Samsung DE47-20037A Range High Limit Thermostat OEM Part

With the help of several You Tube videos I was able to diagnose the problem. Diagnosis was confirmed with the help of a multi-meter. The thermo fuse was dead. I ordered the part from Appliance Parts Pros on Wednesday and it arrived via UPS on Friday afternoon. The fuse was very easy to remove and replace and my range was up and running in less than 15 minutes. Local repair service wanted $100 to do the diagnosis plus parts plus a return trip for installation. I got the part from Appliance Parts Pros for less than $5.00 plus shipping. I did the install on my schedule, not theirs.

Just using a Phillips Screw Driver ...Parts Arrived 4 days after online ordering . it took me longer to Vacuum behind the Range than it took me to fix it.. lol .. Un plug the Range Remove 5 Screws holding the back panel on, My Model Range the Sensor Thermistor was in the Top Middle .. and the Screw was (Inside) the range not on the back. (USE A GOOD PHILLIPS Screwdriver ) as to not strip out the head, Carefully unplug the Wire harness, Remove screw, pull wire harness from inside oven area and rethread NEW wire harness into open area,clip harness together (To help hold it in place ) re screw thermo bracket to Oven wall, and your done... I Replaced the Therm just to be safe it sits on the back of the Range held on with metal tabs, Carefully bend tabs out to remove and unplug sensor and re-plug new sensor, Bend tabs back and DONE! install 5 screws move range back to location and your done... here's a lil tip .. If you have tile floors or Linoleum.. Spray Windex in front of the Range Legs and it will slide out minimum Effort Ladies, If you can work a screwdriver no need for you to wait on the husband to get Around to it.... added my wife LOL ( but I still Repaired in Less than 20 minuets.Most importantly four days before Thanksgiving.

Used a multimeter and the service guide to determine there was power coming into the range, but no power to either of the circuit boards. This led me to the themal fuse. To test, I broke off one of the tabs on the blown fuse and used it as a temporary splice. Everything started working, so I knew this was the culprit. Replacing the fuse is easy, however clearance is a bit tight with the cooktop in place. If it should fail again, the repair would be less than 15 minutes. I bought 2 to keep a spare on hand.

Replaced thermal fuse; After performing self-cleaning, oven shut off. My thermal fuse on model# ne58f9500ss, was under the ceramic top. Door was stuck from self-cleaning so I unlatched the metal bar that runs to the door motor in the back of the oven. Needed to do this in order to unscrew faceplate on the front to get the top off. Once top is off, the thermal fuse is easy to replace. Took me a while to figure out how to get top off but project would take <15 minutes next time.

After determining where the part was located I tested it and found it to be bad. Ordered a new part in the afternoon and it arrived the next morning. After changing it everything was fine.
