Parts for Frigidaire CGEH3047VFA: Top / Drawer Parts

This replacement refrigerator cabinet liner restores the appliance's interior surface, helping contain spills and support shelves/drawers for reliable storage. Fits specific Frigidaire models; use the part number on your unit. What it does:

• Replaces cracked, warped or damaged interior surface that can allow moisture, odors, and debris to collect
• Provides the finished interior surface that supports shelf and bin mounting points
• Helps maintain a clean, easy-to-wipe interior and prevents insulation exposure
• Reduces the risk of leaks by restoring the proper fit and seals where the liner meets doors and gaskets

• One refrigerator cabinet liner as shown

• Disconnect power and empty the refrigerator before starting; follow manufacturer safety guidance
• Installation generally requires removing shelves, drawers and trim; small fasteners or clips may secure the liner
• Avoid sharp tools to prevent damage; inspect surrounding seals and hardware while replacing the liner

This metal shield protects internal components from heat, debris, and wear, helping the appliance run safely and reliably. It replaces damaged or missing shields to restore proper protection around sensitive parts. What it does:

• Shields wiring and components from heat and debris to prevent damage
• Helps reduce risk of shorting or component exposure caused by a damaged panel
• Common symptom: visibly bent, warped, or corroded shield
• Common symptom: unusual odors or hot spots near the area the shield covers

• One replacement shield/trim panel as shown

• Disconnect power (and gas supply if applicable) before starting any repair
• Wear gloves to protect against sharp sheet-metal edges
• Retain and reuse original fasteners when possible; replace any stripped screws
• If accessing the shield requires removing other panels, keep track of hardware and order of removal

The stainless drawer panel is an OEM replacement part for Frigidaire gas ranges. It is a cosmetic component that serves as the front panel or façade of the drawer compartment located beneath the oven cavity. This panel is typically made of high-quality stainless steel, designed to complement the overall aesthetic of the range and provide a sleek, modern appearance.

Symptoms of a bad or damaged Panel,Drawer,Stainless include:

• Visible dents, scratches, or discoloration on the panel surface
• Difficulty in opening or closing the drawer due to misalignment
• Rust or corrosion on the panel, especially in areas exposed to moisture or spills

Causes of a bad panel can range from accidental impacts or mishandling during installation or use, to prolonged exposure to heat, moisture, or harsh cleaning chemicals. Over time, regular wear and tear can also lead to the deterioration of the panel's appearance or functionality.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore gas range models.

This glide is a replacement drawer slide that helps the refrigerator or freezer drawer open and close smoothly and stay aligned. It restores stable drawer movement and reduces sticking or uneven travel. What it does:

• Guides the drawer along its track for smooth, controlled opening and closing
• Keeps the drawer aligned to prevent rubbing, binding, or uneven movement
• Replaces worn or damaged glides that cause sticking, sagging, or noisy operation
• Works as a structural support point for the sliding drawer assembly

• One replacement glide

• Basic hand tools are typically all that's needed; remove the drawer to access the glide
• Compare the old glide to this part before installing to confirm fit and orientation
• Keep fingers clear of pinch points; wear gloves if needed and follow appliance power-off safety
• If fasteners are stripped or broken, replace them with OEM-equivalent hardware

This oven bake element provides the heating needed for baking and roasting, restoring proper oven temperature and cooking performance. It fits into the oven cavity and connects to the range's electrical terminals. What it does

• Heats the oven cavity so food can bake and roast evenly.
• Replaces a visibly burned, broken, or non-heating bake element.
• Common symptom: oven won't reach or maintain baking temperature.
• Common symptom: uneven baking or cold spots on the oven floor.

• One bake element.

• Disconnect power to the appliance before starting any work; this part connects to live electrical terminals.
• Installation generally requires access to the oven cavity and removal of the oven bottom or rear panel to reach mounting screws and terminals.
• Handle carefully to avoid bending or damaging the element; use proper tools and follow OEM instructions.

The Surface Element is an OEM part for Frigidaire electric ranges and cooktops. It is the individual electric coil located beneath the cooktop that provides heat.

The surface element heats up rapidly upon activation in order to boil, simmer or saute foods efficiently. Its precise heating capabilities assist home cooks in meal preparation.

Causes can be mineral deposits caked onto the element surface over time reducing its ability to transfer heat properly. Excess moisture exposure can also damage internal wiring.

Symptoms of a bad surface element include:

• Burners that do not heat up at all or heat unevenly
• Lights flickering below an element when in use
• Popping, buzzing or crackling noises coming from below an element

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

Restore reliable heat with this replacement heating element. A worn or damaged element can cause long heat-up times, uneven temperatures, or no heat at all. Swapping it out helps return consistent, dependable heating performance.

• Converts electrical energy to heat when energized
• Common symptoms: no heat, slow to heat, or uneven/inconsistent temperatures
• Visual clues: cracks, breaks, burn spots, or terminals damaged/corroded
• Helps resolve heat-related error codes after proper diagnosis

• Disconnect power at the breaker before servicing; verify no voltage present
• Note wire positions and terminal orientation before removal
• Handle carefully; avoid stressing terminals and element sheath
• Inspect wiring and connectors; replace any heat-damaged spade terminals before reassembly

The Surface Element is an OEM part for Frigidaire ranges. The small surface element is responsible for providing direct heat to the cookware placed on the corresponding burner of the electric cooktop or range. This element is typically located underneath the glass surface of the cooktop or range, ensuring efficient and even heat distribution for cooking.

Symptoms of a failing Surface Element include:

• The element not heating up at all
• Heating unevenly or only partially
• Noticeable damage or blistering on the element itself
• The control switch not regulating the temperature properly

Causes of a bad surface element can include a burnt-out coil, a break in the element's continuity, or problems with the connection points such as corrosion or loosening. Regular wear and tear from cooking can also lead to degradation over time.

This OEM replacement is also compatible with Electrolux, Gibson, Kelvinator, and Kenmore models.

This smooth-top glass is the replacement cooktop surface that restores a flat, easy-to-clean cooking area and protects the underlying burners and components. Ideal when the original glass is cracked, scratched, or otherwise damaged. What it does:

• Replaces damaged or broken cooktop glass to restore a smooth cooking surface
• Provides a sealed, easy-to-wipe surface that helps contain spills and debris
• Maintains correct spacing and protection for the heating elements beneath the glass
• Helps eliminate rattling or uneven cooking caused by a warped or broken top

• Disconnect power to the range before starting work to avoid shock risk
• Use proper supports and soft padding to prevent chipping during removal/installation
• Verify alignment and secure mounting to avoid stress points that can cause cracking

This replacement part is a black element mounting clip used in ranges or wall ovens. This clip is used for surface elements on electric ranges and ovens. The clip itself connects the surface of the element to the support bracket which allows the stove to heat up. The user might need a new clip or clips if the heating element on the stove is loose, if the heating element is completely detached, or if the clip itself is bent or broken. This clip is black and made of sturdy metal that can withstand heat as well as strain on the clip itself. Installation of this clip is very simple as it just requires replacing the old one with a new one and making sure it is secure. Pliers might be required if the old clip is bent or stuck near or on the heating element. There are no special tools needed for this repair. This is an OEM part sourced directly from the manufacturer. It is sold individually. This part is compatible with machines from Frigidaire and other brands like Electrolux, Gibson, Kelvinator, Crosley, Westinghouse, and more.

This is a replacement mounting screw used to secure panels and components in compatible Frigidaire appliances. It restores proper fit and helps prevent rattles, loose panels, and parts that shift during operation. What it does:

• Fastens trim, panels, brackets, or controls to the appliance frame
• Restores secure attachment to reduce vibration, noise, and movement
• Replaces stripped, missing, or corroded screws that prevent proper assembly
• Works wherever the OEM screw with this part number is specified

• Disconnect power to the appliance before beginning any repair
• Use the correct screwdriver or bit to avoid stripping the head
• Tighten until snug—do not overtighten to avoid stripping threads or damaging parts
• Keep removed hardware organized and compare parts to the old screw for correct fit

This decorative trim piece restores the finished appearance where the original trim is cracked, dented, or missing. It provides a clean edge and helps the appliance look factory-new again. What it does:

• Covers damaged or worn edges to improve appearance
• Helps keep gaps closed between panels to reduce exposed edges
• Prevents dirt and grime build-up along the trim line
• Fits where the original factory trim was installed and fastened

• Disconnect power to the appliance before starting any work
• Basic hand tools (screwdriver, nut driver) may be required for removal and installation
• Handle edges carefully to avoid cuts and scratching the finish
• Replace any damaged fasteners; do not overtighten to avoid warping the trim

The Rear Filler Kit is an OEM part for Frigidaire ranges. It is responsible for sealing gaps and maintaining proper ventilation at the rear of the range. The filler kit prevents air leaks while allowing heat to properly escape from the oven cavity.

Causes of a bad rear filler kit can include normal wear and tear over time, damage that has compromised the sealing properties, or improper installation that has left gaps.

Symptoms of a bad rear filler kit include:

• Improper or uneven baking and broiling results
• Higher than normal temperatures on oven surfaces or cabinets nearby
• Excessive drafts or cold air felt around oven door or oven controls

This OEM Frigidaire part is also compatible with Electrolux, Gibson, Kelvinator and some Kenmore models.

This genuine replacement door seal restores a tight refrigerator fresh-food compartment closure to help maintain even temperatures and reduce frost, moisture, and energy loss. Use when the original gasket is cracked, warped, or no longer seals. What it does:

• Creates an airtight barrier between the door and cabinet to keep cool air in and warm air out
• Helps prevent condensation, frost buildup, and uneven cooling in the fresh-food compartment
• Reduces compressor run time and energy waste caused by a failing seal
• Stops door gaps that can allow food spoilage or excess moisture

• One replacement door seal/gasket for the fresh-food compartment

• Unplug the appliance or switch off power before starting any work
• Clean the mounting surface and remove old adhesive or debris for a proper fit
• Warm and flex the gasket if needed (per OEM guidance) to align and seat it evenly; avoid overstretching
• Inspect and reuse or replace retainers/clips as required; test seal by closing the door and checking for gaps

This is a replacement mounting screw used to secure the dual safety valve assembly on compatible gas ranges and ovens. It restores proper fastening so the valve stays firmly in place during operation. What it does

• Secures the safety/dual gas valve to the appliance chassis or manifold
• Prevents valve movement that can interfere with burner operation or alignment
• Commonly replaced when original screw is missing, stripped, or damaged
• Matches OEM thread size and length for correct fit and retention

• One (1) screw, size 10-16 x 0.486

• Disconnect power and shut off gas supply before starting work; follow all safety procedures
• Thread carefully to avoid cross-threading; do not overtighten — snug to OEM torque specification
• Inspect surrounding mounting holes and hardware; replace any stripped or damaged parts for a secure fit

Size: 6-20 x 0.312 inch.

Size: 8-32t x 0.500 inch. Color: Black.

The Screw is an OEM part for Frigidaire ranges and ovens. This part is designed to securely fasten various parts of the appliance, ensuring stability and durability.

Over time, screws can become loose due to the expansion and contraction of materials with temperature changes. Regular use and the occasional necessary removal for repairs or cleaning can also wear down the threads, making them less effective.

Symptoms of a bad Screw (Chrome) include:

• Loose or wobbly components that should be securely fastened.
• Difficulty in securing parts due to stripped or damaged screw threads.
• Visible corrosion or deterioration of the screw.

This OEM Frigidaire part can also be used on Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, and Sears/Kenmore.

Size: 8-18 x 0.5 inch. Color: Chrome.
