Jesse P Layton , UT October 04, 2015 Appliance: Samsung Washer WA422PRHDWR/AA-0000 Washer pump rattled off of the drum spilling all water inside all over my house huge mess! After some research I discovered the design change Samsung did 3 months after my model was manufactured. Instead of spending $110 on the "redesigned" part I took a good look at it and determined I could disregard the current mounting bracket and order 3 parts to make the conversion with my existing pump, which is working just fine. I did this for about $30 and that includes shipping. Saved $80!!! You'll order the new floor bracket, a hose that has a 90 on it to connect to the drum and another short hose that connects the pump to the exit hose out of the washer. NOTE: don't use the hose rings that are on there. Use actual hose clamps that you can since down tightly witha nut driver. The 3 parts #s you'll need: 1) DC67-00601A (drain hose) 2) DC61-03550A (Pump bracket to mount to floor) 3) DC97-17417A (washer tub drain hose) Read More... 15 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Pliers, Screwdrivers, Socket Set
Michael D Lower Burrell , PA March 11, 2016 Appliance: Samsung Washer WA422PRHDWR/AA-0001 Poor location of drain pump First of all, I cannot believe that Samsung would actually think that putting the drain pump on the drum was a GOOD idea. The fix was easy, When I bought the washer off an individual, She told me that she was informed the drain pump needed replaced. So I did that. Pain in the a&* du to the location and trying to secure the bolts. It broke off after a week. I found out that Samsung put out a repair bulletin and a customer service rep from this site emailed it to me. After looking up the parts, I decided that I did not need to spend over $100 for the kit and purchased the necessary parts from APP for $60. So much easier to relocate the pump. Now you cannot even hear the washer run. Read More... 13 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Adjustable Wrench, Pliers, Screwdrivers, Wrench Set
Joshua R Orlando , FL June 27, 2015 Appliance: Samsung Washer WA456DRHDWR/AA-0000 Drain pump assembly cracked off Replaced it with this part which was mounted to the base instead of the tub. Much better design! Super easy fix, took 20 mins. The wire assembly didn't need replacing which saved much time. Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Richard M Riverside , CA October 21, 2016 Appliance: Samsung Washer WA456DRHDSU/AA-0001 Wa456drhdsu/aa pump braraket broke flooded house Well to say this site was a live saver is a understatement. While there was no replacement bracket to mount the pump under the washing basket. I saw from other reviews they changed the mounting to the base of the unit. After purchasing the new bracket and realizing latter that I had to order two new hoses my Washer is now officially fixed. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Joseph H Fort Smith , AR November 01, 2015 Appliance: Samsung Washer WA456DRHDWR/AA-0001 Broken mounting bracket and broken drain pump protectivr housing Researched APP for existing problem stories for my model. Contacted APP Tech support and learned from Stanley Rymer that Samsung had revised the drain pump design and released a new assembly kit of parts to fix problem and a new assembly location. I did not buy the kit, but bought AP5669738 bracket, DC67-00601A hose and DC97-17417A hose and relocated the pump to the washer outer frame base, connected new hoses and electrical connections to the pump. I could not have done this repair without APP tech and APP user resources Read More... Do-It-Yourself Rating: Repair Time Estimate: 2+ hours Tools: Nut Drivers, Pliers, Screwdrivers, Socket Set
