Parts for Mtd Pro 31AE6GFF795 / 2007: .Quick Reference Parts

Slide shoes, otherwise known as skid shoes, are attached to a snowblower to help protect the concrete it moves over. The slide shoe also helps to protect the underside of the snowblower. They are composed of metal and are attached to the bottom of the machine. With use, the slide shoes may wear down. They can also become defective from accidents while operating the snow throwing machine. When the slide shoes are not working correctly, there can be irreversible damage done to both the snowblower and the concrete. Replacement slide shoes can easily be attached to the bottom of a snowblower. Be sure to allow the machine to cool down completely. It's recommended to set the snowblower on top of a piece of cardboard. Remove the old shoes and install the new ones, tightening all nuts and washers while the skid shoe is flat on the ground.This is a manufacturer supplied OEM MTD snowblower slide shoe. Each shoe is sold separately. The slide shoe is made of high-quality, durable black steel. It is suggested to replace both shoes simultaneously to ensure an even and consistent path for the MTD snowblower.

This power cord extension is a genuine MTD part, sold individually. This power cord extension can be used as a replacement part for a snowblower. This power cord extension lengthens the reach of the power cord so that the appliance can be used from a greater distance from its direct power source while it is plugged in. The power cord extension might have to be replaced at some point if the cord suffers damage that renders it beyond functionality. This could occur if the cord is frayed, if it gets wet, or if it is punctured, torn, scratched, or eroded to the point that it does not power on the snowblower when properly plugged in. Remember to wear work gloves as a safety precaution while repairing or replacing parts within an outdoor appliance. This is an OEM part sourced directly from the manufacturer. It is sold individually. This power cord extension is compatible with the following outdoor appliance brands: MTD, Toro, Cub Cadet, Ryobi, Tecumseh, Lawn Boy, Huskee, Montgomery Wards, Bolens, Yard Man, Troy-Bilt, and Yard Machines.

This impeller is a genuine OEM replacement part sourced directly from the manufacturer for use on snowblowers to move snow that has accumulated and is a safety hazard. The impeller rotates to pull the snow up and out a discharge chute. If snow is not blowing out of the blower, the impeller should be checked to ensure it is rotating. If the impeller is not rotating, it will need to be removed and replaced for the blower to function properly.Remove the spark plug from the machine and drain the gas from the engine. Disconnect the control cables and separate the engine of the blower from the blower itself. Remove the auger to access the impeller. Remove the impeller from the blower and install the new one. Reassemble the snowblower and refill the gas. Put the spark plug back in and fire up the engine to test the new impeller. This impeller is sold as an individual unit. It is designed for use in snowblowers that are manufactured by MTD, Yard Machines, Yard-Man, Troy-Bilt, Husky, and Cub Cadet.

This is a genuine replacement belt designed to work with multiple types of snowblowers. It is sometimes called a wheel drive belt or a V-belt. The belt is installed on pulleys that allow the transfer of motive power from the engine to the wheels and the auger, allowing the snowblower to move forward, as well as break up and throw snow. These belts are made from high-quality rubber, but they will suffer from wear and tear over time. Through normal use, exposure to extreme temperatures, and over time, the rubber can crack, and eventually, the belt will break. If the snowblower's wheels will not turn, it is most likely that the belt needs to be replaced. Replacing the belt is simple, but will require accessing the pulleys. Remove the old belt and then install the new one according to the owner's manual. Note that this is an OEM replacement part and is sold individually. It is designed for Craftsman and MTD snowblowers, as well as models from Ryobi, Huskee, Cub Cadet, Yard Machines, Yard-Man, and Troy-Bilt.

This part is a spark plug that is used on a number of lawn and garden power equipment. A spark plug is used as part of an internal combustion engine. The spark plug delivers the electric current from the ignition system to the engine.A new spark plug may be needed after normal wear and tear over a period of time. The operator of the outdoor power equipment may notice that the engine misfires or it is difficult to start. If this is the case, a new spark plug will be needed. Never perform care and maintenance on outdoor power equipment that is powered on. Remember to wear gloves when operating or performing care and maintenance on any outdoor power equipment.This spark plug is a genuine MTD part. It is sold individually. This particular spark plug is compatible with various outdoor power equipment that are manufactured by MTD, Yard Machines, Troy-Bilt, Bolens, Yard-Man, and Cub Cadet.

This is a replacement shave plate for use with snowblowers. The plate attaches to the bottom of the auger housing on the machine and provides protection for the auger and the housing. If it is broken or not functioning properly, debris could damage these other parts of the snowblower. This would then require a larger repair.The shave plate is made from metal and is durable. However, the nature of the plate is to provide protection, which means it will become dinged and damaged over time. It could become bent if the user hits a large rock or chunk of ice. If there is damage to the snowblower shave plate, the user should be sure to replace it before using the machine again.This snowblower shave plate is compatible with models from Craftsman, MTD, White Outdoor, Ranch King, Yard-Man, and Yard Machines. The plate is sold individually, and it is a genuine OEM replacement part sourced from the manufacturer.

The snowblower auger cable initiates operation of the snowblower’s auger similar to the cable on the handle of a push mower. To start the snowblower, the control handle must be squeezed. This engages the snowblower auger cable to allow the auger to begin turning. When the snowblower auger cable is broken, the snowblower cannot work because the auger will not turn. The length of this snowblower auger cable is 47.48 inches. It is made from high-quality rubber insulation of a metal wire. A pair of pliers and a wrench are needed to complete the repair. If the snowblower still does not work after replacing the snowblower auger cable, check the shear pin as these are prone to breaking and will also prevent the auger from turning. This genuine OEM snowblower auger cable is compatible with snowblowers manufactured by Craftsman, Cub Cadet, Husky, MTD, Troy-Bilt, Yard Machines, and Yard-Man. This part is sold individually. You will need to order any hardware, housing, and the trigger separately if these items also need repair or replacement.

This is a replacement skid shoe for Craftsman snowblowers. Ideally, when one shoe becomes so worn that it needs to be replaced, the other shoe should be replaced as well. Replacement is not difficult and should only require about half an hour. First, take out the key and disconnect the plug wire to prevent the machine from starting during repair. Remove the carriage bolts, nuts, and washers that hold the skid shoes in place. Replace the skid shoes. Ensure that the adjustable skids shoes are elevated enough that the snow blades will not collide with the ground during use. This will prolong the life of the shave plate. This OEM part fits a variety of different snowblowers made by Craftsman, Cub Cadet, Ryobi, Troy-Bilt, Yard Machines, MTD, Huskee, Montgomery Wards, Bolens, Yard-Man. Sold individually. The carriage bolts that hold the shoe in place may also need to be replaced and are sold separately.

The shear pin’s purpose is to stop the engine when it is broken. If the machinery hits something hard, the shear pin will break. This prevents injuries that could be fatal. If something large or small becomes clogged or jammed in the auger, the shear pin is meant to snap in half, rendering the auger useless. This happens once the auger reaches a certain point in pressure load, which also prevents damage to the rest of your equipment. The auger part of your machinery cannot turn without a shear pin. Since the purpose of the shear pin is to break on impact, it's a good idea to have several of these on hand for quick replacements. There’s nothing like having your equipment break down in the middle of a job. Repair is simple. Just remove the broken shear pin, line up the auger’s holes, and insert your new shear pin. Use the cotter pin to secure your shear pin. This genuine OEM auger shear pin works in conjunction with small engine equipment with augers made by Craftsman, Cub Cadet, MTD, Troy-Built, Yard Machines, and Yard-Man. This part is sold individually. Consider also ordering an MTD Pin-Bow Tie Cotter or retaining clip.

A cotter pin, also known as a hitch pin, is used to secure pins and shafts in place. Meant for snowblowers, riding lawnmowers, and lawn tractors, this bow-tie shaped cotter pin has a double-end design making it easy to pull or push through either side of a pre-drilled hole. This pin snaps into a locked position without tension, keeping it secure during operation. Designed for lawn and garden maintenance equipment, this part ensures secure fastening. If the power equipment is used frequently, cotter pins may have to be replaced regularly so it would be practical to keep extra bow tie cotter pins on hand. It is highly recommended that work gloves be worn during the installation of this part. This part is compatible with Craftsman, Cub Cadet, Troy-Bilt, Murray, Yard Machines, MTD, Huskee, Bolens, Yard-Man, and MasterCut brands of lawn mower, snowblower, and log splitters. This is a genuine OEM replacement part that is sold individually.
