Parts for Ge AZ45E09DBMW1: Sealed System Parts

This door vent assembly replaces the venting component mounted in the appliance door to help direct airflow and exhaust. It restores proper door airflow path and prevents gaps that can reduce performance or allow debris entry. What it does:

• Provides the door-mounted vent path for airflow and exhaust.
• Seals and directs air through the door opening to maintain intended circulation.
• Can prevent lint, dust, or small debris from entering internal cavities.
• Symptoms of a failing vent: visible cracks, warped or loose vent, reduced airflow, or abnormal exhaust routing.

• Disconnect power (and gas if applicable) before beginning any repair.
• Basic hand tools (screwdriver, nut driver) are typically required to remove the door panel and replace the vent.
• Handle edges carefully; wear gloves to protect hands and avoid damaging the new part.

A rubber compressor grommet that cushions the compressor and helps reduce vibration and noise for more stable, quieter operation. Fits over compressor mount studs to isolate the compressor from the cabinet frame. What it does:

• Absorbs and isolates compressor vibration to reduce rattling and noise
• Prevents metal-to-metal contact between compressor and mounting plate
• Helps protect mounting hardware and compressor casing from wear
• Commonly used when noise, vibration, or movement is noticed around the compressor area

• Disconnect power to the appliance before servicing to avoid shock hazard
• Access the compressor from the rear panel; support the compressor when removing mounts
• Replace any additional worn grommets or mounting hardware for best results

This compressor overload protector interrupts power to the compressor when the motor overheats or draws excessive current, helping prevent compressor damage and premature failure. Replaces a failed thermal overload on the compressor terminal for reliable restart protection. What it does:

• Senses compressor over-temperature or over-current and disconnects power to protect the compressor
• Helps stop a hard-starting compressor from running continuously and overheating
• Commonly linked to symptoms such as a refrigerator that hums but won't run, intermittent cooling, or a compressor that trips off
• Works with the compressor's start components to allow safe restart once conditions normalize

• Disconnect power to the appliance before accessing the compressor terminals
• Handle terminals and wiring carefully; note original connections and replace exactly

This plug base pan is the metal mounting pan that secures the appliance's power plug/terminal assembly and helps protect wiring from heat and debris. It restores a stable mounting surface for the power connection. What it does:

• Provides a secure mounting surface for the power plug/terminal assembly
• Helps protect wiring and connections from heat, grease, and debris
• Prevents the power plug from shifting or rubbing against other components
• Worn or damaged pans can expose wiring or cause poor electrical seating

• One plug base pan

• Disconnect all power at the breaker or unplug the appliance before beginning work
• Access typically requires removing the appliance back panel or console; keep track of fasteners
• Inspect wiring and terminal hardware while replacing the pan; replace any damaged connectors

Thermistor monitors internal appliance temperature and sends readings to the control board so the system can maintain proper cooling and cycle behavior reliably. What it does:

• Detects temperature and reports it to the control board so cooling, fans and cycles respond correctly.
• Helps the appliance maintain consistent temperatures and prevents overcooling or excessive runtime.
• A faulty thermistor can cause temperature fluctuations, an appliance that runs constantly or not long enough, or uneven cooling.
• Works as the temperature-sensing component used by the control system to regulate performance.

• Disconnect power before servicing to avoid shock or injury.
• Note connector orientation and wire routing before removal; handle the sensor leads gently to avoid damage.
• Seat the connector fully and secure any clips or mounting points so the sensor sits in the correct location.

This thermistor holder secures the refrigerator temperature sensor in the correct position so the control board reads accurate air/evaporator temperatures for consistent cooling performance. What it does:

• Holds the temperature sensor/thermistor in place near the evaporator or air duct so the control can monitor temperature.
• Helps ensure accurate temperature readings to prevent overcooling or insufficient cooling.
• Stabilizes sensor location to reduce intermittent or false temperature signals.
• Commonly associated with symptoms like erratic temperature display, long run cycles, or uneven cooling when the sensor is loose or damaged.

• One thermistor holder/mounting bracket.

• Disconnect power to the appliance before servicing to avoid shock.
• Handle the thermistor/sensor carefully; do not pull on wires or bend the sensing element.
• Ensure the sensor is fully seated in the holder and that the holder is secured in its mounting location.
