Whirlpool W10860464 Electronic Control Board (Main Control) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10860464 replaces AP6026286, W10571743, 4454868, PS11737994, W10166392.

Description

This electronic control board manages the appliance's core operations by interpreting inputs and switching power to components. Replacing a failed board restores proper control of cycles and functions when the unit is unresponsive or behaving erratically.

• Coordinates cycle timing and operation based on signals from sensors and the user interface
• Switches power to loads via onboard relays/triacs
• Monitors for faults and stores/displays error codes for diagnostics
• Failure symptoms can include: won't start, no response at controls, cycle won't advance, intermittent operation, or recurring error codes

What's included: 1 electronic control board Install notes:

• Disconnect power before servicing; follow all safety and ESD precautions
• Photograph/label connectors; transfer wiring one at a time to the new board and secure with existing hardware
• Restore power and perform any model-specific diagnostics, resets, or calibrations per the tech sheet/service manual
