Parts for Dacor EG486SCHLP: Main Assembly Parts

This service assembly secures and aligns the injector used in the appliance's dispensing/ice/water system, restoring proper positioning and reliable flow. Replace a damaged holder to stop misalignment that can cause leaks or intermittent dispensing. What it does:

• Holds and aligns the injector/nozzle in the dispenser or ice/water delivery path
• Keeps seals and hoses seated to prevent leaks and poor water flow
• Restores correct injector position when cracked, warped, or broken
• Helps resolve intermittent dispensing or dispenser misfeeds tied to misalignment

• Disconnect power and shut off water supply before beginning any repair
• Remove access panels and mounting fasteners to access the injector area; handle plastic clips gently to avoid breakage
• Inspect adjacent seals, hoses and the injector for damage; replace any worn parts as needed

This dual burner gasket seals the dual burner assembly to the cooktop surface, keeping spills out and the burner properly supported. Replacing a worn gasket restores a snug fit and consistent, reliable burner operation.

• Creates a tight barrier between the dual burner base and the cooktop
• Helps maintain correct burner height and alignment for stable operation
• Limits liquid and debris intrusion that can cause corrosion or binding
• Common signs: visible cracking/flattening, burner not sitting flush, liquids seeping below, or the burner shifting during use

• Disconnect power and shut off the gas supply; allow the appliance to cool completely
• Remove grates, caps, and burner components to access and remove the old gasket
• Clean mating surfaces before installation; do not stretch or twist the new gasket
• Reassemble and verify the burner sits flat and operates normally

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This burner ring cap base provides the support and alignment for a gas cooktop burner cap, helping direct the flame for consistent heating and safe operation. It replaces damaged or warped bases that prevent proper burner seating. What it does:

• Supports and centers the burner cap so the flame is properly directed
• Restores even heating and stable flame pattern when the original base is cracked or warped
• Helps maintain correct burner-to-cap spacing for reliable ignition and simmer control
• Prevents burner cap wobble that can cause uneven cooking or noisy flames

• Turn off the gas supply and power to the appliance before starting any work
• Remove burner cap and grate to access the base; ensure all surfaces are clean and dry before installing
• Fit the new base into the burner assembly and ensure the cap seats evenly and securely

This service pack includes the burner cap and burner ring used on compatible Samsung gas cooktops and ranges. It restores proper gas flow and stable flame by replacing worn or damaged burner top components. What it does

• Replaces the visible burner cap and surrounding burner ring for one cooktop burner
• Helps restore even flame distribution and consistent heating on the affected burner
• Can resolve ignition issues caused by warped or corroded burner tops
• Useful when the burner shows yellow tipping, uneven flame, or poor simmer performance

• One burner cap and one burner ring service pack

• Turn off gas supply and disconnect power before servicing the appliance
• Remove grates and existing burner components, then fit new ring and cap in correct orientation
• Inspect ignition electrode and gas orifice while servicing; clean or replace if needed

This service pack includes the burner cap and burner ring used on compatible Samsung gas cooktops and ranges. It restores proper gas flow and stable flame by replacing worn or damaged burner top components. What it does

• Replaces the visible burner cap and surrounding burner ring for one cooktop burner
• Helps restore even flame distribution and consistent heating on the affected burner
• Can resolve ignition issues caused by warped or corroded burner tops
• Useful when the burner shows yellow tipping, uneven flame, or poor simmer performance

• One burner cap and one burner ring service pack

• Turn off gas supply and disconnect power before servicing the appliance
• Remove grates and existing burner components, then fit new ring and cap in correct orientation
• Inspect ignition electrode and gas orifice while servicing; clean or replace if needed

This burner base assembly replaces the oven's damaged or worn burner base to restore stable combustion and proper heat distribution for gas ranges. It fits original equipment configurations and mounts where the burner connects to the range. What it does:

• Provides the appliance's burner mounting and gas flow interface for ignition
• Helps restore even flame pattern and consistent heating across the burner
• Replaces cracked, warped, or corroded burner bases that cause poor performance
• Can resolve ignition and flame stability issues when base damage is the cause

• Disconnect the appliance from gas and power before servicing.
• Use proper gas-line fittings and check all connections for leaks after installation.
• Inspect surrounding seals and gaskets; replace if damaged to maintain proper operation.

This re-ignition module controls spark for gas surface burners and automatically re-sparks if the flame goes out, helping burners ignite consistently and stay lit when the original module has failed. What it does:

• Sends high-voltage pulses to the burner igniters to light gas
• Provides re-ignition if a burner flame is extinguished
• Distributes spark output to multiple burners as designed
• Common failure symptoms: no spark on all or most burners, continuous clicking, or intermittent ignition across burners

• 1 re-ignition module

• Disconnect electrical power at the breaker and shut off gas supply before servicing
• Access location varies by model; remove rear cover or top as required
• Label and transfer each wire one at a time; mount the module securely and route wires away from heat
• After installation, test each burner for proper ignition and that clicking stops once flame is established

This service tool is designed to handle dual-ring gas burner components during service and repair, helping seat and remove burner parts cleanly to reduce damage and speed maintenance. What it does:

• Helps install, remove, and align dual-ring burner elements and caps without scratching or bending
• Enables safer handling of burner assemblies during maintenance and replacements
• Useful when burners show uneven flame, inconsistent ignition, or need realignment
• Reduces risk of damaging delicate burner parts while servicing

• Disconnect power and turn off the gas supply before servicing gas components
• Use only as intended for burner servicing
• Wear appropriate PPE (gloves, eye protection) when working on gas ranges
• Recommended for use by trained service technicians or repair personnel

This service cable clamp secures a refrigerator/freezer wire harness to the cabinet, reducing strain and preventing chafing for reliable electrical connections and quieter operation. What it does:

• Holds the service or harness cable firmly to the cabinet or chassis to prevent movement
• Reduces strain on wire terminals to help avoid intermittent connections
• Helps prevent wire chafing and insulation wear that can lead to shorts
• Keeps wiring neat and routed away from moving parts or hot surfaces

• Always unplug the appliance or disconnect power at the breaker before beginning any work
• Remove any access panels needed to reach the original clamp location; install by aligning with the original mounting point and securing using the original method
• Position the cable in the clamp so it is held snugly without pinching the insulation
• After installation, restore power and inspect for any loose wires

This service nut retainer secures 1/4-20 service nuts used on panels and assemblies, keeping fasteners locked in place so parts stay aligned during use and maintenance. It's a low-profile clip designed for reliable holding where a captive nut is required. What it does:

• Captures and holds a 1/4-20 nut to provide a captive fastening point
• Keeps panels, brackets or components aligned while fasteners are installed
• Prevents nuts from falling into hard-to-reach areas during repair
• Helps reduce vibration looseness on secured assemblies

• Verify correct orientation and nut size (1/4-20) before installation
• Install with power off and disconnect appliance from power source
• May require basic hand tools; avoid forcing the retainer to prevent damage
• If hardware or mating clips are corroded or damaged, replace them together for best fit

This LED isolator board supplies and protects the LED lighting/display circuitry on compatible Samsung appliances. It restores proper LED operation by isolating and regulating the LED power feed for reliable lighting and display performance. What it does:

• Routes and isolates power specifically for LED modules and display LEDs
• Helps stop LED flicker, dimming, or intermittent lighting caused by a failing isolator board
• Supports stable LED backlight and control signals to the appliance display
• Serves as a direct replacement for the original service board when the LED circuit is at fault

• One LED isolator/service board (DE81-06682A)

• Disconnect all power to the appliance before starting any repairs
• Handle the PCB by its edges and avoid static-sensitive contact with components
• Verify correct board orientation and connector seating during installation
