Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Dishwasher Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number W10473197 replaces AP5617593, 2312559, AH3651408, EA3651408, PS3651408, W10375793, W10461375.
Description
This electronic control board is the appliance's main brain. It manages cycles and powers key components based on sensor and user input, restoring normal operation and responsive controls when the original board fails.
- Directs the appliance's operations by processing inputs from sensors and the user interface
- Distributes power to motors, valves, heaters, fans, and other loads as needed
- Monitors system status and logs/communicates fault or error codes
- Typical failure symptoms: won't start, unresponsive controls, stops mid-cycle, intermittent power, or recurring error codes
What's included: 1 electronic control board Install notes:
- Disconnect power to the appliance before servicing
- Use ESD protection and handle the board by its edges
- Photograph wire/connector positions; transfer connectors one at a time to the new board
- Ensure all harnesses are fully seated and the board is secured; run a diagnostic or test cycle after installation
