Parts for Dacor EG486SCHLP: Top Assembly Parts

This service spill tray replaces a cracked or damaged left-side defrost/drip tray to help contain meltwater and prevent leaks under the refrigerator. It restores proper drainage and protection for the cabinet floor. What it does

• Catches and channels defrost or condensation water away from refrigerator components.
• Helps prevent water pooling and potential floor damage from leaks.
• Restores a secure mounting surface when the original tray is cracked, warped, or missing.
• Matches the left-side tray location and specified 14 x 24 size for a correct fit.

• One service spill tray (left-side, 14 x 24) as shown.

• Disconnect power to the appliance before starting any service work.
• Remove shelves, drawers, or kick plate as needed for access; handle plastic parts gently to avoid damage.
• Verify tray orientation and seating before reassembling; do not force parts into place.

This service spill tray is a molded replacement tray that sits under the appliance to catch and channel small water leaks and drips, helping protect the cabinet and floor from moisture damage. What it does:

• Collects and directs minor water from leaks, condensation, or ice maker/defrost drip
• Prevents water from pooling under the appliance and reaching flooring
• Replaces cracked, warped, or missing trays that allow leaks to spread
• Helps identify and contain source of slow leaks during diagnosis

• One spill tray (center, 14 x 24 in.)

• Disconnect power (and water supply if applicable) before beginning service
• Remove access panels or components as needed to access the tray; keep fasteners for reassembly
• Verify correct orientation and seating of the tray before restoring power
• If tray was damaged by a leak, repair the underlying cause before installing replacement

This replacement spill tray trim restores the black trim piece that surrounds the refrigerator spill/drip area so the interior looks finished and helps channel minor spills away from drawers. Fits the OEM tray opening for a clean seal and appearance. What it does:

• Replaces a cracked, warped or missing spill tray trim that lets spills escape or catch on drawer edges
• Helps direct small food and liquid spills toward the tray for easier cleanup
• Restores proper edge finish so drawers open and close without rubbing
• Prevents debris buildup under the trim that can lead to odors

• High-level: remove the affected drawer or shelf to access the trim; align the trim tabs into the housing and snap into place
• Use gentle pressure to avoid breaking plastic tabs; do not force if resistance is encountered
• Disconnect power only if removal requires moving appliance components that expose electrical parts

A replacement service screw used to secure appliance panels and components. Durable fastener sized for common service points, making repairs and panel reassembly quick and reliable. What it does:

• Secures trim, access panels, brackets or small components during service and reassembly
• Commonly used where a shallow truss/wafer head is needed to sit flush without catching
• Helps stop rattling or loose parts caused by missing or stripped screws
• Matches OEM fit for compatible assemblies when the OEM part number is required

• One service screw (#8 x 1/2" truss/wafer head) as specified by the OEM part number

• Use the matching size driver to avoid cam-out and head damage
• Hand-start fasteners to avoid cross-threading; tighten until snug — do not overtighten
• Wear safety glasses and disconnect power before working on electrical appliances
• If a screw threads into plastic or thin sheet metal, consider replacing with the same OEM screw to preserve original threads
