Parts for Lg LWHD1807HR: A / C Room Parts

This clamp secures a line or connection inside your appliance, maintaining a tight fit under vibration. Replacing a fatigued clamp helps prevent leaks or disconnections and keeps components anchored so the system operates reliably.

• Holds a line/fitting firmly to keep the joint sealed and secure
• Helps prevent leaks or disconnections at hose/tube connections
• Resists vibration that can loosen fittings during operation
• Replace if bent, weakened, or corroded, or if the connection repeatedly loosens

• Disconnect power and, if applicable, shut off water supply before service
• Note clamp orientation and routing; seat the clamp just behind the fitting bead/stop
• Use the correct tool for your clamp style to compress or tighten evenly
• After reassembly, restore utilities and test for leaks or movement

This horizontal louver directs airflow inside the appliance to help even cooling and prevent direct blasts on food. It restores proper air distribution when vent fins are broken or stuck. What it does:

• Guides refrigerator/freezer airflow for more even temperature distribution
• Replaces cracked, warped, or missing horizontal vent slats
• Helps reduce cold spots caused by misdirected air
• Visible damage or a louver that won't hold position are common symptoms

• One horizontal louver

• Disconnect power before servicing to avoid electrical hazards
• Remove nearby shelves or drawers for access if needed
• Typically snaps or slides into the vent housing; align and seat gently to avoid breaking tabs
• Inspect surrounding clips and housing; replace if damaged

This isolator routes microwave energy between the magnetron and waveguide to help protect components and maintain consistent heating performance. Replacing a failed isolator can restore reliable cooking and help prevent further high-voltage damage. What it does:

• Directs RF energy from the magnetron into the waveguide/cavity
• Helps protect the magnetron by reducing reflected energy
• Aids in preventing arcing or burn damage in the waveguide area
• Common symptoms of failure: no heat or uneven heating, loud humming/buzzing, visible arcing/burn marks near the waveguide

• 1 isolator

• Disconnect power and discharge the high-voltage capacitor before servicing; risk of electric shock
• Handle waveguide components carefully; avoid contaminating RF surfaces and note exact orientation
• Take photos of the original setup to match positioning and fastener locations

The Thermistor Assembly is an OEM part for LG air conditioners. It is typically located near the evaporator coil or in the air intake area of the unit. It measures the ambient temperature and sends signals to the control board to adjust the cooling output accordingly.

Causes of a faulty or malfunctioning thermistor assembly can include normal wear and tear, exposure to extreme temperatures, or electrical issues. These factors can lead to inaccurate temperature readings, improper cooling performance, or erratic behavior of the air conditioner.

Symptoms of a bad thermistor assembly may include:

• Inconsistent cooling or insufficient cooling
• Inaccurate temperature display on the control panel
• Frequent cycling on and off of the compressor

This OEM LG part can also be used on Kenmore/Sears appliances.

This installation kit includes the manufacturer-specified hardware used to secure and align an appliance during setup. Use it to replace missing or damaged install hardware and restore a safe, stable, factory-correct fit in the opening. What it does:

• Provides required mounting hardware for proper installation
• Helps prevent shifting, rocking, or tipping when the appliance is used
• Aids in correct alignment and spacing within the cabinet/opening
• Replaces lost or damaged original install parts

• One installation kit

• Disconnect power (and gas/water, if applicable) before starting
• Follow your model's installation instructions for bracket locations and fasteners
• Use appropriate anchors for wall/floor material as specified by the manufacturer
• After installation, verify the unit is level and securely anchored

This Guide Assembly, Air is an OEM part designed specifically for LG air conditioning units. Its primary function is to facilitate proper airflow direction and distribution within the air conditioning system, ensuring optimal cooling or heating performance.

Over time, this part may encounter issues due to extended usage or physical damage, leading to potential misalignment or restriction of airflow. Moreover, the accumulation of dust, dirt, or debris within the assembly can impede its functionality, ultimately affecting the unit's overall efficiency.

Symptoms indicating a bad guide assembly, air include:

• Inadequate cooling or heating output
• Uneven air distribution across the room
• Unusual sounds emanating from the air conditioning unit during operation
• Visible signs of damage or misalignment in the guide assembly

This OEM LG part is also compatible with some Sears/Kenmore models.
