Mark H Chesterland , OH January 21, 2019 Samsung double range led display has burned out digit segments 1. Unplug range from power source. 2. Remove screws necessary to remove rear panel over the range controls. 3. Carefully unplug the white display cable connector from display housing. You will have to squeeze the bottom connector clip to unplug. 4. Remove the two mounting screws from the control panel circuit board. 5. Carefully push side clips away from the circuit board and free it from the housing. 6. Now the display will be exposed. Carefully remove the display from its housing by depressing the black clips. 7. Install new display into the housing clips being sure the connector is on top. 8. Reinstall the control panel circuit board into the housing clips and secure with the two screws. 9. Re-connect the display connector. 10. Re-install the rear panel and secure with screws. 11. Plug range into power source and test display functions. Read More... 17 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Bradford W Gloucester , MA April 26, 2020 Appliance: Samsung Range Electric NE59J7850WS/AA Clock led had missing 'bars', samsung flex duo stove Searching the internet I came across the led board for my stove as being this fix. I ordered from appliancepartspros.com and when it arrived had it installed in about 10 minutes. Works great! Read More... 10 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
James J Bradenton , FL November 20, 2022 Appliance: Samsung Range Electric NE59J7850WS/AA The display on the Samsung range had a strobing effect and not displaying all numbers when displaying the time. I replaced the LED Display part number DE07-00130A Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Peter M Methuen , MA June 07, 2018 Appliance: Model NE59J7850WSAA Samsung range led display partially out AP suggested LED display part and number. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Vincent P Palm Bch Gdns , FL June 23, 2025 Led screen was strobing and missing segments as well as indicating things were on that weren't actually on but only some partial segments were illuminated Replaced the LED digital display screen. Worked perfectly after part was replaced! Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
