Parts for Whirlpool LER3622HQ1: 03 - Section Parts

This white top panel replaces the outer cooktop surface on compatible ranges to restore a finished look and protect internal components from spills and debris. It's a direct-fit exterior part used when the original top is dented, cracked, or cosmetically worn. What it does:

• Covers and protects the range's internal components and burners from spills and heat exposure
• Restores a clean, finished appearance to the appliance exterior
• Helps maintain proper spacing and support for burner assemblies and controls
• Reduces risk of debris falling into the cabinet area below the cooktop

• One white top panel

• Requires basic disassembly of the cooktop; your model's service manual for step-by-step instructions
• Disconnect power (and gas supply if applicable) before beginning any repair to avoid shock or injury
• Use appropriate fasteners and gaskets from your model's parts list; do not force-fit parts

10 - 16 x 1/2

This 3-cycle timer controls the sequence and duration of wash/dry cycles, restoring proper cycle advancement and timing for compatible appliances. Designed to replace a worn or non-advancing timer so your machine completes cycles as expected. What it does:

• Rotates through the machine's timed cycles to start, run, and end selected programs
• Opens and closes internal contacts to route power to motors, valves, or heaters at the right times
• Commonly replaces a timer that won't advance, stops mid-cycle, or fails to energize components
• Helps resolve symptoms like no cycle progression, no motor/heater activation, or stuck settings

• One 3-cycle timer

• Disconnect power before servicing to avoid shock risk
• Follow for removal, wiring locations, and mounting; label or photograph connections before disconnecting
• Handle the timer gently; avoid bending terminals or applying excessive force
• Test appliance functions after installation; some models may require timer indexing or calibration per OEM instructions

This latch knob screw secures the latch knob to its shaft on compatible appliances. Replace a missing, stripped, or rusted screw to restore a firm, reliable attachment and proper latch/knob operation. What it does:

• Attaches the latch knob securely to the latch mechanism/shaft
• Helps maintain proper door latch engagement and knob control
• Common fix for a loose, wobbly, or falling-off knob
• Replaces a lost, corroded, or cross-threaded screw

• 1 latch knob screw

• Disconnect power and allow the appliance to cool completely before servicing
• Align the knob on the shaft and start the screw by hand to avoid cross-threading
• Tighten with the correct screwdriver; do not overtighten to prevent damage
• The latch engages and releases smoothly after installation

This is a replacement machine screw sized 8-18 x 3/8 that secures panels and components on compatible appliances. It restores proper fastening where a worn, stripped, or missing screw causes loose parts or rattling. What it does

• Fastens control panels, trim pieces, or brackets to the appliance chassis
• Replaces stripped, corroded, or missing screws that cause loose panels or vibrating noise
• Provides correct thread engagement for a secure hold in tapped holes
• Small hardware solution often used during door, console, or interior repairs

• One 8-18 x 3/8 machine screw (quantity: 1)

• Use the correct screw size and thread; do not force a different-size fastener into tapped holes
• Hand-start the screw to avoid cross-threading, then tighten with the appropriate screwdriver
• Disconnect power before accessing internal components or panels on electrical appliances
• If metal threads are damaged, repair with a helicoil or replace the damaged component rather than over-torquing

The Push to Start Switch is an OEM part for Whirlpool dryers. It is responsible for initiating the drying cycle when pressed, sending an electrical signal to start the dryer.

You should replace this push to start switch if it becomes defective. Causes of a bad switch can include electrical failures, physical damage from repeated use, or internal wear over time.

Symptoms of a bad push to start switch include:

• The dryer not starting when the button is pressed
• The need to press the button multiple times to start the dryer
• No response or clicking sound when the button is pressed

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Note: For square top push to start switch, use part number W10156101.

Color: White.

Specs: 10-16 x 1/2 inch.

This front-panel bracket secures and positions the appliance's front panel to keep it aligned and stable, helping prevent gaps, vibration, or rubbing during operation. It restores a snug, secure fit after damage or wear. What it does

• Secures the front panel to the appliance frame to maintain proper alignment.
• Supports the panel to reduce vibration, rattling, and noise.
• Helps prevent gaps that can allow debris buildup or interfere with door/panel operation.
• Restores correct panel positioning after impact, bent mounting points, or missing hardware.

• Disconnect power (and gas supply if applicable) before starting any repair.
• Handle sharp sheet-metal edges carefully and wear gloves and eye protection.
• Basic hand tools (screwdriver, socket) are usually required; follow the service manual for fastener locations.
• Replace damaged mounting hardware and inspect adjacent clips/brackets for wear.
