Parts for Frigidaire CAHE12ER1: 03 - Recommended Spare Parts

This replacement evaporator fan blade circulates cold air across the freezer and refrigerator compartments to help maintain even temperatures and efficient cooling. Designed to match the OEM shape for proper airflow and fit. What it does:

• Spins on the evaporator fan motor to move cold air through the evaporator and into the cabinet
• Helps stabilize internal temperatures and reduce frost buildup when operating correctly
• Commonly replaced when cracked, chipped, warped, or causing unusual noise or poor airflow
• Restores proper airflow to improve cooling performance when the original blade is damaged

• One fan blade

• Disconnect power before servicing the appliance to avoid electrical shock or injury
• Inspect the motor shaft and mounting for damage; clean debris before installing the new blade
• Ensure the blade is seated fully and rotates freely without rubbing against the housing
• If the motor shows excessive wear or noise, replace the motor assembly as needed rather than just the blade

The Heater is an OEM part for Frigidaire air conditioners. Designed to provide supplemental heating, this heater extends the usability of your air conditioning unit into the colder months, enabling both cooling and heating from a single appliance.

Causes of a bad heater can include electrical faults like short circuits or failing elements, accumulation of dust or debris that impedes functionality, and general wear and tear that deteriorates its components over time.

Symptoms of a bad heater include:

• Reduced heating efficiency, failing to adequately warm the space
• Circuit breaker trips when the heater is turned on
• Unusual or loud noises during operation
• Smell of burning when the heater is active

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This capacitor supplies the temporary electrical boost motor compressors need to start and run smoothly. Replacing a failed capacitor can restore reliable startup and help the refrigerator maintain proper cooling performance. What it does:

• Provides a momentary voltage boost to the compressor motor during startup
• Helps the compressor run more efficiently and prevents hard-starting
• Commonly linked to symptoms like a humming compressor, repeated clicking, or no-start condition
• Prevents excessive stress on start relays and other starting components when functioning properly

• Disconnect power to the appliance before starting any work
• Capacitors can hold charge—discharge safely with insulated tools
• Handle terminals carefully and match polarity/terminals to the original part

This electronic control board manages oven functions and user inputs so cooking cycles, timers, and display settings operate correctly. It replaces a failed or unresponsive oven control to restore normal keypad, clock, and bake/clean operations. What it does:

• Receives commands from the control keypad and runs the oven's heating and timing circuits.
• Controls bake, broil, timers and display signals for temperature and clock readouts.
• Can correct symptoms like no display, unresponsive touchpad, or failure to start heating when faulty.
• Interfaces with sensors and relays to sequence oven functions.

• Disconnect power at the breaker before accessing the oven control to avoid shock.
• Handle the board by the edges and avoid touching component leads; ESD precautions recommended.
• Verify connectors are fully seated and secure all mounting hardware before restoring power.

This oven temperature sensor detects the internal temperature and sends readings to the range control so the oven can maintain accurate cooking temperatures. Replaces a failed or intermittent sensor to restore reliable temperature control. What it does:

• Senses oven cavity temperature and provides temperature data to the control board
• Helps the control maintain set bake/roast temperatures
• Common symptom: oven temperature is incorrect or fluctuates during cooking
• Common symptom: cook cycles take too long or oven does not reach set temperature
• Common symptom: oven displays a temperature sensor or sensor fault code

• One oven temperature sensor (1 each)

• Disconnect electrical power to the appliance before removing or installing the sensor
• Handle the sensor carefully to avoid damaging the probe or wiring and ensure proper connector seating
• Inspect wiring and connector for damage; replace if frayed or corroded

This replacement power cord supplies mains power to compatible electric ranges and ovens so the appliance can operate safely and reliably. Use it to replace damaged, frayed, or non-functioning power cords. What it does:

• Carries household mains power to the appliance's terminal block and control assembly
• Restores power when a damaged or broken cord prevents the unit from turning on
• Addresses symptoms such as a blank display, no heat, or intermittent power loss
• Helps prevent hazards from frayed insulation or exposed wiring when replaced promptly

• Always disconnect power at the circuit breaker before starting work
• Verify the cord's plug and terminal configuration match your outlet and appliance before installation
• Route the cord and secure strain relief per the appliance's service instructions to avoid pinching or chafing

This electronic control board manages the appliance's user controls and electronic functions so buttons, displays, and timed cycles operate correctly. Replacing a faulty board can restore normal control response and display behavior. What it does:

• Receives user inputs and sends control signals to motors, valves, heaters, and displays
• Manages timed cycles, settings, and electronic diagnostics
• Can cause unresponsive buttons, blank or erratic display, or failure to start when faulty
• Works as the central logic module coordinating other electronic components

• One electronic control board (single complete assembly)

• Disconnect power (unplug or shut off breaker) before service to avoid shock
• Handle the board by its edges and avoid static discharge; wear an ESD strap if available
• Installation typically requires removing the control console or access panel and unplugging harness connectors

This main electronic control board manages your appliance's key functions and timing to keep cycles, defrost, lights and fans operating correctly. Replacing a failed board restores proper electronic control and cycle coordination. What it does:

• Regulates compressor, evaporator fan and condenser fan timing for normal cooling
• Controls automatic defrost cycles and defrost heater operation
• Manages user interface signals and status indicators
• Can stop operation or cause error codes when the board fails

• Disconnect power to the appliance before servicing to avoid shock or damage
• Handle the board carefully; avoid static discharge and moisture
• Verify the part number matches the existing control board before installation

This run capacitor helps the refrigerator's motor start and run more reliably, reducing strain on the compressor and fan. Replacing a failing capacitor can restore normal motor operation and help the appliance cool properly. What it does:

• Provides the electrical phase shift needed for motor start and continuous operation
• Helps reduce motor overheating and hard-start symptoms
• Commonly replaced when motors hum, won't start, or cycle erratically
• Supports steady compressor and fan performance for consistent cooling

• One run capacitor (single unit as pictured)

• Disconnect power to the appliance before inspecting or replacing the capacitor
• Discharge the capacitor safely before handling to avoid shock
• Verify terminal markings and wiring; replace with same type and ratings
