Whirlpool W10804665 Washer Motor Start Capacitor OEM Part

I was actually getting an error code for the shifter and speed sensor. I ordered a shifter, which included the speed sensor, and replaced that part but the washer still didn't work. After doing some more research online, someone mentioned that the capacitor may be bad. After talking to my dad, who is an electrician, he said it sounded like my problem could very well be the capacitor. Knowing that we'd been without a washer for almost two weeks at this point, I went ahead and ordered the capacitor. It arrived two days after I ordered it (thanks for the prompt service!). I got it changed out and the washer now works. I'm happy I was finally able to make the repair and my wife is happy we don't have to go to the laundry-mat in town anymore!

Ordered capacitor, received it the next day with the standard shipping, installed it and the wash machine now works fine.

Leaned machine over just enough to access bottom of washer, quick and easy fix..

BOTH went out in the same day! I ordered my parts, watched the repair videos and had both appliances fixed in about half an hour. Use a putty knife to lift the top off of the dryer. (I even did it with my driver license as an experiment.) The washer, I just tipped back and leaned against the wall. 2 5/16 nuts for the drive cover, one for the capacitor and 2 phillips screws for the shift actuator. It actually took as long to do the calibration mode as it did to fix the washer. After the repair, you have to go into diagnostic mode then calibration mode if you replace the capacitor. 3 clicks right on the dial, 1 left, 1 right, all lights flash, then turn until rinse is on, then hit start. easy peasy.

Chatted with Kenneth K who helped me ID the correct wire harness and part number. Kenneth was a big help because there where no graphics of the harnesses on your site. He located a diagram for me to assure we had the correct part number. Ordered harness and condenser then replaced parts. Parts arrived in a couple of days
