Whirlpool W11116592 Electronic Control Board (Main) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others. See all items in Washer Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W11116592 replaces AP6261034, W10916226, 4545913, PS12114298, W10803588, W10831168, W10865068, W10916483.

Description

Restore reliable operation with this electronic control board. Acting as the appliance's central processor, it interprets user/sensor inputs and switches components to run the selected cycle accurately and consistently. What it does

• Controls cycle timing and powers components to execute selected programs
• Communicates with sensors and the user interface to carry out settings
• Typical failure symptoms: won't start or respond to controls, stops mid-cycle, won't advance through a cycle, or displays error codes
• Can cause intermittent power or unresponsive controls when faulty

What's included

• 1 electronic control board

Install notes

• Disconnect electrical power at the breaker before servicing; verify no power is present
• Handle the board by the edges and use anti-static protection
• Photograph wiring and move connectors one at a time to matching terminals; transfer any reusable brackets/shields from the original part if applicable
• After installation, restore power and run a test/diagnostic cycle per the tech sheet for your model to verify operation
