Whirlpool WPY0063532 Broil Element OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WPY0063532 replaces AP6024080, Y0063532, 0060552, 0063532, 1236072, 14250452, 4320840, 63532, D85451-1, D8545101, PS11757430, R0710054, R0710159, Y0060552, Y63532.

Description

This electric range broil element installs at the top of the oven to deliver direct radiant heat for broiling. Replacing a burned-out or damaged element restores fast, even broil performance and consistent top heat.

• Provides high, direct heat from the top of the oven during Broil to sear and brown food
• Common fix for: broiler not heating, weak or uneven broiling, visible blisters/cracks on the element, or sparking during broil
• Mounts at the upper oven cavity; connects to two push-on terminals
• Helps restore consistent top heat and even browning when functioning correctly

What's included: 1 broil heating element Install notes:

• Disconnect power at the breaker or unplug the range before servicing
• Remove oven racks; unfasten mounting screws/bracket, gently pull element forward, and disconnect the wire terminals (support wires to prevent them from falling back)
• Transfer existing mounting hardware if needed; ensure terminals are fully seated and insulated—do not overtighten screws
• The element is clear of the oven liner; restore power and test Broil

This part fixes the following symptoms

• Little to no heat when broiling
• Element will not heat
