Parts for Ge JBS05GL3: 03 - Section3 Parts

This end cap secures the refrigerator light housing and helps keep the lens and bulb in place for reliable interior lighting. Replaces a worn or broken end cap to restore a snug fit and prevent rattling or light misalignment. What it does

• Secures the end of the refrigerator light housing and helps hold the lens and bulb assembly in position.
• Common symptom: cracked or broken end cap allowing the lens or bulb to shift, rattle, or fall.
• Restores a tight fit at the light housing end so the interior light operates and stays properly aligned.
• Fits into the existing light housing and works with the factory lens and bulb.

• One end cap for the light housing.

• High-level replacement: part typically snaps or screws into the light housing; keep power off to the appliance before starting.
• Disconnect power or unplug the appliance before attempting service to avoid electrical shock.
• Handle the lens and bulb carefully; avoid forcing the cap to prevent cracking surrounding plastic.
• Use manufacturer screws or clips removed from the old cap if the new cap does not include fasteners.

8" element switch

6" element switch

A light indicator is installed on ranges and wall ovens as a safety feature. The purpose of the light indicator is to tell the user when the appliance is in operation. When the unit is heating up or running, the light indicator will illuminate. A replacement part is necessary if the component is no longer functioning.A visual inspection will determine if the light indicator is working. Turn the oven on, and if the light doesn't glow, it's broken. Replacing the light indicator is a quick and easy process. Unplug the range from its power source before starting. An adjustable wrench or nut driver is required to make the replacement. The light indicator is located inside the cover plate of the appliance.This light indicator is an authentic OEM replacement part. It is sold as an individual unit. It comes sourced directly from the manufacturer. The light indicator is made of durable, high-quality materials. The component is compatible with several models of ranges. It fits into products produced by General Electric, RCA, and Hotpoint.

This part is the lens for a small appliance light on select GE cooking products. It covers and diffuses the lamp, protecting the opening and restoring a clean, finished appearance so status illumination is easy to see.

• Covers and diffuses a panel/indicator light so it's visible without glare
• Helps shield the lamp cavity from grease, moisture, and debris
• Restores proper appearance if the original lens is cracked, missing, or discolored
• Common symptoms: missing or broken lens, cloudy/yellowed lens, exposed indicator lamp

• Disconnect power to the appliance before servicing
• Access the lens from the rear of the panel or mounting area; release retaining tabs or hardware
• Seat the new lens fully and align any tabs before securing
• Restore power and verify the indicator light shines through clearly

ST10-16 X 7/16"

Nickel
