Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Dishwasher Control Board.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number 12002711 replaces AP4009642, W10169327, 1184143, 99002978, 99003159, 99003352, 99003478, AH2004006, EA2004006, PS2004006.
Description
This control board kit replaces the appliance's main electronic control to restore normal cycle selection and responsive user controls. It provides the core logic and interface needed for timing, sensor response, and displaying status. What it does:
- Manages cycle timing, sensor inputs, and actuator commands to run selected cycles
- Processes user inputs from the console and updates the display/status indicators
- Helps resolve symptoms like unresponsive controls, missing display feedback, or intermittent cycle failures
- Works as the OEM-specified replacement logic module for affected control functions
What's included:
- One control board kit as shown
Install notes:
- Disconnect power (and water/gas if applicable) before servicing to avoid shock or injury
- Handle boards by the edges and ground yourself to prevent ESD damage
- Follow the appliance's service manual for connector locations and mounting; retain all fasteners
