Parts for Ge GTD65EBSJ2WS: Water System Parts

The Trap Duct Slides are an OEM part for GE dryers. These slides are integral to the dryer's lint trap system, providing a smooth surface for the lint screen to slide in and out easily. This ensures efficient lint trapping and removal.

Replacement of the trap duct slides may be necessary due to wear and tear, damage, or if they become clogged with lint over time.

Symptoms of a bad Trap Duct Slides include:

• Difficulty in inserting or removing the lint screen.
• Excessive lint accumulation outside the trap area.
• Reduced drying efficiency, possibly due to restricted airflow.
• Visible wear or damage to the slides, hindering the movement of the lint screen.
• Potential for increased risk of overheating if lint is not properly trapped.

This GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.


The Trap Duct Assembly for Dryer is an OEM replacement part for GE dryers. It forms the internal ductwork connection between the dryer drum and the vent tube. This assembly is critical for proper airflow and efficient moisture removal during the drying cycle.

Causes of a bad trap duct assembly can include cracks or loose connections due to heat fatigue over many cycles. Ducts must withstand temperature swings and mechanical stresses.

Symptoms of a bad trap duct assembly include:

• Increased drying times
• Excess condensation or moisture remaining in clothes after cycles
• Visible cracks or damage to ducts

This GE replacement part is compatible with Hotpoint, RCA, and Kenmore dryer models.

The Lower Drum Felt seal is an OEM replacement part for GE dryers. The Lower drum felt seal is responsible for creating a seal between the drum and the front panel of the dryer.

This part fixes the following symptoms:

• Air leaking from the dryer drum
• Reduced dryer efficiency and increased energy costs
• Clothes becoming caught in the gap between the drum and front panel
• Potential damage or snags to clothes or the dryer

Causes of a bad Lower Drum Felt Seal can range from normal wear and tear, which degrades the felt material over time, to excessive load sizes that strain the drum and seal. Additionally, over time, the seal can become compressed or damaged, leading to a less effective seal and the potential for heat loss and inefficiency in the drying process.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Lint Screen Housing Seal is an OEM part for GE dryers. This seal is designed to fit around the housing of the lint screen, ensuring a tight seal that prevents lint and small particles from bypassing the filter and entering the dryer's internal components. This seal measures approximately 36” long.

Symptoms of a failing lint screen housing seal include:

• Increased accumulation of lint inside the dryer cabinet
• Decreased drying efficiency, requiring longer cycles to dry clothes
• Visible wear or gaps in the seal

Causes of wear or failure of the lint screen housing seal often include regular use, which can stretch or tear the material, exposure to high temperatures which can degrade the rubber or foam, and improper installation which can lead to a poor fit.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.
