Parts for Kitchenaid KDDC24RVS00: 05 - Unit Parts

Note: The original compressor service kit 8201787, which was used as the service replacement for compressor 4344775, is no longer available. Whirlpool has a service bulletin to help determine if there is a service replacement for your model. Contact us for more information.

Rubber grommet for refrigerators. Installs in various cabinet locations to secure components or seal openings. Replace if cracked, missing, or worn.

Adjustable leveling foot that supports and levels your refrigerator. Replace worn, cracked, or missing legs to stop rocking and improve stability.

This drier tube is a component in the refrigerator's sealed refrigeration system that removes moisture from the refrigerant as it circulates. It helps prevent ice blockages that can restrict refrigerant flow and reduce cooling performance. Replace if the refrigerator is not cooling properly, runs continuously, or a technician has diagnosed a moisture-related restriction in the sealed system.

This is the electrical power cord that connects the refrigerator to the wall outlet, supplying electricity to the unit. It includes the plug and wiring needed to deliver the correct voltage to the appliance. Replace this cord if it is frayed, damaged, has exposed wiring, or if the refrigerator intermittently loses power due to a faulty connection.

This is the condenser fan motor located near the compressor at the bottom or rear of the refrigerator. It circulates air over the condenser coils to dissipate heat and maintain efficient cooling. Replace this motor if the refrigerator is running warm, the compressor is overheating, or you no longer hear the fan running when the compressor is on.

This 6 MFD start/run capacitor helps the appliance motor start and run smoothly, restoring proper motor performance and reliable operation. Use when the motor struggles to start or run consistently. What it does:

• Provides the brief voltage boost motors need to start and maintain run speed
• Commonly linked to symptoms such as motor hums, slow or no start, or intermittent running
• Replaces a failed or weak capacitor to improve motor reliability and reduce strain on components
• Matches the specified capacitance required for proper motor timing and operation

• Always disconnect power before inspecting or replacing electrical parts
• Discharge the capacitor before handling to avoid electric shock
• Replace with identical capacitance and mounting style; verify orientation and wire connections

The Screw is an OEM part for Whirlpool microwaves. It is responsible for securing various parts of the microwave together. This screw ensures a tight and secure fit for parts and helps maintain the structural integrity of the microwave, preventing any loose or rattling parts.

A bad microwave screw can occur due to wear and tear, accidental damage, or misplacement during maintenance or repairs. If you notice symptoms such as loose or wobbly components, difficulty in opening or closing the microwave door, or abnormal noises while the microwave is in use, it may be time to replace this part.

Symptoms of a bad microwave screw include:

• Loose or wobbly components
• Difficulty in opening or closing the microwave door
• Abnormal noises during operation

Restore your Whirlpool microwave by replacing the faulty or missing microwave screw with this genuine OEM part.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


Fix refrigerator frost buildup or warm temperatures with this defrost thermostat sensor. Moderately easy repair for most home DIYers with basic tools.

This wire harness cover protects and organizes appliance wiring, helping prevent abrasion and accidental contact for safer, more reliable operation. It keeps wiring routed and out of the way of moving parts. What it does:

• Shields wiring from rubbing, chafing and heat exposure that can cause shorts
• Helps keep harnesses routed neatly to reduce strain and interference
• Can stop intermittent electrical issues when worn covers expose wiring
• Commonly replaced when cover is cracked, melted, or missing

• Disconnect power (unplug or shut off breaker) before starting work
• Remove access panels as required; secure the harness under the cover and fasten per factory locations
• Use basic hand tools (screwdriver/socket) and avoid forcing clips to prevent breakage
• Repair or replace the harness before reassembling

This evaporator fan motor drives the freezer fan that circulates cold air across the evaporator coils and through the ducts. Replacing a weak or noisy motor restores proper airflow for consistent cooling and defrost performance.

• Circulates cold air from the evaporator through the freezer and fresh food compartments
• Helps maintain even temperatures and quicker recovery after door openings
• Common failure symptoms: warm refrigerator section, little/no airflow from vents, loud humming/squealing or intermittent fan operation, and frost/ice buildup on the freezer's rear panel
• Also known as the freezer fan motor or "Motor-Evap"

• Disconnect power; remove shelves/drawers and the rear interior freezer panel to access the fan
• Note wiring and mounting orientation; unplug connectors and remove the old motor
• Transfer the fan blade and any rubber isolators/mounting hardware from the original motor if needed
• Ensure blade orientation and wire routing clear the blades; test operation before reassembly

Fix a non-responsive ingredient center with this refrigerator switch. Controls drawer functions and settings. Direct replacement for select models.

Fix temperature control issues with this refrigerator thermistor. Resolves inaccurate cooling and erratic temperature readings. Direct fit part.

Wire harness for refrigerator ingredient center drawer. Connects electrical components within the specialty compartment. Replace if wiring is damaged or frayed.

This is the appliance control box — the electrical assembly that manages cycle selection, timing and power distribution so your appliance responds correctly to user commands. Replacing a faulty control box restores normal control and cycle operation. What it does:

• Receives inputs from the user interface and controls cycle timing and sequences
• Switches power to motors, valves, heaters or other components as directed
• Sends/receives signals to control indicators and status displays
• Can cause no-start, unresponsive controls, error codes, or incorrect cycles when faulty

• Disconnect all power before attempting replacement to avoid electrical shock
• Handle the board carefully and avoid static discharge; use ESD protection if available
• Reinstall all covers and wire connectors securely; test appliance functions after power is restored

A single replacement mounting screw used to secure appliance panels and components for a stable fit and quiet operation. Use this screw to replace missing or damaged fasteners and restore proper panel alignment and function. What it does:

• Secures panels, trim, and internal brackets to prevent movement and rattling
• Restores proper alignment where a lost or stripped screw allowed gaps
• Helps maintain electrical and mechanical component positioning for safe operation
• Suitable as a direct replacement when the original screw is damaged or missing

• One replacement mounting screw

• Turn off and unplug the appliance before beginning any repair
• Use the correct screwdriver or driver bit to avoid stripping the head
• Tighten until snug—do not overtighten to prevent thread or part damage
• If threads are damaged, replace the mating captive nut or insert as needed
