slip off of the pulley. If the belt breaks, the snowblower will no longer be able to operate. When replacing the belt, drain the fuel and remove the spark plug for a safe repair.This V-belt is a genuine OEM replacement part that is sourced directly from the manufacturer. It's made for use with snowblowers by Craftsman, Yard-Man, Cub Cadet, Huskee, Troy-Bilt, MTD, and Yard Machines. It is sold as an individual component.

This light bulb is designed for use with outdoor lawn and garden power equipment such as lawn mowers, snow blowers, and snow throwers. It is compatible with products made by Craftsman, MTD, Columbia, Husky, Yard-Man, Cub Cadet, White Outdoor, and Troy-Bilt.This light bulb attaches to the light socket in a mower or blower and illuminates the area in front of the machine. The purpose of the light bulb is to make the machine operable even when light is sparse. For example, if someone is mowing their lawn at dusk and it gets too dark to see the yard, they'll need a functioning light bulb to finish the job. This is also an important piece for snow blowers because even if it isn't nighttime, a dense snowfall can greatly limit visibility. A light bulb on the front of the machine can make the task less overwhelming when the environment is dark or if visibility is otherwise limited. To replace a broken bulb, unscrew the bad bulb and screw the new one in. No extensive technical knowledge of the machine is required for a simple light bulb replacement.This light bulb is a genuine OEM part sourced directly from the manufacturer, and it is sold individually. It is manufactured by MTD.

This power cord extension is a genuine MTD part, sold individually. This power cord extension can be used as a replacement part for a snowblower. This power cord extension lengthens the reach of the power cord so that the appliance can be used from a greater distance from its direct power source while it is plugged in. The power cord extension might have to be replaced at some point if the cord suffers damage that renders it beyond functionality. This could occur if the cord is frayed, if it gets wet, or if it is punctured, torn, scratched, or eroded to the point that it does not power on the snowblower when properly plugged in. Remember to wear work gloves as a safety precaution while repairing or replacing parts within an outdoor appliance. This is an OEM part sourced directly from the manufacturer. It is sold individually. This power cord extension is compatible with the following outdoor appliance brands: MTD, Toro, Cub Cadet, Ryobi, Tecumseh, Lawn Boy, Huskee, Montgomery Wards, Bolens, Yard Man, Troy-Bilt, and Yard Machines.

This replacement part is a hand-held oil pump, and it is intended for use in different types of lawn equipment. This is a genuine replacement part made by MTD. This oil pump is small and portable and is able to assist the user during oil changes in their lawn mowers. Oil changes are a normal part of maintenance for many lawn mower models and this oil pump will facilitate that.A user might require a new oil pump if the old one is damaged. This part with the lawn mower at purchase, so it may need to be purchased after the fact. It makes changing the oil inside of the engine very easy.This hand-held oil pump is sold individually and is a genuine OEM replacement part sourced directly from the manufacturer. This device can come in handy for those looking to change the oil in their lawn mowers.

This is a small engine spark plug positioned in the engine cylinder head. It supplies the spark that will ignite the air-fuel mixture to enable an engine to produce power. This particular spark plug is designed with superior corrosion resistance and dependable performance. Small but mighty, this component allows for increased conductivity and heat control. If the spark plug is damaged or in poor condition, many problems may arise in equipment, including sudden stop while running, overheating, and excessive gas consumption. Replace the spark plug by disconnecting the spark plug wire first, then use a socket driver or wrench to remove the spark plug. Install the new spark plug by turning it by hand initially to avoid cross-threading. If it doesn't twist anymore, use a deep socket wrench or socket driver to tighten the plug until snug. The spark plug can also be used to tune up outdoor power equipment or improve a small engine. This part is recommended to be replaced once per season. This part works with lawn mowers, snowblowers, tillers, leaf blowers, log splitters, wood chippers, and others with small engines. It is compatible with brands such as Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and MasterCut. This is a genuine OEM part directly from the manufacturer and is sold individually.

The drive clutch cable is a clutch or engagement cable that tightens the drive belt or lifts the spinning friction disc contained within the drive housing. It will cause contact between the driveshaft and turn the wheels. If the wheels refuse to turn, it may be due to a cable that is damaged, loose, or snapped. If tightening the tension fails to yield results, this OEM replacement cable is needed. Replacing a drive clutch cable is fairly easy. Remove the original and use pliers and a socket set to install and tighten the new one. "This is a drive clutch cable designed for use in snowblowers produced by MTD, Craftsman, Cub Cadet, Troy-Bilt, Yard Machines, Huskee, Yard-Man, and others. It ships individually and is made of rubber, wire, and metal.

This is a genuine replacement ignition key that is manufactured by MTD for use in select models of outdoor power equipment. The ignition key is a plastic piece that is inserted into the ignition cylinder to start the machine. Turning the plastic key will signal to the engine to fire. This is a durable plastic piece, but it can become damaged or lost over time, which will render the machine unable to start. Replacing it will be necessary in order to operate the unit. This genuine OEM ignition key is manufactured to exact standards. It can be used in snowblowers and snow throwers from MTD, Yard Machines, Troy-Bilt, Cub Cadet, Yard-Man, and Husky. The durable plastic key is sold as an individual unit and does not require any tools for installation. This is a simple replacement that should only take a couple of minutes. In the event that the old key is damaged or stuck in the ignition, it may take more effort. It is important to disconnect the power supply for safety before performing any repairs, as well as to wear gloves for hand protection.

This impeller is a genuine OEM replacement part sourced directly from the manufacturer for use on snowblowers to move snow that has accumulated and is a safety hazard. The impeller rotates to pull the snow up and out a discharge chute. If snow is not blowing out of the blower, the impeller should be checked to ensure it is rotating. If the impeller is not rotating, it will need to be removed and replaced for the blower to function properly.Remove the spark plug from the machine and drain the gas from the engine. Disconnect the control cables and separate the engine of the blower from the blower itself. Remove the auger to access the impeller. Remove the impeller from the blower and install the new one. Reassemble the snowblower and refill the gas. Put the spark plug back in and fire up the engine to test the new impeller. This impeller is sold as an individual unit. It is designed for use in snowblowers that are manufactured by MTD, Yard Machines, Yard-Man, Troy-Bilt, Husky, and Cub Cadet.

This replacement is a friction wheel assembly that is designed to work with a snow blower. The friction wheel engages the friction disc assembly to assist in the forward and rearward travel movement of the snowblower. If the friction wheel becomes worn or damaged, the snowblower moves slowly or erratically. Prior to the start of this project, ensure all appropriate personal protective equipment is worn. This would include work gloves and eye protection. To replace this part, first disconnect the spark plug wire. Then, remove the frame cover and wheels. Next, remove the hex shaft mounting nut and the friction disc. Clean the shaft and install the new friction disc. Reinstall the wheels and the frame panel. Reconnect the spark plug and test the snowblower. The snowblower is now ready for use.To clean the friction wheel assembly, remove the cover of the snowblower to expose the friction wheel. With all PPE donned, take a cloth with a small amount of gas saturated on it and place it over the friction wheel. Spin the wheels to engage the friction wheel. The gas saturated cloth will work by cleansing the grease off the friction wheel. Once there is no more grease coming off the friction wheel, take a dry cloth and repeat the steps to dry the friction wheel assembly. Replace the frame cover and the snowblower is ready for use. The friction wheel assembly is manufactured and compatible with MTD, Craftsman, Troy-Bilt, Noma, Murray, Ariens, Husqvarna, Snapper and Yard Man snowblowers. This is a genuine OEM part sourced directly from the manufacturer and it is sold individually.

This part is a replacement friction wheel assembly. It is intended to replace a defective or broken friction wheel assembly in snow blowers.The friction wheel works with the friction disc to turn the drive wheel axle. This part is essential to proper equipment functionality but may be damaged with regular equipment usage. Before beginning this repair job, disconnect spark plug. Wear work gloves to protect the hands and check that equipment is powered off and cooled down before beginning. This friction wheel assembly is a genuine MTD OEM part made of durable materials and is sold individually. It is suitable for use with snow blower models that have been manufactured by MTD, Craftsman, Troy-Bilt, and some other brands.

This genuine MTD speed selector cable attaches the speed control lever to the snowblower's ground drive system to regulate and maintain the speed of the snowblower.Though speed selector cables are highly durable, they can be subject to damage as a result of exposure to inclement weather, impact upon collision, and general decline. Signs of a damaged speed selector cable can include malfunctioning regulation of speed, an overheating engine, or black smoke rising from the engine. If any of these symptoms occur, the speed selector cable should be checked and replaced immediately, as the snowblower cannot function properly without it. Remember to always wear gloves when handling, repairing, and operating outdoor equipment. This speed selector cable is compatible with the following brands: MTD, Troy-Bilt, Cub Cadet, Yard Machines, and Craftsman. Part sold individually.

The snowblower auger cable initiates operation of the snowblower’s auger similar to the cable on the handle of a push mower. To start the snowblower, the control handle must be squeezed. This engages the snowblower auger cable to allow the auger to begin turning. When the snowblower auger cable is broken, the snowblower cannot work because the auger will not turn. The length of this snowblower auger cable is 47.48 inches. It is made from high-quality rubber insulation of a metal wire. A pair of pliers and a wrench are needed to complete the repair. If the snowblower still does not work after replacing the snowblower auger cable, check the shear pin as these are prone to breaking and will also prevent the auger from turning. This genuine OEM snowblower auger cable is compatible with snowblowers manufactured by Craftsman, Cub Cadet, Husky, MTD, Troy-Bilt, Yard Machines, and Yard-Man. This part is sold individually. You will need to order any hardware, housing, and the trigger separately if these items also need repair or replacement.

The shear pin’s purpose is to stop the engine when it is broken. If the machinery hits something hard, the shear pin will break. This prevents injuries that could be fatal. If something large or small becomes clogged or jammed in the auger, the shear pin is meant to snap in half, rendering the auger useless. This happens once the auger reaches a certain point in pressure load, which also prevents damage to the rest of your equipment. The auger part of your machinery cannot turn without a shear pin. Since the purpose of the shear pin is to break on impact, it's a good idea to have several of these on hand for quick replacements. There’s nothing like having your equipment break down in the middle of a job. Repair is simple. Just remove the broken shear pin, line up the auger’s holes, and insert your new shear pin. Use the cotter pin to secure your shear pin. This genuine OEM auger shear pin works in conjunction with small engine equipment with augers made by Craftsman, Cub Cadet, MTD, Troy-Built, Yard Machines, and Yard-Man. This part is sold individually. Consider also ordering an MTD Pin-Bow Tie Cotter or retaining clip.

A cotter pin, also known as a hitch pin, is used to secure pins and shafts in place. Meant for snowblowers, riding lawnmowers, and lawn tractors, this bow-tie shaped cotter pin has a double-end design making it easy to pull or push through either side of a pre-drilled hole. This pin snaps into a locked position without tension, keeping it secure during operation. Designed for lawn and garden maintenance equipment, this part ensures secure fastening. If the power equipment is used frequently, cotter pins may have to be replaced regularly so it would be practical to keep extra bow tie cotter pins on hand. It is highly recommended that work gloves be worn during the installation of this part. This part is compatible with Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and MasterCut brands of lawn mower, snowblower, and log splitters. This is a genuine OEM replacement part that is sold individually.
