Brett D Comstock Park , MI June 16, 2015 Samsung microwave e5 code Unplugged the wall outlet and went to work. Watched a Youtube vide on how to change this touchpad first before I started, so as I got into it, there were no surprises. Hardest part was actually peeling the old unit off the plastic base. The adhesive is strong. It works really well to just rub the leftover glue with you finger to get it to ball up and be removed before you stick the new one in place. Really a very straightforward repair as long as you can wield a Philips screwdriver and the sight of a circuit board doesn't make you terrified. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Screwdrivers
Dan F Carver , MA November 17, 2014 Microwave switchmembrane was bad Simple repair - removed defective piece & installed replacement part. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Mark W Plantation , FL March 28, 2016 The switch membrane failed causing random led information and beeping this is obviously a flaw wtih this over the range samsung microwave because this is the third replacement i have installed I replaced just the membrane. Unplug. Then remove two Phillips screws on top of the vent/diffuser, shift slightly and remove. Then remove one screw holding the touchpad. Lift up then out. Gently remove four connectors and the ribbon connector on the board and the touch pad is free. Remove three or four screws holding the circuit board to the metal bracket inside the plastic touch pad housing. Remove the metal bracket by gently separating the plastic tabs. A knife or small flathead can be used to pry a corner of the old membrane up then peel it off. It is about as thick as a credit card but flexible. Run the ribbon connectors through their slot and adhere the peel and stick new membrane. Reassemble in reverse order. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
Angela S Clay Center , KS November 08, 2015 Appliance: Samsung Microwave SMH9187W/XAA Getting the se code I ordered the control panel and switch membrane. Replaced the control panel and microwave works great! I'll be keeping the switch membrane just in case we have any more issues with our microwave. Shipping was insanely fast, ordered on a wednesday during lunch hour and received the parts the next day before lunch and hubby had the install done in just a few minutes! Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
David G El Paso , TX September 05, 2016 Appliance: Samsung Microwave SMH9187W/XAA Kept getting an se error After searching the internet ran into the AppliancePartsPROS.com website, Found that the problem was the "switch mambrane". I ordered it and received it withing two days as expected. The part was easy to replace and seems to have slolved the problem, microwave is working fine. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
