Rick K Naperville , IL June 20, 2021 Agitator didn't work Simple by using 7/16 socket with long extension to remove the bolt and pull the whole agitator out and clean them. Put back in together with new parts. It works fine now. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers, Socket Set
Donovan D Maryville , TN May 12, 2016 Upper agitator would not turn With repair kit Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Socket Set
Dana B Warrenton , MO January 12, 2026 Appliance: Model COULD NOT FIND ON ON THE MACHINE! Washing machine would fill with water and stop won't agitate drain or spin My husband researched the problem and purchased a lid switch, timer,cam assembly, and a whirlpool direct drive washer motor coupling to rule out every possible problem. The machine was used when we received it over 10 years ago. It works better than ever. Fair disclosure, my husband is in the maintenance field. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Adjustable Wrench, Nut Drivers, Pliers, Screwdrivers, Socket Set, Wrench Set
Charles H Ripley , WV June 27, 2014 Appliance: Model 110-16972500 Agitator upper portion was not turning Pulled the top of the agitator off and removed the dust shield beneath. Removed the bolt holding the agitator in place and pulled it up and out. The dogs that were supposed to turn the agitator were worn away. Ordered the Cam-Agit and installed it. Everything works like it is supposed too. Easy fix. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers, Socket Set
